ATCA-7360
Installation and Use
P/N: 6806800J07S
May 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATCA-7360 and is the answer not in the manual?

Questions and answers

Related Manuals for Artesyn ATCA-7360

Summary of Contents for Artesyn ATCA-7360

  • Page 1 ATCA-7360 Installation and Use P/N: 6806800J07S May 2016...
  • Page 2 Artesyn reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Artesyn to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    3.2.2 Keys ............... . 71 ATCA-7360 Installation and Use (6806800J07S)
  • Page 4 Advanced -> Super IO Configuration ....... . . 106 ATCA-7360 Installation and Use (6806800J07S)
  • Page 5 4.12.4.7 Correctable Memory Log Disabled ........130 ATCA-7360 Installation and Use (6806800J07S)
  • Page 6 6.3.1 Register Decoding ............155 ATCA-7360 Installation and Use (6806800J07S)
  • Page 7 6.4.12.4 Telecom Status/Control Register ........196 ATCA-7360 Installation and Use (6806800J07S)
  • Page 8 System Boot Options Commands ........221 ATCA-7360 Installation and Use (6806800J07S)
  • Page 9 Artesyn Specific Commands ........
  • Page 10 Related Documentation ............. . 285 Artesyn Embedded Technologies - Embedded Computing Documentation ....285 Manufacturers’...
  • Page 11 Save & Exit ..............114 ATCA-7360 Installation and Use (6806800J07S)
  • Page 12 LPC I/O Register Map Overview ..........156 ATCA-7360 Installation and Use (6806800J07S)
  • Page 13 Version Register ............. . 182 ATCA-7360 Installation and Use (6806800J07S)
  • Page 14 Telecom CH1_CLK1B clock period MSB Register ........208 ATCA-7360 Installation and Use (6806800J07S)
  • Page 15 Set Serial Interface Properties Command ........242 ATCA-7360 Installation and Use (6806800J07S)
  • Page 16 Artesyn MAC Address Descriptor ........
  • Page 17 Interrupt Structure on ATCA-7360 ........
  • Page 18 Figure 6-2 IOH36D PCIe Port mapping on ATCA-7360 ....... . 154 Figure 7-1 SOL Overview .

  • Page 19: About This Manual

    Firmware Upgrade on page 275 provides information on how to upgrade the firmware  components. Replacing the Battery on page 281 provides the battery exchange procedures.  Related Documentation on page 285 provides links to further blade-related  documentation. ATCA-7360 Installation and Use (6806800J07S)
  • Page 20 Field Replaceable Unit Hard Disk Drive Integrated Device Electronics IPMB Intelligent Platform Management Bus IPMC Intelligent Platform Management Controller IPMI Intelligent Platform Management Interface Low Pin Count Media Access Control NEBS Network Equipment Building System ATCA-7360 Installation and Use (6806800J07S)
  • Page 21 Sensor Data Record SDRAM Synchronous Dynamic Random Access Memory SELV Safety Extra Low Voltages Serial Management Interface Serial-over-LAN Serial Presence Detect Serial Peripheral Interface SRAM Static Random Access Memory SROM Serial Read-Only Memory Video Graphics Array ATCA-7360 Installation and Use (6806800J07S)
  • Page 22 Repeated item for example node 1, node 2, ..., node Omission of information from example/command that is not necessary at the time being Ranges, for example: 0..4 means one of the integers 0,1,2,3, and 4 (used in registers) Logical OR ATCA-7360 Installation and Use (6806800J07S)
  • Page 23 Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury Indicates a property damage message No danger encountered. Pay attention to important information ATCA-7360 Installation and Use (6806800J07S)

  • Page 24: Table 6-7 Table

    264. Updated Power Requirements on page  6806800J07G August 2010 Updated Appendix A, Replacing the Battery. Added Chapter 10, Firmware Upgrade, on page 275. 6806800J07F January 2010 GA version 6806800J07E November 2009 Updated EA version ATCA-7360 Installation and Use (6806800J07S)

  • Page 25: Table

    "P32 Backplane Connector Pinout - Rows A to D" on page Figure "P32 Backplane Connector Pinout - Rows E to H" on page 86 6806800J07B June 2009 Updated Sensor Data Records on page 264 6806800J07A June 2009 First version ATCA-7360 Installation and Use (6806800J07S)
  • Page 26 About this Manual About this Manual ATCA-7360 Installation and Use (6806800J07S)

  • Page 27: Safety Notes

    The blade has been tested in a standard Artesyn system and found to comply with the limits for a Class A digital device in this system, pursuant to part 15 of the FCC Rules, EN 55022 Class A respectively.
  • Page 28 Damage of Blade and Additional Devices and Modules Incorrect installation of additional devices or modules may damage the blade or the additional devices or modules. Before installing or removing an additional device or module, read the respective documentation ATCA-7360 Installation and Use (6806800J07S)
  • Page 29 A and input line B so that line A remains powered even if it is disconnected from the power supply circuit (and vice versa). To avoid damage or injuries, always check that there is no more voltage on the line that has been disconnected before continuing your work. ATCA-7360 Installation and Use (6806800J07S)
  • Page 30 Therefore, always use the same type of Lithium battery as is installed and make sure the battery is installed as described in this manual. Environment Always dispose of used blades, system components and RTMs according to your country’s legislation and manufacturer’s instructions. ATCA-7360 Installation and Use (6806800J07S)

  • Page 31: Sicherheitshinweise

    Produkt mit vielfältigen Einsatzmöglichkeiten handelt, können wir die Vollständigkeit der im Handbuch enthaltenen Informationen nicht garantieren. Falls Sie weitere Informationen benötigen sollten, wenden Sie sich bitte an die für Sie zuständige Geschäftsstelle von Artesyn. Das System erfüllt die für die Industrie geforderten Sicherheitsvorschriften und darf ausschließlich für Anwendungen in der Telekommunikationsindustrie und im Zusammenhang...
  • Page 32 Sicherheitshinweise Das Blade wurde in einem Artesyn Standardsystem getestet. Es erfüllt die für digitale Geräte der Klasse A gültigen Grenzwerte in einem solchen System gemäß den FCC-Richtlinien Abschnitt 15 bzw. EN 55022 Klasse A. Diese Grenzwerte sollen einen angemessenen Schutz vor Störstrahlung beim Betrieb des Blades in Gewerbe- sowie Industriegebieten...
  • Page 33 Bevor Sie das Blade betreiben, müssen Sie sicher stellen, dass das Shelf über eine Zwangskühlung verfügt. Wenn Sie das Blade in Gebieten mit starker elektromagnetischer Strahlung betreiben, stellen Sie sicher, dass das Blade mit dem System verschraubt ist und das System durch ein Gehäuse abgeschirmt wird. ATCA-7360 Installation and Use (6806800J07S)
  • Page 34 Batterie Beschädigung des Blades Ein unsachgemäßer Einbau der Batterie kann gefährliche Explosionen und Beschädigungen des Blades zur Folge haben. Verwenden Sie deshalb nur den Batterietyp, der auch bereits eingesetzt wurde und befolgen Sie die Installationsanleitung. ATCA-7360 Installation and Use (6806800J07S)
  • Page 35 Sicherheitshinweise Umweltschutz Entsorgen Sie alte Batterien und/oder Blades/Systemkomponenten/RTMs stets gemäß der in Ihrem Land gültigen Gesetzgebung und den Empfehlungen des Herstellers. ATCA-7360 Installation and Use (6806800J07S)
  • Page 36 Sicherheitshinweise ATCA-7360 Installation and Use (6806800J07S)

  • Page 37: Introduction

    Chapter 1 Introduction Features The ATCA-7360 is a high-performance ATCA compliant single board computer designed for demanding storage and processing applications. The following is the list of main features: Dual socket Intel Xeon5500 Series CPU  Standard configuration ATCA-7360: Intel Xeon 5500 L5518 60W 2.13GHz...

  • Page 38: Standard Compliances

    Standard Description UL 60950-1 Legal safety requirements EN 60950-1 IEC 60950-1 CAN/CSA C22.2 No 60950-1 CISPR 22 EMC requirements on system level (predefined Artesyn system) CISPR 24 EN 55022 EN 55024 FCC Part 15 EN 300386 NEBS Standard GR-1089 CORE...

  • Page 39: Mechanical Data

    The following table provides details about the blade's mechanical data, such as dimensions and weight. Table 1-2 Mechanical Data Feature Value Dimensions (width x height x depth) 30 mm x 351 mm x 312 mm 8U form factor Weight of blade 3.8 kg ATCA-7360 Installation and Use (6806800J07S)

  • Page 40: Ordering Information

    Ordering Information The following table lists the blade variants that were available as of the time of writing this manual. Consult your local Artesyn sales representative for the availability of further variants. Table 1-3 Blade Variants - Ordering Information Product Name...
  • Page 41 RJ45-DSUB-ATCA7140 RJ-45 DSUB cable for the ATCA-7140, 7150, 7350, 736X SA-BBS-WR30-7360 CD - BBS SW and WR PNE3.0 for ATCA-7360 1. HDD kit option for RTM-ATCA-7360 and RTM-ATCA-7360-L 2. Persistent memory and solid state disk mutually exclusive ATCA-7360 Installation and Use (6806800J07S)

  • Page 42: Product Identification

    Introduction Product Identification The following figure illustrates the location of the serial number label. Figure 1-1 Serial Number Location ATCA-7360 Installation and Use (6806800J07S)
  • Page 43 Introduction ATCA-7360 Installation and Use (6806800J07S)
  • Page 44 Introduction ATCA-7360 Installation and Use (6806800J07S)

  • Page 45: Installation

    3. Remove the desiccant bag shipped together with the blade and dispose of it according to your country’s legislation. The blade is thoroughly inspected before shipment. If any damage occurred during transportation or any items are missing, please contact our customer service immediately. ATCA-7360 Installation and Use (6806800J07S)

  • Page 46: Environmental And Power Requirements

    Blade Overheating and Blade Damage Operating the blade without forced air cooling may lead to blade overheating and thus blade damage. When operating the blade, make sure that forced air cooling is available in the shelf. ATCA-7360 Installation and Use (6806800J07S)

  • Page 47: Table 2-1 Environmental Requirements

    Random 20-200Hz at 3 m Shock Half-sine, 11 ms, 30 m/s Blade level packaging Half-sine, 6 ms at 180 m/s Free Fall 1.2 m/ packaged (according to ETSI 300 019-2-2) 100 mm unpackaged (according to Telcordia GR-63-core) ATCA-7360 Installation and Use (6806800J07S)

  • Page 48: Table 2-2 Critical Temperature Limits

    =110°C (case) cmax Intel 82572EI 2.1 W (typ. 1.5W) =97°C (case) cmax Payload DCDC 48 V/12 V 10 W DDR3 DIMM Modules 6.9 W (estimate TS 85° C team) CPU VCC controller (up to 100 A) ATCA-7360 Installation and Use (6806800J07S)

  • Page 49: Figure 2-1 Location Of Critical Temperature Spots (Blade Top Side)

    Temperature Test Point #1 (on DC/DC Converter Module): Max. 100°C (Exact location: In the geometric middle of the heat spreader). Temperature Test Point #2 (on Power Input Module): Max. 90°C (Exact location: On top of the transformer). Temperature Test Point #3 (on Hold-Up Capacitor): Max. 105°C ATCA-7360 Installation and Use (6806800J07S)

  • Page 50: Power Requirements

    Operating Voltage -39 VDC to -72 VDC Exception in the US and Canada -39 VDC to -60 VDC Maximum power consumption of ATCA-7360 (with 260 W RTM-ATCA-7360 including a SAS HDD) (200 W typical) Maximum power consumption of ATCA-7360 (without...
  • Page 51 There is also a dependency on the batch variance of the major components like the processor and DIMMs used. Artesyn does not represent or warrant that measurement results of a specific board provide guaranteed maximum values for a series of boards.

  • Page 52: Blade Layout

    Installation Blade Layout The following figure illustrates the location of components on the ATCA-7360: Figure 2-2 ATCA-7360 Blade Layout ATCA-7360 Installation and Use (6806800J07S)

  • Page 53: Switch Settings

    Switch Settings The blade provides the configuration switches SW1, SW2, SW3, and SW4. Their location is shown in Figure "ATCA-7360 Blade Layout" on page Blade Malfunction Switches marked as 'Reserved' might carry production-related functions and may cause the blade to malfunction if their setting is changed.

  • Page 54: Table 2-4 Switch Settings

    OFF: IPMI selects boot flash (default) ON: SW3-2 selects Boot Flash SW3-2 SW3-2 controls boot flash selection if SW3-1 is set to ON OFF: Boot from “Default Boot Flash” device (default) ON: Boot from “Recovery Boot Flash” device ATCA-7360 Installation and Use (6806800J07S)

  • Page 55: Installing Blade Accessories

    PMEM (persistent memory) module  SATA module  USB flash module  Rear transition modules  They are described in detail in the following sections. For order numbers refer to section Ordering Information on page ATCA-7360 Installation and Use (6806800J07S)

  • Page 56: Dimm Memory Modules

    ESD-safe environment. Installation Procedure To install a DIMM module, proceed as follows: 1. Remove the blade from system as described in Installing and Removing the Blade on page 2. Open the locks of memory module socket. ATCA-7360 Installation and Use (6806800J07S)

  • Page 57: Pmem And Sata Module

    The PMEM/SATA extension slot allows assembly of either a PMEM or SATA module which are available as upgrade kits for ATCA-7360. PMEM module consists of an SRAM and a flash memory. The SRAM has a capacity of up to 16 MB and can be used as persistent memory, that means a memory that holds up the contents during reset.
  • Page 58 S/F memory module connector is shown Figure 2-2 on page The PMEM and SATA module are accessory kits and are not part of the default ATCA-7360. The following procedure describes the steps to install/remove the PMEM/SATA module.

  • Page 59: Usb 2.0 Flash Module

    Installing and Removing the Blade on page 2.5.3 USB 2.0 Flash Module The blades provides a USB 2.0 flash module with a capacity of 4 GB or 16 GB. The corresponding removal/installation procedures are described in this section. ATCA-7360 Installation and Use (6806800J07S)

  • Page 60: Installing And Removing The Blade

    Installation The location of the USB 2.0 Flash Module is shown in Figure "ATCA-7360 Blade Layout" on page Damage of Circuits Electrostatic discharge and incorrect module installation and removal can damage circuits or shorten their life. Before touching the module or electronic components, make sure that you are working in an ESD-safe environment.

  • Page 61: Installing The Blade

    Incorrect blade installation and removal can result in blade malfunctioning. When plugging the blade in or removing it, do not press on the faceplate but use the handles. 2.6.1 Installing the Blade To install the blade into an AdvancedTCA shelf, proceed as follows. ATCA-7360 Installation and Use (6806800J07S)
  • Page 62 3. Apply equal and steady pressure to carefully slide the blade into the shelf until you feel resistance. Continue to gently push the blade until the blade connectors engage. 4. Squeeze the lever and the latch together and hook the lower and the upper handle into the shelf rail recesses. ATCA-7360 Installation and Use (6806800J07S)
  • Page 63 When the blue LED is switched OFF and the green LED (IS) is switched ON, this indicates that the payload has been powered up and the blade is active. 7. Connect cables to the faceplate, if applicable. ATCA-7360 Installation and Use (6806800J07S)

  • Page 64: Removing The Blade

    2. Wait until the blue LED is illuminated permanently, then unlatch the upper handle and rotate both handles fully outward. If the LED continues to blink, a possible reason may be that the upper layer software rejected the blade extraction request. ATCA-7360 Installation and Use (6806800J07S)
  • Page 65 Wait until the blue LED is permanently illuminated, before removing the blade. 3. Remove faceplate cables, if applicable. 4. Unfasten the screws of the faceplate until the blade is detached from the shelf. 5. Remove the blade from the shelf. ATCA-7360 Installation and Use (6806800J07S)
