SURFACE MAINTENANCE:
Do not use corrosive detergents, abrasive detergents or oven cleaners.
Do not use any product containing chlorine bleach or any product containing chloride.
Do not use steel wool or abrasive scrubbing pads which will scratch and damage surface.
Cleaning Stainless Steel
Clean periodically with warm soapy water and clean cotton cloth or micro fiber cloth. Always rub in the
direction of the stainless steel grain. To remove heavier grease build up use a liquid degreaser detergent.
After cleaning use a non-abrasive stainless steel polish/cleaners, to polish and buff out the stainless luster
and grain. Always scrub lightly, with clean cotton cloth or micro fiber cloth and buff in the direction of the
stainless steel grain.
Cleaning the Baffle Filters
The filters are intended to trap residue and grease from cooking. Although the filters should never need
replacing, they are required to be cleaned every 30 days or more often depending on cooking habits.
Filters may be placed in dishwasher at low heat or soaked in hot soapy water Dry filters and re-install before
using hood.
Installing the Baffle FIlters, FIG 5:
1. Place filter into top groove of the insert as shown and
pull towards front of insert using handles.
2. Pivot back of filter upwards so it is angled in the insert.
3. Push filter into channel on back of insert to lock into place.
Cleaning the Grease Tray
The grease tray is intended to catch residue and grease that may drip from the baffle filters. The grease tray
should be cleaned when baffle filters are cleaned. Clean the grease tray by soaking in hot soapy water and
gently scrubing any residue off with a soft terry cloth. Dry grease tray and re-install before using hood.
Removing the Grease Tray
Grease tray has a hooked lip that attaches to bottom panel top edge.
Remove grease tray by:
1. Pull up on tray to release from bottom panel. FIG. 6-1
2. Pull tray out of insert body. FIG. 6-2
1
13
1
2
FIG. 5
1
2
FIG. 6
