Artesyn iVPX7225 RTM Installation And Use Manual

Hide thumbs Also See for iVPX7225 RTM:
Table of Contents

Advertisement

Quick Links

Download this manual
iVPX7225 RTM
Installation and Use
P/N: 6806800S35B
April 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iVPX7225 RTM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Artesyn iVPX7225 RTM

Summary of Contents for Artesyn iVPX7225 RTM

  • Page 1 RTM Installation and Use P/N: 6806800S35B April 2015...
  • Page 2 Artesyn reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Artesyn to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    3.5.2 J1 - USB1Front Panel Type -A Receptacle ........38 iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 4 Related Documentation ............. . . 53 Artesyn Embedded Technologies - Embedded Computing Documentation ....53 Related Specifications .
  • Page 5 RTM Block Diagram ........
  • Page 6 List of Figures iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 7 COM0 (J7)/COM1 (P701) RS232/422/485 Functions ....... . 50 Table A-1 Artesyn Embedded Technologies - Embedded Computing Publications ....53 Table A-2 Specifications .
  • Page 8 List of Tables iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 9: About This Manual

    This document uses the following abbreviations: Abbreviation Description Indication for LOW active signals Two-Level Maintenance BIOS Basic Input/Output System Bill of Material Cubic Feet per Minute Serial V.24 / V.28 compliant interface Cathode Ray Tube Double Data Rate iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 10 Gigabits per second Gen1 PCI Express Generation 1 supporting 2.5 GT/s Gen2 PCI Express Generation 2 supporting 5.0 GT/s Gigahertz GPIO General Purpose Input/Output GT/s Gigatransfers per second High Definition HDMI High-Definition Multimedia Interface iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 11 Megabits per second Management Engine Megahertz Not Applicable NAND Not AND NEBS Network Equipment Building System Non-maskable Interrupt NVRAM Non-volatile Random Access Memory Original Equipment Manufacturer Printed Circuit Board Platform Controller Hub PCIE PCI-Express iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 12 Serial Presence Detect Serial Peripheral Interface To be defined Thermal Design Power Trusted Platform Module Transmit line (of a duplex serial communication interface) UART Universal Asynchronous Receiver-Transmitter Voltage Identification (for Intel CPUs) Vendor Product Data iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 13 Notation for selecting a submenu <text> Notation for variables and keys [text] Notation for software buttons to click on the screen and parameter description Repeated item for example node 1, node 2, ..., node iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 14 No danger encountered. Pay attention to important information Summary of Changes This manual has been revised and replaces all prior editions. Part Number Publication Date Description 6806800S35A October 2013 Initial version 6806800S35B April 2015 Rebranded to Artesyn iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 15: Safety Notes

    Artesyn Embedded Technologies and our suppliers take significant steps to make sure that there are no bent pins on the backplane or connector damage to the boards prior to leaving the factory.
  • Page 16 Keep any fresh air intakes of the system enclosure completely clear. Ensure that any fresh air supply is not mixed with hot exhaust from other devices. Ensure that all system slots are populated with either blades, filler blades, or dummy blades. iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 17 Use the handle and face plate when removing the product from the enclosure. Hot Swap Product Damage Installing or removing the product while power is applied damages the product. Power off the rack before installing or removing the product. iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 18 Safety Notes iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 19: Sicherheitshinweise

    Installieren Sie keine Ersatzteile oder führen Sie keine unerlaubten Veränderungen am System durch, sonst verfällt die Garantie. Wenden Sie sich für Wartung oder Reparatur bitte an die für Sie zuständige Geschäftsstelle von Artesyn Embedded Technologies. So stellen Sie sicher, dass alle sicherheitsrelevanten Aspekte beachtet werden.
  • Page 20 Produktionsstätte in einwandfreiem Zustand befinden. Verbogene Pins, verursacht durch fehlerhafte Installation oder durch Installation von Boards mit beschädigten Steckern kann die durch Artesyn Embedded Technologies gewährte Garantie für Boards und Backplanes erlöschen lassen. Gehen Sie mit äußerster Vorsicht vor, bei der Handhabung, Prüfung und Einstellung dieser Anlagen und deren Komponenten bezueglich gefährliche Spannungen, die zu Verletzungen...
  • Page 21 Um Verletzungen durch Verbrennung zu vermeiden, berühren Sie während der Arbeit keine Komponenten oder Kühlkörper auf dem Produkt. Fassen Sie das Produkt an den Handles und der Frontblende an, wenn Sie es aus dem System herausnehmen. iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 22 Sicherheitshinweise Hot Swap Beschädigung des Produktes Wenn Sie das Produkt im laufenden Betrieb ein- oder ausbauen, kann es beschädigt werden. Schalten Sie das Rack aus, bevor Sie das Produkt ein- oder ausbauen. iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 23: Introduction

    Chapter 1 Introduction Features The iVPX7225 RTM provides access to the rear IO of the Artesyn 3U iVPX7225 module. The following physical ports and switch banks are available via the iVPX7225 RTM: Front Panel Access One e-SATA port (Gen3) ...

  • Page 24: Standard Compliances

    AS/NZS CISPR 22, Class A Mechanical Data The following table provides details about the dimensions and weight of the board. Table 1-2 Mechanical Data Feature Value Form-factor Per VITA 46.10 Weight 0.16Kg (0.35 lbs) iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 25: Ordering Information

    3U VPX, AIR COOLED, RTM FOR iVPX7225,.8” FACEPLATE iVPX7225-RTM-1 3U VPX, AIR COOLED, RTM FOR iVPX7225, 1” FACEPLATE Table 1-4 Accessories Order Number Description SERIAL-MINI-D (30-W2400E01A) Female-to-Male Micro-Mini DB9 to DB9 adapter cable (~12 inches) iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 26: Product Identification

    Introduction Product Identification The following graphic shows the location of the iVPX7225 RTM serial number label. Figure 1-1 Serial Number Label Location iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 27: Hardware Preparation And Installation

    1. Verify that you have received all items of your shipment which includes the following but are not limited to; Printed Quick Start Guide and Safety Note  iVPX7225 RTM  Any optional items ordered  iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 28: Environmental And Power Requirements

    High humidity and condensation on the board surface causes short circuits.  Do not operate the board outside the specified environmental limits. Make sure the  board is completely dry and there is no moisture on any surface before applying power. iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 29: Power Requirements

    Gigabit Ethernet, 2-USB 2.0, DP, VGA, Keyboard and COM. All externally powered peripherals active. Maximum Power: Calculated worst-case power based upon device data sheets and is not expected to be reached under normal operation. All peripherals are presumed to be externally powered. iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 30: Installing The Rtm

    Hardware Preparation and Installation Installing the RTM The iVPX7225 RTM does not support hot swap. Remove power to the rear slot or system before installing the RTM. Product Damage Installing or removing the product while power is applied damages the product.
  • Page 31 9. Connect the appropriate cables to the transition module. To remove the transition module from the chassis, reverse the procedure and press the red locking tab to extract the board. iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 32 Hardware Preparation and Installation iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 33: Controls, Leds And Connectors

    The following graphic shows the location of the significant board components: Figure 3-1 RTM Connectors LAN2 Super Cap SATA2 LAN1 SATA0 Mini-DP XMC_IO WP_OR USB 0 IPMC Debug USB 2 R-Term eSATA COM 0 USB1 PCH GPIO COM 1 Reset Switch iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 34: Front Panel

    D1002 - LAN1 PHY up  D1102 - LAN2 PHY up  LAN1 Port - Integrated Steady Green LED (Link), Blinking Green LED (Activity)  LAN2 Port - Integrated Steady Green LED (Link), Blinking Green LED (Activity)  iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 35: Backplane Connectors

    3.3V VPX Power 5.0 VPX 5.0 VPX 5.0 VPX 5.0 VPX 5.0 VPX 5.0 VPX Single NVMRO Ended Single 3.3V AUX Ended Single Ended Differential Differential Differential Differential Differential VBAT Differential Differential Differential Differential Differential iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 36: Rp1 Connector

    VBAT input remains above 2V (at the iVPX7225 PCH RTC input). In the event that the system does not provide a voltage at VBAT, there is a diode protected 0.2F SuperCap (C214) onboard the iVPX7225 RTM to maintain operation for short down times.

  • Page 37: Rp2 Connector

    12D 7 N 12D 7 P 12D 8 N 12D 8 P Differential RTM RST L P2 XMC P2 XMC P2 XMC P2 XMC 12D 9 N 12D 9 P 12D 10 N 12D 10 P iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 38: Front Panel Connectors

    SATA P1 TX N Ground SATA P1 RX N SATA P1 RX P Ground 3.5.2 J1 - USB1Front Panel Type -A Receptacle Table 3-5 J1 – USB1 Front Panel Type-A Receptacle Pinout USB1 N USB1 P Ground iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 39: J7 - Com0 Rs232/422/485 Front Panel Port

    CRT BLUE Ground Red GND Green GND Blue GND Sync GND CRT DATA CRT HSYNC CRTVSYNC CRT CLK PCB Planar Access Ports The following sections detail the PCB Planar Access Ports available on the board: iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 40: J101 - Planar Dual-Ganged Gigabit Ethernet Port

    LAN 1 DD P LAN 1 DD N 3.6.2 J4 - SATA Port0 L -Shaped Internal Table 3-9 J4 – SATA Port0 L-Shaped Internal Pinout CAD P0 N SATA P0 TX P SATA P0 TX N Ground iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 41: J5 - Sata Port2 L-Shaped Internal

    J3 - USB0 Mini-B Receptacle Table 3-11 J3 – USB0 Mini-B Receptacle Pinout USB0 N USB0 P Ground 3.6.5 J2 - USB2 Mini-B Receptacle Table 3-12 J2 – USB2 Mini-B Receptacle Pinout USB2 N USB2 P Ground iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 42: P701 - Com1 Rs232/422/485 Header

    10 MegOhm Pull Down Ground Ground DPD D1 P DPD D3 P DPD D1 N DPD D3 N Ground Ground DPD D2 P DPD AUX P DPD D2 N DPD AUX N Ground +3.3V iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 43: J1201 - Ipmc Debug Mini-B Usb Physical Receptacle

    3.6.10 J1101 - P2 XMC J16 Differential I/O Table 3-17 J1101 - P2 XMC J16 Differential I/O Pinout Ground Ground P2 XMC 12D 1 N P2 XMC 12D 7 N P2 XMC 12D 1 P P2 XMC 12D 7 P iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 44: Switch Banks

    P2 XMC 12D 6 N P2 XMC 12D 12 N P2 XMC 12D 6 P P2 XMC 12D 12 P Ground Ground Ground Ground Switch Banks The following sections detail the available switches on the board: iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 45: S701 - Rs422/485 Termination Switch Bank

    SPI BootFlash Write Protect iVPX7225 SPI BootFlash Write Protected Follows NVMRO Backplane Input. Regardless of NVMRO Backplane Input May be Overridden by iVPX7225 Memory Write Protect Register at Offset 0x0B when NVMRO is LOW. iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 46 NVMRO Backplane Input. NVMRO Backplane Input May be Overridden by iVPX7225 Memory Write Protect Register at Offset 0x0B when NVMRO is LOW. For more information about Memory Write Protect Register, refer 6806800S11A-iVPX7225 Installation and Use manual. iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 47: Functional Description

    Chapter 4 Functional Description Block Diagram The following figure shows the block diagram of iVP7225 RTM. Figure 4-1 iVPX7225 RTM Block Diagram iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 48: Ethernet Interfaces

    Functional Description Ethernet Interfaces The Artesyn iVPX7225 module provides two 1000BASE-BX ports that are routed to the VPX backplane for operation as Ultra Thin Pipes per VITA 65 SLT3-PAY-2F2U-14.2.3 and SLT3-PAY- 1F1F2U-14.2.4 slot profiles. Ethernet is implemented using an Intel 82580 Gigabit Ethernet controller onboard the iVPX7225.

  • Page 49: Sata

    User Defined SATA The Artesyn iVPX7225 module provides two SATA Gen 3 (up to 6Gbit/s) ports and one SATA Gen 2 (up to 3Gbit/s) port routed to the VPX backplane P1 connector and another SATA Gen 2 (up to 3Gbit/s) port routed to the XMC.

  • Page 50: Serial Com

    DVI or HDMI through the use of active DP ->DVI or DP->HDMI adapters. The RTM front panel DE-15F connector (J901) provides the analog VGA output. 4.6.2 The RTM front panel DE-15F connector (J901) provides the analog VGA output. iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 51: Ipmc Debug Port

    PCH via VPX user IO pins. XMC Rear IO Access iVPX7225 RTM connector J1101 is a Samtec Edge Rate Socket providing access to the 12 differential pairs defined by the VITA 46.9 3U X12d Pattern. iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 52 Functional Description iVPX7225 RTM Installation and Use (6806800S35B)

  • Page 53: Related Documentation

    The publications listed below are referenced in this manual. You can obtain electronic copies of Artesyn Embedded Technologies - Embedded Computing publications by contacting your local Artesyn sales office. For released products, you can also visit our Web site for the latest copies of our product documentation.
  • Page 54 Related Documentation iVPX7225 RTM Installation and Use (6806800S35B)
  • Page 56 Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of Artesyn Embedded Technologies, Inc. All other product or service names are the property of their respective owners. © 2015 Artesyn Embedded Technologies, Inc.
