- Page 1 TQMLS1028A Preliminary User's Manual TQMLS1028A UM 0001 06.05.2019...
-
Page 2: Table Of Contents
Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page i TABLE OF CONTENTS ABOUT THIS MANUAL ..................................1 Copyright and license expenses ..............................1 Registered trademarks ..................................1 Disclaimer ....................................... 1 Imprint ........................................1 Tips on safety ......................................2 Symbols and typographic conventions ............................ - Page 3 Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page ii TABLE OF CONTENTS (continued) MECHANICS ......................................18 Assembly ......................................18 Dimensions ......................................19 Images ........................................20 Connectors ......................................21 Adaptation to the environment ..............................22 Protection against external effects.............................. 22 Thermal management ..................................
- Page 4 Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page iii TABLE DIRECTORY Table 1: Terms and Conventions ................................2 Table 2: LS1028A variants ..................................7 Table 3: Reset- and Status signals on the TQMLS1028A ........................7 Table 4: RCW_SRC_SEL ....................................
-
Page 5: About This Manual
Preliminary User's Manual, or due to usage of erroneous or incomplete information, are exempted, as long as there is no proven intentional or negligent fault of TQ-Systems GmbH. TQ-Systems GmbH explicitly reserves the rights to change or add to the contents of this Preliminary User's Manual or parts of it without special notification. -
Page 6: Tips On Safety
Violation of this guideline may result in damage / destruction of the TQMLS1028A and be dangerous to your health. -
Page 7: Naming Of Signals
The information provided in this Preliminary User's Manual is only valid in connection with the tailored boot loader, which is preinstalled on the TQMLS1028A, and the BSP provided by TQ-Systems GmbH. See also chapter 6. The TQMLS1028A is a universal Minimodule based on the NXP Layerscape CPUs LS1028A / LS1018A / LS1027A / LS1017A. ®... -
Page 8: Overview
• Two connectors (240 pins) All essential CPU pins are routed to the TQMLS1028A connectors. There are therefore no restrictions for customers using the TQMLS1028A with respect to an integrated customised design. All TQMLS1028A versions are fully pin-compatible and therefore interchangeable. -
Page 9: Electronics
Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page 5 ELECTRONICS LS1028A CPU 4.1.1 LS1028A variants, block diagrams Illustration 2: Block diagram LS1028A (Source: NXP) Illustration 3: Block diagram LS1018A (Source: NXP) -
Page 10: Illustration 4: Block Diagram Ls1027A
Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page 6 4.1.1 LS1028A variants, block diagrams (continued) Illustration 4: Block diagram LS1027A (Source: NXP) Illustration 5: Block diagram LS1017A (Source: NXP) -
Page 11: Ls1028A Variants, Details
Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page 7 4.1.2 LS1028A variants, details The following table shows the features provided by the different variants. Fields with a red background indicate differences; fields with a green background indicate compatibility. -
Page 12: Self-Reset
The output HRESET_REQ# is driven internally by the CPU and can be set by software in register RSTCR (bit 30). RESET_REQ# is returned to RESIN# within the TQMLS1028A (default). No additional feedback is necessary on the carrier board. When RESET_REQ# is triggered a self-reset is executed. -
Page 13: Cpu Configuration
Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page 9 CPU Configuration 4.3.1 RCW Source The RCW source selection is managed by the system controller. Table 4: RCW_SRC_SEL Level Reset Configuration Source Required external pull-down (Module pull-up is 10 kΩ to 3.3 V) 80 –... -
Page 14: Reset Configuration Word
This state can only be exited with a PORESET_B or Hard Reset." System Controller The TQMLS1028A uses a system controller for housekeeping and initialization functions. This system controller also performs power sequencing and voltage monitoring. The functions are in detail: •... -
Page 15: System Clock
Block diagram eMMC interface The eMMC is connected to SDHC2. The maximum transfer rate corresponds to the HS400 mode (eMMC from 5.0). SDRAM DDR4 SDRAM is used on the TQMLS1028A. Expansion stages with 1, 2, 4 or 8 GB are possible. -
Page 16: Eeprom
Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page 12 EEPROM 4.8.1 Data EEPROM 24LC256T The EEPROM is empty on delivery. • 256 Kbit or not assembled • 3 decoded address lines • Connected to I C controller 1 of the CPU •... -
Page 17: Rtc
The accuracy of the RTC is primarily determined by the characteristics of the quartz used. The type FC-135 used on the TQMLS1028A has a standard frequency tolerance of ±20 ppm at +25 °C. (Parabolic coefficient: max. –0.04 × 10 –6 / °C... -
Page 18: Power Consumption
4.12.2 Power consumption TQMLS1028A The given current consumptions have to be seen as typical values. The power consumption of the TQMLS1028A strongly depends on the application, the mode of operation and the operating system. The following table shows details of the TQMLS1028A supply and power consumption. -
Page 19: Interfaces To Other Systems And Devices
C buses of the LS1028A CPU (I2C1 to I2C6) are not terminated and routed to the TQMLS1028A connectors. The I2C1 bus is level shifted to 3.3 V and terminated with 4.7 kΩ pull-ups to 3.3 V on the TQMLS1028A. The I C devices on the TQMLS1028A are connected to the level-shifted I2C1 bus. -
Page 20: Pinout Tqmls1028A
Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page 16 4.15.2 Pinout TQMLS1028A Table 10: Pinout connector X1 Ball Level Group Signal Signal Group Level Ball Power Power Power Power Power Power Power Power Power Power... -
Page 21: Table 11: Pinout Connector X2
Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page 17 4.15.2 Pinout TQMLS1028A (continued) Table 11: Pinout connector X2 Ball Level Group Signal Signal Group Level Ball 3.3 V System SWD_IO TEMP_ALERT# System 3.3 V (OC) 3.3 V... -
Page 22: Mechanics
Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page 18 MECHANICS Assembly Illustration 11: TQMLS1028A assembly, top Illustration 12: TQMLS1028A assembly, bottom The labels on the TQMLS1028A show the following information: Table 12: Labels on TQMLS1028A... -
Page 23: Dimensions
Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page 19 Dimensions Illustration 13: TQMLS1028A dimensions, side view Illustration 14: TQMLS1028A dimensions, top view through TQMLS1028A... -
Page 24: Images
Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page 20 Images Illustration 15: TQMLS1028A, 3D, top view Illustration 16: TQMLS1028A, 3D, bottom view A 3D model is available in SolidWorks, STEP and 3D PDF formats. Please contact Support@tq-group.com. -
Page 25: Connectors
The TQMLS1028A is held in the mating connectors with a retention force of approximately 24 N. To avoid damaging the TQMLS1028A connectors as well as the carrier board connectors while removing the TQMLS1028A the use of the extraction tool MOZI8XX is strongly recommended. See chapter 5.9 for further information. -
Page 26: Adaptation To The Environment
TQMLS1028A and thus malfunction, deterioration or destruction. Structural requirements The TQMLS1028A is held in the mating connectors by the retention force of the pins (240). If high requirements are set for vibration and shock resistance, additional fastening may be necessary. -
Page 27: Safety Requirements And Protective Regulations
Filtering of all signals, which can be connected externally (also "slow signals" and DC can radiate RF indirectly). Since the TQMLS1028A is plugged on an application-specific carrier board, EMC or ESD tests only make sense for the whole device. In order to avoid interspersion on the signal path from the input to the protection circuit in the system, the protection against electrostatic discharge should be arranged directly at the inputs of a system. -
Page 28: Environment Protection
By environmentally friendly processes, production equipment and products, we contribute to the protection of our environment. To be able to reuse the TQMLS1028A, it is produced in such a way (a modular construction) that it can be easily repaired and disassembled. The energy consumption of this subassembly is minimised by suitable measures. The TQMLS1028A is delivered in reusable packaging. -
Page 29: Appendix
Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page 25 APPENDIX Acronyms and definitions The following acronyms and abbreviations are used in this document: Table 16: Acronyms Acronym Meaning Acronym Meaning ® Advanced RISC Machine Ball Grid Array... - Page 30 Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page 26 Acronyms and definitions (continued) Table 16: Acronyms (continued) Acronym Meaning Pre-Boot Loader Printed Circuit Board Peripheral Component Interconnect PCIe Peripheral Component Interconnect express PCMCIA People Can't Memorize Computer Industry Acronyms...
-
Page 31: References
Preliminary User's Manual l TQMLS1028A UM 0001 l © 2019, TQ-Systems GmbH Page 27 References Table 17: Further applicable documents No.: Name Rev., Date Company LS1028A / LS1018A Data Sheet Rev. C, 06/2018 LS1027A / LS1017A Data Sheet Rev. C, 06/2018 LS1028A Reference Manual Rev. - Page 32 TQ-Systems GmbH Mühlstraße 2 l Gut Delling l 82229 Seefeld Info@TQ-Group TQ-Group...
