- Page 1 Библиотека СОК User manual NIBE™ F135 Exhaust air module UHB GB 1522-1 331433...
-
Page 3: Table Of Contents
1 Important information Installation data Safety information Serial number Contact information F135 – An excellent choice 2 The heating installation – the heart of the house The function of the exhaust air module Maintenance of F135 3 Disturbances in comfort... -
Page 4: Important Information
Exhaust air fan in- stallation 5.3.14 Pump speed Serial number must always be given Certification that the installation is carried out according to instructions in NIBE's installer manual and applicable regulations. Date __________________ Signed _________________________ Chapter 1 | Important information... -
Page 5: Safety Information
Marking F135 is CE marked and fulfils IP21. The CE marking means that NIBE ensures that the product meets all regu- lations that are placed on it based on relevant EU directives. The CE mark is obligatory for most products sold in the EU, regardless where they are made. -
Page 6: Serial Number
Serial number The serial number can be found to the left, on top of F135. Serial number Caution Always give the product's serial number (14 digits) when contacting your installer. Chapter 1 | Important information NIBE™ F135... -
Page 7: Contact Information
NIBE Energy Systems France Sarl, Zone industrielle RD 28, Rue du Pou du Ciel, 01600 Reyrieux Tel : 04 74 00 92 92 Fax : 04 74 00 42 00 E-mail: info@nibe.fr www.nibe.fr NIBE Energy Systems Ltd, 3C Broom Business Park, Bridge Way, Chesterfield S41 9QG Tel: 0845 095 1200 Fax: 0845 095 1201 E-mail: info@nibe.co.uk... - Page 8 NIBE AB Sweden, Box 14, Hannabadsvägen 5, SE-285 21 Markaryd Tel: +46-(0)433-73 000 Fax: +46-(0)433-73 190 E-mail: info@nibe.se www.nibe.se For countries not mention in this list, please contact Nibe Sweden or check www.nibe.eu for more information. Chapter 1 | Important information...
-
Page 9: F135 - An Excellent Choice
All control of F135 is from the indoor module. -
Page 10: The Heating Installation - The Heart Of The House
0 °C 22 °C -3 °C 0 °C Heat source Värmekälla The temperatures are only examples and may vary between different installations and time of year. Chapter 2 | The heating installation – the heart of the NIBE™ F135 house... -
Page 11: The Function Of The Exhaust Air Module
Here, the air releases the heating energy to the brine and the air's temper- ature drops significantly. The cold air is then blown out of the house. Chapter 2 | The heating installation – the heart of the NIBE™ F135 house... -
Page 12: Maintenance Of F135
On the other hand, it is recommended that you check your installation regularly. If F135 is installed with an indoor module and something untoward occurs, a message appears regarding the malfunction in the form of different alarm texts in the indoor module display. - Page 13 The exhaust air module starts when the supply cable is connected to an earthed socket. Settings All settings for F135, such as fan speed and scheduling, are carried out in the indoor module. See the indoor module manual for more information. Chapter 2 | The heating installation –...
-
Page 14: Disturbances In Comfort
All the indoor module measured values are gathered under menu 3.1 in the indoor module menu system. Looking through the values in this menu can often simplify finding the source of the fault. Manage alarm (NIBE Indoor module) Low pressure alarm alarm... -
Page 15: Troubleshooting
Problems with F135 do not affect the indoor module's operation. You do not need to select "aid mode" in event of problems with F135. - Page 16 Clean or replace filter (see page 11). ■ Gurgling sound Not enough water in the water seal. ■ Refill the water seal with water. ■ Choked water seal. ■ Check and adjust the condensation water hose. ■ Chapter 3 | Disturbances in comfort NIBE™ F135...
-
Page 17: Technical Data
4 Technical data Detailed technical specifications for this product can be found in the in- stallation manual (www.nibe.eu). Chapter 4 | Technical data NIBE™ F135... -
Page 18: Glossary
Heat exchanger where the refrigerant evaporates by retrieving heat energy from the air which then cools. Exhaust air The air that comes from the exhaust air device in the various rooms of the accommodation, to F135. Chapter 5 | Glossary NIBE™ F135... - Page 19 Exhaust air devices Vents, usually in the ceiling, in the kitchen/bathroom/clothes closet where the air is drawn in to be forwarded to F135. Expansion valve Valve that reduces the pressure of the refrigerant, whereupon the temper- ature of the refrigerant drops.
-
Page 20: Index
Item register Contact information, 5 Disturbances in comfort Manage alarm, 12 Troubleshooting, 13 F135 – An excellent choice, 7 Glossary, 16 Heat pump function, 9 Important information, 2 Contact information, 5 F135 – An excellent choice, 7 Installation data, 2... - Page 24 WS name: -Gemensamt WS version: a35 (working edition) Publish date: 2015-06-10 11:52 NIBE AB Sweden Hannabadsvägen 5 Box 14 SE-285 21 Markaryd info@nibe.se www.nibe.eu 331433...
