- Page 1 DIPLOMAT DENTAL s.r.o. Vrbovská cesta 17 921 01 Piešťany SLOVAKIA INSTALLATION MANUAL For dental units Comfort Line DA270,DA280 model 2015) Premium Line DA370,DA380 model 2015)
-
Page 2: Table Of Contents
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Table of Contents 01. Media availability ......................3 02. Uncover and unpack containers ..................4 03. Prepare place for the unit ....................6 3.1 Fixing the unit to the floor (no Base Plate is used) ..............6 3.2 Fixing the unit to the base plate (with adjustable balancing without drilling) ...... -
Page 3: Media Availability
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 01. Media availability Before starting to unpack, the service technician has to ensure: That place for the chair or unit is appropriately prepared according to Drill Plan. That all required media are available That all local, national and international requirements are in compliance. Namely we talk about availability of these basic media inputs/outputs: Drain pipe: PVC tube Ø... -
Page 4: Uncover And Unpack Containers
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 02. Uncover and unpack containers The stomatological set is packed in two containers. Take away the base plate (if ordered) and remove box cover plates and all the 4 side plates in the following order: Stomatological Unit container Chair container Take out all parts from unit box. - Page 5 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Releasing the unit Unit is fixed to the pallet with 2 different screws. This screw is fixed directly to the wooden pallet. Just unscrew it. This screw is fixed using the nut at the bottom side of the pallet. 5 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
-
Page 6: Prepare Place For The Unit
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 03. Prepare place for the unit Before moving the unit, prepare its place, depending on your variant: 3.1 Fixing the unit to the floor (no Base Plate is used) If the floor is from solid material and circumstances allow drilling to the floor, then Drill 4 holes and fix the unit to the floor at these 4 points. -
Page 7: Fixing The Unit To The Base Plate (With Adjustable Balancing Without Drilling)
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 3.2 Fixing the unit to the base plate (with adjustable balancing without drilling) Important - Microscope integration !!! If you are preparing base plate for microscope integration then the first step is to lead the cabling through the column and then fixing the base plate with the column. -
Page 8: Move The Unit
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 04. Move the unit Move the unit from the pallet to base plate using transport belts which are available on both sides of the unit. 8 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4... - Page 9 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Removing unit doors and left pane cover To remove doors follow these steps: 1: Disconnect grounding cable located at the bottom of the doors 2: Unscrew nut insuring the joint 3: Remove the doors by picking them up 9 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 10 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Disassembling left side panel You need to take out the panel as behind it, there are light and communication connectors 1: Disconnect grounding cable 2: Release winged nut at the bottom 3: Release winged nut on the upper side 4: Take out the panel 10 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 11 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Remove the transport belts and unscrew 4 temporal consoles. 11 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
-
Page 12: Prepare Chair To Move
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 05. Prepare chair to move Release the belt fixing chair accessory box to the pallet on both sides of the box. Take out the box. The chair is fixed to the pallet on both sides. Right side: Unscrew both screws and remove the console. - Page 13 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Left side: The chair is fixed to the holder with 2 screws (each on one side of the holder). 13 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 14 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Unscrew these 2 screws holding transport console with chair. Save 2 nuts for later use. Removing upholstery Front and back parts of backrest are connected together with 4 pins like illustrated below. Disjoin front part from the back part of the backrest Unscrew these 2 screws holding transport console with chair.
- Page 15 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 15 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 16 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Left handrest comes fixed from the factory. But if the chair with wide seat has been ordered, then you must unscrew it and fit there extending square (see below). If the chair with wide seat has been ordered, then include extending square between the chair and handrest: 16 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
-
Page 17: Moving The Chair
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 06. Moving the chair Unit ready to fit the chair. Hold the chair as shown below and move it to the prepared unit 1: While holding the chair, put the communication and powering cable into the tunneled arm of the chair (third person required) 2: And at the same time move the chair closer to the unit and hook it as shown below 17 / 61... - Page 18 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Correctly positioned cable in the chair tunnel Correctly fitted 18 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 19 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Fix the chair on both sides with 8 screws Connect connectors to the chair as illustrated below. 19 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 20 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Connect and fix the grounding cable Fit and fix cover with 2 screws 20 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 21 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Fix the backrest to the chair. Use the 4 nuts which we saved before. 21 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 22 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Put in the front side of the backrest. Ensure the 4 pins fit into the 4 holes. 22 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 23 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Fit the headrest into the backrest Fix the right handrest holder with 4 screws. If chair with wide seat has been ordered, then install handrest this way (include extending square): 23 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 24 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Mount the seat to the correct position: fit the pins to the holes and tighten the nut under the seat. 24 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
-
Page 25: Dentist's Pantograph Installation
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 07. Dentist’s pantograph installation 1: Push in the bundle of cables. 2: Fit in the Control Panel pantograph. 25 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4... - Page 26 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Use highlighted screws to appropriately brake all the moving parts of the dentist’s pantograph. 26 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 27 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Setting of dentist’s pantograph endpoint. 27 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
-
Page 28: Light Arm And Pantograph Installation
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 08. Light Arm and pantograph installation Pantograph Adaptation for monitor Light Arm is divided (fixed and movable parts) and can be equipped with arm adaptation for monitor. Picture below illustrates fixing and braking points. Braking set is included in the unit accessories box. 28 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4... - Page 29 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 If Monitor arm is used, follow suggested steps. Do not forget to include highlighted esthetic circle in right moment (before fitting light arm into monitor adaptation). 29 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 30 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 1: Push in the light wires 2: Fit in the light arm. Fix firmly the arm to the spittoon block 30 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 31 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Installing brake of the rotating part of the light arm 1: Insert M10 screw into the hole and screw it in with allen key and adjust the braking power 2: Fit in the esthetic cover 31 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 32 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Installing back stop of the light arm pantograph. This end-point prevents from hitting arm with the pantograph each other. 1: Fix the end point insuring screw of the light pantograph 2: Put in the esthetic cover 32 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
-
Page 33: Air And Water Connections
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 09. Air and Water Connections Connect Pressed Air and Main Water to appropriate valves as shown below. 4 bar air connection: Plug blue tube coming from dentist’s panel side to blue tube from main air filter regulator (4 bar) The tubes are marked with 4 33 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4... - Page 34 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 2.5 bar air connection: Plug another blue tube coming from control panel to blue tube coming from 2,5 bar air pressure regulator. The tube is unmarked. 1: Plug thin green tube coming from control panel to distillated water bottle connection (2,5 bar water). 2: If unit is equipped with central water system, find free “T”...
- Page 35 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 If suction aggregate is present then connect both: 1: Drain hose to DRAIN PIPE (Drain hose is marked with green tape). 2: Suction hose to SUCTION PIPE. Use gaskets as outlined below. If suction is applied via saliva ejector only, then just connect the Drain hose to DRAIN PIPE Use rubber gasket as outlined below.
-
Page 36: Electrical Connections
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 10. Electrical Connections !!! Make sure electrical circuit breaker is turned off. If necessary, follow wiring diagrams attached with the unit. 10.1 Connection steps identical for both: BASIC and FULL Config Unscrew 3 screws fixing plastic cover of electronic modules. 36 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4... - Page 37 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 1: Connect 24V connector coming from dentist panel. 2: Connect communication RJ45 cable coming from dentist panel. Plug in the wires from suction unit to connector X6 marked on the picture below 37 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 38 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Fix the grounding wire coming from dentist’s control panel at the bottom of spittoon block. Connect equipotential cable with the base of the spittoon block. 38 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 39 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Connect main power supply 230 V 39 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
-
Page 40: Basic Configuration Connections (Based On Pb_Lux_8 Electronics)
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 10.2 Basic Configuration connections (based on PB_LUX_8 electronics) Connect XENOS lamp to PB_LUX_8 40 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4... - Page 41 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 On module PB_CAT_5 you can choose the control suction supply mode: 1: PASIVE (terminal T1, positions 1,2) or 2: ACTIVE 24V AC (terminal T1 , positions 3,4). Picture below illustrates ACTIVE connection. 41 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
-
Page 42: Full Configuration Connections (Based On Pb_Lux_11 Electronics)
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 10.3 Full Configuration connections (based on PB_LUX_11 electronics) 1: Connect XENOS lamp to PB_LUX_11 2: You can change mode for suction: Passive or Active Turn ON the circuit breaker 42 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4... -
Page 43: Assembling Coverings
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 11. Assembling coverings Assemble electronics cover. Fix cover of electronics block with 3 screws. 43 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4... - Page 44 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Assembling left side panel 1: Connect grounding cable 2: Fit bottom side 3: Fit upper side 4: Fix the panel 44 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 45 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Fitting the doors back to spittoon block 1: Connect grounding cable located at the bottom of the doors 2: Fit the doors back by fitting hinges into the holes as shown below 3: Screw the nut onto the hinge 45 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
-
Page 46: Assembling Accessories
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 12. Assembling accessories Install spittoon bowl, sieve and ceramic cover. Assemble cup filler on spittoon bowl. 46 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4... - Page 47 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Connect suction hoses of aspirators. Fit filters and tips to the aspirator hoses. 47 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 48 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Fit saliva ejector filter and tip to its hose. If whipped unit used, then put and fit the whip into base part. Fix the whip with worm screw. 48 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 49 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Adjust moving strength of the headrest with adjustment screw. Before testing of the unit you need to fill bottles with appropriate liquids. 49 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
- Page 50 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Put this cover onto unit base. 50 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
-
Page 51: Foot Controller
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 13. Foot controller 13.1 Cable connected foot controller Connect Foot controller cable to the Unit. 51 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4... -
Page 52: Wi-Fi Connected Foot Controller
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 13.2 Wi-Fi connected foot controller 13.2.1 Connecting battery (activating transmitter) Foot controllers are delivered with disconnected battery to prevent useless discharging. Connecting battery in foot controller UNO: Unscrew 4 screws located at the bottom of the controller Rechargeable battery is inside, just connect the connector as shown below: 52 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4... - Page 53 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Connecting battery in foot controller NOK: Unscrew 4 screws located at the bottom of the controller Rechargeable battery is inside, just connect the connector as shown below: 53 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
-
Page 54: Connecting Wifi Receiver
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 13.2.2 Connecting wifi receiver 1: Connect RF receiver to the socket. 2: When LED1 shines GREEN, then receiver has established communication with the foot controller. For more details and troubleshooting, refer to chapter K of Service Manual. Purposes of FC Cable: •... -
Page 55: Finalizing Of Installation
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 14. Finalizing of installation Turn the main switch ON and check functionality of the unit according to user manual. 14.1 Adjusting installed elements If necessary, you can balance tray table located under the dentist’s control panel 55 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4... - Page 56 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 If whips do not line up, check presence of silicone washers located inside of the control panel below each whip. 56 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
-
Page 57: Disinfection Of New Dental Unit Before Its First Use
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 14.2 Disinfection of new dental unit before its first use Before first use of the dental unit, it is necessary to disinfect all instruments and waterlines of all instruments. Please perform the following steps: Fully open valve(s) of instrument’s spraying water. Fill in the bottle for distilled water with disinfection solution SANOSIL SUPER 25 Ag (S003 Ag). -
Page 58: Specific And Optional Installations
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 15. Specific and Optional installations 15.1 Installation procedure of side tray table (V620.29-00-00.3) on units DA270 Before the installation, prepare the following items: If the touch screen display is located on the right side of control panel, the tray must be mounted on left side of control panel and vice-versa. - Page 59 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 Fit the individual elements onto the holder in following order: tray table holder sliding washer with back stop hole tray table with arm sliding washer washer stainless spring washer fixing circle (nut) 59 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
-
Page 60: Preparing Base Plate For Microscope Integration
INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 15.2 Preparing base plate for microscope integration Important remark !!! First step is to lead the cabling through the column and then fixing the base plate with the column Follow this procedure: Prepare necessary screws for column fixing and put the base plate on the floor 1 - Fit the column cover onto to the column as shown below as later it would be impossible 2 - Lead the cabling through the column (HDMI and Power cable) 60 / 61... - Page 61 INSTALLATION MANUAL DA270,DA280,DA370,DA380 model 2015 3 - Fix the column with the installation base plate 4 - Fit the column cover and cables cover on its places Then follow instructions in chapter 3.2 61 / 61 IM_EN_ DA270_DA280_DA370_DA380_m2015_2019-04_ver3.4...
