Appendix B: Specifications - NanoVibronix UROSHIELD User Manual

UroShield® User Manual

Appendix B: Specifications

Driver model FD-14B
Frequency:
Voltage output:
Rechargeable battery:
Dimensions:
Weight:
Housing:
UroShield Actuator
Dimensions:
Weight (including cable):
Housing:
Charger
Voltage input: 100-240 VAC, ~ 300 mA, 50/60 Hz
Output: 5 VDC, 1 A
Note: Use an appropriate adaptor for local mains.
Product classification
Low risk device classification:
CE mark – Class II a
Compliance with standards
EN 60601-1; EN 60601-1-2
USUM005 Ver. 07
90 kHz ± 0.001 kHz, modulated by 30 Hz
12 V p-p
Lithium-Ion, 3.7 V, 1200 mAh (full charging time ~ 2 hours)
125 mm (L) x 39 mm (W) x 13 mm (H)
Approximately 70 g
ABS
42 mm x 34 mm x 15 mm
20 g
Polypropylene
30
