- Page 1 DIPLOMAT DENTAL s.r.o. Vrbovská cesta 17 921 01 Piešťany SLOVAKIA User Manual System of Automatic Hygiene For dental units Comfort Line DA270,DA280,DC310,DL210 model 2015 Premium Line DA370,DA380,DC350,DL320 model 2015...
-
Page 2: Table Of Contents
Automatic Hygiene DC310,DL210,DC350,DL320,DA270,DA280,DA370,DA380 model 2015 Table of Contents 1 Purpose and use of the hygiene ....................3 2 Control of hygiene from the touch screen ................5 3 Fillings shortage indication ...................... 6 Fillings shortage indication before starting ................6 Fillings shortage indication during hygiene ................. -
Page 3: Purpose And Use Of The Hygiene
Automatic Hygiene DC310,DL210,DC350,DL320,DA270,DA280,DA370,DA380 model 2015 1 Purpose and use of the hygiene Hygiene = Disinfection + Decontamination Disinfection ▪ of the waterlines of the instruments and ▪ of the cup filler is made in order to eliminate and/or reduce the biofilms formed by microcolonies of bacteria, fungi and protozoa on the internal surface of waterlines of the dental unit. -
Page 4: Automatic Hygiene Dc310,Dl210,Dc350,Dl320,Da270,Da280,Da370,Da380 Model
Automatic Hygiene DC310,DL210,DC350,DL320,DA270,DA280,DA370,DA380 model 2015 Fig. 1 Containers of the solutions of ALPRON and GREEN & CLEAN M2 Fig. 2 Selector switch of the water source in the position „0“ (located in the spittoon block) 4 / 12 UM_EN_AUTOMATIC_HYGIENE_m2015_2017-01_ver1.1... -
Page 5: Control Of Hygiene From The Touch Screen
Automatic Hygiene DC310,DL210,DC350,DL320,DA270,DA280,DA370,DA380 model 2015 2 Control of hygiene from the touch screen To get access to HYGIENE mode, press the button HYGIENE in SETTINGS screen. The hygiene screen is displayed: Screen symbols explained: Turning the continuous decontamination for the small aspirator On/Off Turning the continuous decontamination for the big aspirator On/Off Starting the decontamination of the spittoon bowl Starting the targeted decontamination for the big and small aspirator... -
Page 6: Fillings Shortage Indication
Automatic Hygiene DC310,DL210,DC350,DL320,DA270,DA280,DA370,DA380 model 2015 3 Fillings shortage indication Fillings shortage indication before starting In the event of the shortage of a filling before the hygiene is started (water, disinfecting solution, decontamination solution) the following screen with alarm is displayed briefly and an audible signal sounds. 12.09.2015 12:12 >... -
Page 7: Fillings Shortage Indication During Hygiene
Automatic Hygiene DC310,DL210,DC350,DL320,DA270,DA280,DA370,DA380 model 2015 Fillings shortage indication during hygiene If the filling being used is spent during the hygiene operation, information is displayed in the respective button by means of flashing symbol of a bottle in orange field and by means of interrupted acoustic indication. -
Page 8: Activation Of Hygiene
Automatic Hygiene DC310,DL210,DC350,DL320,DA270,DA280,DA370,DA380 model 2015 Activation of Hygiene Hygiene can be activated by means of the buttons of the touch screen of the dentist table. Decontamination of the spittoon bowl Press the button This will start the flushing of the spittoon bowl with water with admixed decontamination solution for 10 seconds. -
Page 9: Disinfection Of The Cooling Waterlines Of The Instruments
Automatic Hygiene DC310,DL210,DC350,DL320,DA270,DA280,DA370,DA380 model 2015 Disinfection of the cooling waterlines of the instruments Insert the funnel (Figure a) into the container(Pic. 3a). Fit the container prepared in described way over the spittoon bowl (Pic. 3b). Take out all instruments for the disinfection of the cooling waterlines. The instruments should be taken off the hoses and the hoses should be inserted into the beds in the container on the spittoon bowl(Pic. - Page 10 Automatic Hygiene DC310,DL210,DC350,DL320,DA270,DA280,DA370,DA380 model 2015 Till the end of the process, you cannot change instrument positions, otherwise the process will be interrupted. The change of the instrument is indicated by the red square and error message: END - INTERRUPT POSITION INTERRUPT You can continue from this point only when the instruments will be returned back on its positions as indicated by red squares.
-
Page 11: Disinfection Of The Syringe Waterlines
Automatic Hygiene DC310,DL210,DC350,DL320,DA270,DA280,DA370,DA380 model 2015 When all selected instruments have been rinsed, you are notified to manually rinse the syringes. Rinse the syringes and press the button on the screen: FLUSHING POSITION 0 sec SYRINGE !!! The disinfection process ends with message: POSITION After the instruments have been returned into the holders in the dentist table the whole process is completed. -
Page 12: Setting Of The Exposure Time Of The Solution For The Disinfection
Automatic Hygiene DC310,DL210,DC350,DL320,DA270,DA280,DA370,DA380 model 2015 Setting of the exposure time of the solution for the disinfection By pressing button you enter to the editing mode of solution exposure time. Buttons + / - serve to set up the required time in the range from 1 to 240 minutes. Repeated pressing of the button saves the time to memory.
