Moniteq CRYPTO-LOCK CC-8521AN Instruction Manual

Single door access control system

Advertisement

Quick Links

CRYPTO-LOCK
Model CC-8521AN
Single Door Access
Control System
(2/20)
MONITEQ, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CRYPTO-LOCK CC-8521AN and is the answer not in the manual?

Questions and answers

Summary of Contents for Moniteq CRYPTO-LOCK CC-8521AN

  • Page 1 CRYPTO-LOCK Model CC-8521AN Single Door Access Control System (2/20) MONITEQ, Inc.
  • Page 3: Table Of Contents

    Crypto-Lock Model CC-8521AN INSTRUCTION MANUAL TABLE OF CONTENTS 1. INTRODUCTION ....................4 2. SPECIFICATIONS....................6 3. SUPPLIED EQUIPMENT..................7 4. FUNCTIONS OF CONTROLS AND INDICATORS..........8 A. KEYPAD ......................8 B. LOGIC BOARD....................8 C. POWER SUPPLY BOARD ................8 5. INSTALLATION AND SETUP................9 A. INSTALLATION....................9 B. SETUP.........................9 6.
  • Page 4: Introduction

    1. INTRODUCTION The length of time that the lock remains released after entry of the valid PIN is adjustable from 3 to 60 seconds. An invalid PIN penalty feature provides for ignoring all keypad entries for from 3 to 60 seconds after an invalid digit is entered.
  • Page 5 Available settings: Number of PIN digits (3, 4 or 5) PIN number Open duration (3 to 60 sec.) Penalty duration (3 to 60 sec.) Output (12 or 24 Vdc) Versatile outputs: Limit holding current to 300mA Fail safe or fail secure 12 or 24Vdc @ 2A continuous High-rush current opens largest locks Holding current can be limited to 300mA...
  • Page 6: Specifications

    2. SPECIFICATIONS Power required 115/230 Vac, 50 or 60 Hz, 60 W Output 12Vdc, 0.8A or 24 Vdc, 2A continuous Holding current Can be limited to 300mA (switch selectable) In-rush current capacity Relay contacts 10A, SPDT (Form C) Battery backup 12Vdc or 24Vdc, automatic transfer and charging (batteries optional) Warning lamp, beeper and output signal activate when...
  • Page 7: Supplied Equipment

    3. SUPPLIED EQUIPMENT The table below lists all of the items that The CC-8521AN consists of two main units, the Keypad and the Control Unit comprise the Model CC- 8521AN Crypto- Lock along with a brief description of each and various accessories and mounting hardware to facilitate installation.
  • Page 8: Functions Of Controls And Indicators

    4. FUNCTIONS OF CONTROLS AND INDICATORS A. KEYPAD C. POWER SUPPLY BOARD Keys 1 through 0 are used to enter the OUTPUT VOLTAGE SOURCE (INT PIN code. Keys * and # are not used. 24V, EXT, or INT 12V) - Selects the Green LED indicator - Illuminates when voltage that will operate the locking the correct PIN code has been entered...
  • Page 9: Installation And Setup

    5. INSTALLATION AND SETUP 6) Connect the electric lock, strike or Installation of the CC-8551AN Crypto magnet as shown in Figure 3. Lock consists of mounting the Keypad and Control Unit, connecting the Keypad cable, 7) May connect a Release Button power cord, external lock and other (not supplied), and external 12VDC devices and installing the batteries...
  • Page 10: Setup

    5) Set the DURATION control to the B. SETUP 1) Set the OUTPUT source switch in approximate desired open time. (Min.=3 sec., Max.=60 sec.) accordance with the voltage rating of the lock being used (12 or 24 Vdc). 6) Set the PENALTY control to the 2) Set the OUTPUT MODE switch to approximate desired PENALTY time LIMIT HOLDING CURRENT for use...
  • Page 11 LOGIC BOARD (P C B “ G 9844, 94V-01 ”) Low Battery W arnings -The “LOW BATT” indicator will light and a beep will sound every 15 seconds when the battery charge level is low. POWER SUPPLY BOARD (P C B R ev C ) 1 15 BR N GR N...
  • Page 12: Operating Procedure

    6. OPERATING PROCEDURE If one or more incorrect PIN code digits To operate the CC-8521AN, enter the valid 3, 4, or 5 digit PIN code on the are entered the system will enter a penalty mode and will not recognize any digits for keypad.
  • Page 13: Theory Of Operation

    Open Timer, U1:B. The output Refer to the Keypad Schematic Diagram of U1:B then remains high for a time period on moniteq.com. The Keypad contains a set by the DURATION potentiometer R19. This output is coupled to Relay Driver Q5...
  • Page 14 The annunciator control signal from the of K1. Capacitor C3 provides additional Logic Board enters through T1, pin 6 and "in-rush" current immediately after K1 is coupled directly to the external closes to assure activation of the solenoids annunciator through T2, pin 16. in larger, heavy-duty electric locks.
  • Page 16 One Year Limited Warranty MONITEQ, INC. products are warranted to be free from factory defects for a period of one year from the date of shipment. The repair or replacement of a defective part shall be at the option of the factory when the product is shipped prepaid and insured by the owner.
