Bausch Datacom DinBox Reference Manual page 15

• Opto Coupler Input
Input : 5 to 15 V (4 ... 14 mA)
Other input specifications are optional possible.
+ 2/4
- 1/3
• Relais Contact Output
Normal open contact (default)
Normal closed contact (optional)
Load
Rated load
Max. operation voltage
Max. operation current
1/3
2/4
Bausch Datacom NV
DinBox GSM/GPRS Reference manual – V1.0
1 K
BAS16
Res. load (p.f. = 1) / Induct. load (p.f. = 0.4, L/R = 7 ms
0.5 A at 125 Vac, 1 A at 24 Vdc
125 Vac, 60 Vdc
1 A
0 E
NO
-
NC
15
Vcc
To processor
SFH6156-2
From processor
