- Page 1 IHB EN 1841-5 INSTALLATION MANUAL 331432 Exhaust air module NIBE F135...
-
Page 3: Table Of Contents
Table of Contents 1 Important information 7 Disturbances in comfort Safety information Info-menu NIBE indoor module Symbols Manage alarm Marking Troubleshooting Serial number 8 Accessories Recovery Top cabinet Inspection of the installation 9 Technical data 2 Delivery and handling Dimensions and setting-out coordinates... -
Page 4: Important Information
This symbol indicates danger to person or ma- chine . Caution This symbol indicates important information about what you should consider when installing or servicing the installation. This symbol indicates tips on how to facilitate using the product. Chapter 1 | Important information NIBE F135... -
Page 5: Recovery
It must be disposed of at a special waste station or dealer who provides this type of service. Improper disposal of the product by the user results in administrative penalties in accordance with current le- gislation. NIBE F135 Chapter 1 | Important information... -
Page 6: Inspection Of The Installation
(page Setting the ventilation flow Exhaust air filter Heating medium (page 23) System flushed System vented Circulation pump setting Setting heating medium flow System pressure Electricity (page Supply connected 230 V Circuit fuses Chapter 1 | Important information NIBE F135... -
Page 7: Delivery And Handling
10-50* 20-55 mm 30 - 50 mm • F135 must be positioned with the back towards a wall. Install the brackets or position F135 against an outside wall, ideally in a room where noise does not matter, in order to eliminate noise problems. If this is not possible, avoid placing it against a wall behind a bed- room or other room where noise may be a problem. -
Page 8: Supplied Components
Power supply cable Communication cable Circulation pump 2 x bracket 6 x nuts 6 x screws 4 x washers LOCATION The kit of supplied items is placed on top of the product. Chapter 2 | Delivery and handling NIBE F135... -
Page 9: Removing The Covers
Pull the hatch towards yourself. NOTE An earth cable is installed in the hatch, which can therefore only be lifted out 35 cm. If the hatch needs to be removed completely, the cable must be disconnected. NIBE F135 Chapter 2 | Delivery and handling... -
Page 10: The Exhaust Air Module Design
3 The exhaust air module design Component positions XL43 BT77 XL44 QM25 BT12 GQ10 EB10 BT76 BT16 QN20 BT13 Chapter 3 | The exhaust air module design NIBE F135... -
Page 11: List Of Components
Temperature sensor, defrosting MISCELLANEOUS BT77 Temperature sensor, incoming air Rating plate Serial number plate Not visible in the image Designations in component locations according to standard IEC 81346-1 and 81346-2. NIBE F135 Chapter 3 | The exhaust air module design... -
Page 12: Pipe And Air Connections
Heat exchanger To make the installation economical, NIBE recommends Indoor module that all pipes between F135 and the water heater are insulated. The insulation should be at least 12 mm thick. Cooling system NOTE Air/water heat pump... -
Page 13: Dimensions And Pipe Connections
SYSTEM DIAGRAM Dimensions and pipe F135 is an exhaust air module. connections When the air passes through the evaporator, the refri- gerant evaporates because of its low boiling point. In this way the energy in the air is transferred to the refri- gerant. -
Page 14: Mounting
Screw F135 into place in the brackets using the M5 Mounting screws and nuts supplied. The exhaust air module is wall-mounted using the brackets enclosed. The exhaust air module can also be placed on a suitable flat surface. NOTE Check that the mountings are located in the intended grooves on the exhaust air module. -
Page 15: Connection To Indoor Module And Air/Water Heat Pump
(XL9) are connected to the return line between the indoor module and the air/water heat pump. The particle filter must be installed before F135 to prevent dirt from being deposited in F135. Install the shut-off valves outside F135 to facilitate any future servicing. - Page 16 DOCKING NIBE AIR/WATER HEAT PUMP The demand on F135 is controlled by the indoor module in the system. The pump and fan speed are also con- trolled from the menu in the indoor module. -AZ1 -AZ1 -AZ1-HQ1 -AZ1-GP12 -AZ1-QM1 -AZ1-QM2...
- Page 17 In such instances, 4-pipe cooling must be connected between the air/water heat pump and F135. When there is also a pool, F135 must be connected between 4-pipe cooling and the pool. The demand on F135 is controlled by the indoor module in the system. The pump and fan speed are also controlled from the menu in the indoor module.
-
Page 18: General Ventilation Connections
Exhaust air duct (kitchen fan) must not be connected to F135. ventilation To prevent food vapour being transferred to F135 the distance between the kitchen fan and the exhaust air connections device must be considered. The distance should not be less than 1.5 m, but this can vary between different in-... -
Page 19: Ventilation Flow (Exhaust Air)
Ventilation flow (exhaust air) Connect F135 so that all the exhaust air, except kitchen duct air (kitchen fan), passes through the evaporator (EP1) in the exhaust air module. The ventilation flow must comply with the applicable national standards. For the optimum exhaust air module performance, the ventilation flow should not be less than 20 l/s (72 m³/h) -
Page 20: Electrical Connections
• Disconnect F135 before insulation testing the house wiring. F135 is connected to an earthed socket with the factory- • For electrical wiring diagram for F135, see page installed connection cable (length approx. 2.8 m), which is fitted with a plug. - Page 21 X11:1 (15), X11:2 (14) and X11:3 (13). Connect the circulation pump's communication cable to the six pin terminal block in F135 X10:1 (Blue), X10:2 (Brown) and X10:6 (Black). Use a 3 core cable of at least 0.5 mm² cable area.
-
Page 22: Optional Connections
Optional connections AUX INPUTS Connecting the shut-off valve (QN44) Connect the motor (QN44) to AA5-X9:2 (signal), AA5- X9:1 (N) and AA5-X10:2 (230 V). Unit box External AA5-X9 QN44 Black Blue Brown -X10 AA5-X10 Chapter 5 | Electrical connections NIBE F135... -
Page 23: Commissioning And Adjusting Preparations
Check that the externally mounted shut-off valves for the heating system are open. Open the vent valve (QM25). Open the externally mounted filler valves. F135 and the rest of the climate system are filled with water. When the water that exits the vent valve (QM25) is not mixed with air, close the valve. -
Page 24: Start-Up And Inspection
"". NOTE The circulation pump must not be powered up until F135 is activated in the indoor module. Start F135 by connecting the supply cable. Set the indoor module's switch to "". Follow the instructions in the start guide in the in- door module display. - Page 25 NOTE Order a ventilation adjustment to complete the setting. Fan capacity Available pressure Tillgängligt tryck (Pa) 100% (l/s) Airflow Luftflöde Power, fan Effekt Output 100% (l/s) Airflow Luftflöde NIBE F135 Chapter 6 | Commissioning and adjusting...
-
Page 26: Disturbances In Comfort
Start by checking the following items: ALARM • That the feed cable is connected to F135. In the event of an alarm with a red status lamp a mal- function has occurred that the indoor module cannot •... - Page 27 – The heat pump defrosts. GURGLING SOUND • Not enough water in the water seal. – Refill the water seal with water. • Choked water seal. – Check and adjust the condensation water hose. NIBE F135 Chapter 7 | Disturbances in comfort...
-
Page 28: Accessories
8 Accessories More info and images available at nibe.eu. Not all accessories are available on all markets. Top cabinet Top cabinet that conceals the ventilation ducts. HEIGHT 245 MM HEIGHT 345 MM Part no. 089 756 Part no. 089 757 RSK no. -
Page 29: Technical Data
9 Technical data Dimensions and setting-out coordinates NIBE F135 Chapter 9 | Technical data... -
Page 30: Technical Specifications
/h), exkl. driveffekt för fläkt The value varies with the fan speed selected. For more detailed sound data, including sound to ducts, visit nibe.eu. The value can vary with the room’s damping capacity. These values apply at a damping of 4 dB. - Page 31 Other 1x230 V Dimensions and weight Width Depth Height 490 - 515 Weight RSK No. 625 12 41 Part No. 066 075 NIBE F135 Chapter 9 | Technical data...
-
Page 32: Energy Labelling
Annual energy consumption space heating, warm cli- 587 / 731 mate Seasonal space heating energy efficiency, cold climate 147 / 117 Seasonal space heating energy efficiency, warm cli- 136 / 110 mate Sound power level L outdoors Chapter 9 | Technical data NIBE F135... - Page 33 Nominal heating medium flow 0.13 Annual energy consumption 1,087 Brine flow brine-water or water-water heat pumps Contact information NIBE Energy Systems – Box 14 – Hannabadsvägen 5 – 285 21 Markaryd – Sweden NIBE F135 Chapter 9 | Technical data...
-
Page 34: Electrical Circuit Diagram
Electrical circuit diagram Chapter 9 | Technical data NIBE F135... -
Page 35: Item Register
Energy labelling, 32 Start-up and inspection, 24 Information sheet, 32 Setting the ventilation, 25 Technical documentation, 33 Start-up with NIBE Indoor module, 24 Exhaust air duct, 18 Supplied components, 8 External connection options Symbol key, 12 Possible selection for AUX inputs, 22... - Page 36 Transport, 7 Assembly, 7 Troubleshooting, 26 Item register NIBE F135...
-
Page 39: Contact Information
Tel: +46 (0)433-27 3000 kuzmin@evan.ru info@nibe.se nibe-evan.ru nibe.se SWITZERLAND NIBE Wärmetechnik c/o ait Schweiz Industriepark, CH-6246 Altishofen Tel. +41 (0)58 252 21 00 info@nibe.ch nibe.ch For countries not mentioned in this list, contact NIBE Sweden or check nibe.eu for more information. - Page 40 WS version: a597 (working edition) Publish date: 2018-10-11 10:25 This manual is a publication from NIBE Energy Systems. All product illustrations, facts and data are based on the available information at the time of the publication’s approval. NIBE Energy Systems makes reservations for any factual or printing errors in this manual.
