- Page 1 LE910Cx-WE866C3-P LTE Bundling User Guide 1VV0301578 Rev. 5 – 2019-05-17 Mod. 0805 2017-01 Rev.6...
-
Page 2: Notice
LE910Cx-WE866C3-P LTE Bundling User Guide SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE NOTICE While reasonable efforts have been made to assure the accuracy of this document, Telit assumes no liability resulting from any inaccuracies or omissions in this document, or from use of the information obtained herein. -
Page 3: Usage And Disclosure Restrictions
LE910Cx-WE866C3-P LTE Bundling User Guide USAGE AND DISCLOSURE RESTRICTIONS License Agreements The software described in this document is the property of Telit and its licensors. It is furnished by express license agreement only and may be used only in accordance with the terms of such an agreement. -
Page 4: Applicabilty Table
LE910Cx-WE866C3-P LTE Bundling User Guide APPLICABILTY TABLE PRODUCTS WE866C3-P LE910 CAT.1 SERIES 1VV0301578 Rev. 5 Page 4 of 32 2019-05-17... -
Page 5: Table Of Contents
LE910Cx-WE866C3-P LTE Bundling User Guide Contents NOTICE…....................... 2 COPYRIGHTS ....................2 COMPUTER SOFTWARE COPYRIGHTS ............2 USAGE AND DISCLOSURE RESTRICTIONS ..........3 APPLICABILTY TABLE ................. 4 CONTENTS ....................5 INTRODUCTION ................8 Scope ................... 8 Audience..................8 Contact Information, Support ............8 Text Conventions ................ - Page 6 LE910Cx-WE866C3-P LTE Bundling User Guide Wi-Fi STA Mode ................. 26 6.2.1. Exchanging Data with Cloud through Wi-Fi ......... 26 APPENDIX ................. 28 WE866C3 Connection Manager ..........28 7.1.1. Enabling the WE866C3 Connection Manager ......29 7.1.2. Disabling the WE866C3 Connection Manager ......29 Limitations and Known Issues .............
- Page 7 LE910Cx-WE866C3-P LTE Bundling User Guide FIGURE LIST Figure 1: Generic Telit EVB Board .................. 12 Figure 2: MultiTech Interface Board - Top View .............. 13 Figure 3: MultiTech Interface Board Bottom View ............14 Figure 4: WE866C3-P M.2 Card ..................14 Figure 5: M.2 plugged into MTB ..................
-
Page 8: Introduction
LE910Cx-WE866C3-P LTE Bundling User Guide INTRODUCTION Scope This document provides information required to setup and run the Telit LE910Cx + WE866C3-P LTE module. Audience This document is intended only for Telit customers who want to set up a bundling application using LE910Cx + WE866C3-P LTE module. -
Page 9: Text Conventions
LE910Cx-WE866C3-P LTE Bundling User Guide Text Conventions Danger – This information MUST be followed or catastrophic equipment failure or bodily injury may occur. Caution or Warning – Alerts the user to important points about integrating the module, if these points are not followed, the module and end user equipment may fail or malfunction. -
Page 10: Related Documents
LE910Cx-WE866C3-P LTE Bundling User Guide Related Documents • WE866C3 Hardware Design Guide, 1VV0301495 • WE866C3-P M.2 I-F Adapter HW User Guide, 1VV0301533 • Telit Multi Technology TLB Hardware User Guide, 1VV0301508 • Telit Evaluation Board (EVB) HW User Guide, 1VV0301249 1VV0301578 Rev. -
Page 11: Overview
LE910Cx-WE866C3-P LTE Bundling User Guide OVERVIEW Telit’s WE866C3 is a low power, high bandwidth 802.11ac and Bluetooth 4.2 module with a small footprint that provides an easy and cost-effective way to achieve best possible wireless connectivity. Advanced LTE, Wi-Fi and Bluetooth coexistence dramatically reduces complexity designing cellular back haul with the LE910Cx 4G LTE module family, making the WE866C3 module ideal for a wide range of IoT applications including commercial building automation, OEM telematics, fleet management, and video... -
Page 12: Hardware
LE910Cx-WE866C3-P LTE Bundling User Guide HARDWARE This section describes the hardware components of the LE910Cx +WE866C3-P LTE module. Telit Evaluation Board The Telit Evaluation Board is a generic developer’s platform, which is designed to provide the complete development environment to the user and intended to be used with a new set of Telit IoT modules. -
Page 13: Figure 2: Multitech Interface Board - Top View
LE910Cx-WE866C3-P LTE Bundling User Guide • LE910Cx module. • 3x M.2 type mini card slots. • Programmable FPGA. • RF SMA connectors. • Board to Board connectors for interfacing to EVB main board • Module specific circuitry which is not part of the generic circuitry of the EVB Power supply and control interface for the cellular module is provided from the EVB via the B2B connectors. -
Page 14: We866C3-P M.2 Card
LE910Cx-WE866C3-P LTE Bundling User Guide Figure 3: MultiTech Interface Board Bottom View For detailed description, refer LE910Cx Multi Technology Interface Board TLB – HW User Guide. WE866C3-P M.2 Card The M.2 card is designed to interface the Telit LE910Cx module family on an IFBD with the Telit Generic Evaluation Board (EVB) thus forming a complete Development Kit of LE910Cx. -
Page 15: Figure 5: M.2 Plugged Into Mtb
LE910Cx-WE866C3-P LTE Bundling User Guide The WE866C3-P M.2 card follows the below M.2 specification: • SDIO based Socket 1 • 2230 size type • Key type E This form-factor card specification is intended to support Wireless Connectivity devices including combinations of Wi-Fi, BT, NFC, and/or GNSS. The card includes a U. -
Page 16: Figure 6: Final Assembly
LE910Cx-WE866C3-P LTE Bundling User Guide The final assembly of the LE910Cx + WE866C3-P module is as shown below: Figure 6: Final Assembly 1VV0301578 Rev. 5 Page 16 of 32 2019-05-17... -
Page 17: Features
LE910Cx-WE866C3-P LTE Bundling User Guide FEATURES Specification Overview • Dual-Band 1x1 Wi-Fi + BT module based on QCA9377-3 • 802.11 a/b/g/n/ac o Up to 40Mhz channel BW for 2.4G (802.11n) o Up to 80Mhz channel BW for 5G (802.11ac) o Max TpT ~215Mbps •... -
Page 18: Data Rate
LE910Cx-WE866C3-P LTE Bundling User Guide 802.11 PHY Specification Overview Data Range (m) 802.11 Release Frequency Bandwidth Rate MIMO Modulation Protocol Date (GHz) (MHz) (Mbit/s) streams *SGI Indoor Outdoor Jul-19 2.87 (Draft 1.Jan17) 1201 Data Rate • 802.11a (5GHz): 6, 9, 12, 18, 24, 36, 48, 54Mbps •... -
Page 19: Wi-Fi Interface
LE910Cx-WE866C3-P LTE Bundling User Guide Wi-Fi Interface The Wi-Fi Interface is part of the Baseband System of the cellular module. This section describes the method to connect the WIFI interface to WE866C3 module. The Wi-Fi Interface is a dedicated SDIO interface that is used as a communication channel to the Modem chipset. -
Page 20: Set Up
LE910Cx-WE866C3-P LTE Bundling User Guide SET UP Prerequisites • PC with Windows XP or higher, running a serial terminal such as TATC to communicate over the COM interface. • One USB cable. Start Up Plug the MultiTech Board on the generic EVB as shown below. Figure 7: EVB with IFBD on Top Connect the power supply cable to generic EVB [6-15 V]. -
Page 21: Figure 8: Led Glowing After Successful Connection
LE910Cx-WE866C3-P LTE Bundling User Guide LED’s Figure 8: LED Glowing after Successful Connection Connect the one end of the mini USB cable to the USB2.0_3.0 port in EVK and other end to the USB port to your PC. The USB connection is used for establishing a UART communication to a PC over a virtual COM port. -
Page 22: Configuring The We866C3 Module
LE910Cx-WE866C3-P LTE Bundling User Guide Configuring the WE866C3 Module Assuming all settings are set properly, you should be able to communicate with the module. The Telit AT Controller can be used to read or modify the configuration settings. The Telit AT Controller is available for download from the Telit- Download Zone. -
Page 23: Figure 10: Telit At Controller Device Information
LE910Cx-WE866C3-P LTE Bundling User Guide After successful configuration of the Telit AT Controller press the Connect button to connect to the module and receive the device informations. Figure 10: Telit AT Controller Device Information Next, start the AT Terminal to communicate with the module using the AT commands. -
Page 24: Wireless Operations
LE910Cx-WE866C3-P LTE Bundling User Guide WIRELESS OPERATIONS This chapter describes the use cases for wireless operations in WE866C3-P module. Wi-Fi Hot-Spot Mode 6.1.1. Accessing Internet through Cellular Hotspot Mode The WE866C3-P module operates in AP mode. The internet connectivity for the Wi-Fi module is provided via cellular modem. -
Page 25: Exchanging Data Between Mcu And Wi-Fi Station
LE910Cx-WE866C3-P LTE Bundling User Guide Step 4: Bring up a data connection in the modem side AT#SGACT=2,1 The Linux and the host MCU will share the cellular data connection, and every STA connected to the device will be routed through the Linux platform. 6.1.2. -
Page 26: Wi-Fi Sta Mode
LE910Cx-WE866C3-P LTE Bundling User Guide Step 8: Stop the WE866C3 Connection Manager using the following commands AT#CONNMGRSTART=0 Step 9: Disable the WLAN AT#WLANSTART=0 For more details regarding USB composition selection for WE866C3 Connection Manger, refer Chapter 7 Appendix. Wi-Fi STA Mode 6.2.1. - Page 27 LE910Cx-WE866C3-P LTE Bundling User Guide AT#SSEND=101 Enter data when prompted and press Ctrl-Z Step 8: Stop the WE866C3 Connection Manager using the following commands AT#CONNMGRSTART=0 Step 9: Disable the WLAN AT#WLANSTART=0 For more details regarding AT Commands, refer to LE910Cx AT Command Reference. 1VV0301578 Rev.
-
Page 28: Appendix
LE910Cx-WE866C3-P LTE Bundling User Guide APPENDIX WE866C3 Connection Manager WE866C3 Connection Manager is a Linux application running on apps processor enabled for bundling Wi-Fi features. It is supported on USB compositions 13 and 14. • In USB compositions 13, WE866C3 Connection Manager is supported on MODEM1 and MODEM2. -
Page 29: Enabling The We866C3 Connection Manager
LE910Cx-WE866C3-P LTE Bundling User Guide 7.1.1. Enabling the WE866C3 Connection Manager Perform the following steps to enable the WE866C3 Connection Manger: 1. Select the USB composition AT#USBCFG=13 or, AT#USBCFG=14 2. Run the connection Manager • To run the connection manager on MODEM1, issue the following commands AT#CONNMGRSTART=1,0 •... -
Page 30: Others
LE910Cx-WE866C3-P LTE Bundling User Guide Features/Items Related AT command Parameter <dataMode> Send and receive data in AT#SCFGEXT Hexadecimal format <sendDataMode> Abort Connection attempt AT#SCFGEXT2 <abortConnAttempt> NO CARRIER indication AT#SCFGEXT2 <noCarrierMode> 7.2.3. Others • Echo configuration display does not reflect the actual configuration. •... -
Page 31: Document History
LE910Cx-WE866C3-P LTE Bundling User Guide DOCUMENT HISTORY Revision Date Changes 2019-01-11 First issue 2019-02-25 Modified description for the following AT Commands • AT#WLANSECURITY • AT# WLANMACMODE • AT#WLANPC 2019-03-29 Removed the following AT Commands which are not supported. • AT#WLANMAC •... - Page 32 Mod. 0805 2017-01 Rev.6...
