Programming

Function
PIN Management Functions
Set Defaults
Delete PIN
Set PIN
Penalty Time
Invalid PIN Alarm
Door Management Functions
Open Duration
Anti-Follow
Door Propped Alarm Delay
Door Propped Alarm Duration *23*N*
Forced Door Alarm
Enter the programming mode by pressing the PROGRAM MODE button inside the
control unit. The red program LED in the control unit and the green LED on the keypad
will both flash to verify that the programming mode is active. To exit programming,
press the PROGRAM MODE button again or the # key on the keypad. Alternatively,
the system will revert to normal mode if no keys are pressed for 5 minutes.
Initial Settings: During a new installation or if existing settings are unknown, it is
recommended that the default values for all PIN and door monitoring settings be reset
by entering *00* on the keypad.
PIN Management: A new valid PIN code can only be set when the system is in the
programming mode. To establish a new valid PIN, enter *11*N*, where N is any
number containing 3-6 digits. To delete the current valid PIN, enter *10* to effectively
disable the keypad since no PIN entry can be used to release the door.
Penalty Delays: An invalid PIN penalty feature protects against an unauthorized user
gaining entry by entering successive guesses of the correct PIN. When an invalid PIN
is entered, the system then ignores all further PIN entries for 5 to 60 seconds. The
default value is 5 seconds. To change the penalty time, enter *12*N*, where N is from
5 to 60. After five successive invalid PIN entries, the penalty time is automatically reset
to 60 seconds until the valid PIN is entered. This feature increases the average time it
would take to successfully guess the valid PIN and is particularly effective in protecting
Sequence
*00* N/A
*10* N/A
*11*N* 000 to 999, 9999, 99999 or
999999
*12*N* 5 to 60 (seconds)
*13*N* 0=off, 1=on
*20*N* 1 to 60 (seconds)
*21*N* 0=off, 1=on
*22*N* 0=off, 1 to 255
(seconds)=on
0=door closed, 15 to 255
(seconds)
*24*N* 0=off, 1=on
12
Range of N Default
N/A
N/A
No valid PIN
5 seconds
Off
5 seconds
Off
Off
Door closed
Off
