Daily Care Manual
Request for daily care
Inkjet printer is the precision machine that has highly delicate mechanism. Especially, little dust and
paper powder may have effect on a head nozzle firing ink, and may not get normal printing.
To use the inkjet printer in good condition, we recommend the following daily care.
MIMAKI ENGINEERING CO., LTD.
TKB Gotenyama Building, 5-9-41, Kitashinagawa, Shinagawa-ku, Tokyo 141-0001, Japan
Phone: +81-3-5420-8671
Fax: +81-3-5420-8687
URL: http: // www.mimaki. co. jp /
D201579
E-mail: trading@mimaki.co.jp

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UJF-605CII and is the answer not in the manual?

Questions and answers

Related Manuals for MIMAKI UJF-605CII

Summary of Contents for MIMAKI UJF-605CII

  • Page 1 To use the inkjet printer in good condition, we recommend the following daily care. MIMAKI ENGINEERING CO., LTD. TKB Gotenyama Building, 5-9-41, Kitashinagawa, Shinagawa-ku, Tokyo 141-0001, Japan Phone: +81-3-5420-8671 Fax: +81-3-5420-8687 URL: http: // www.mimaki. co. jp / D201579 E-mail: trading@mimaki.co.jp...

  • Page 2: Table Of Contents

    Table of contents In Case Sefective Printing Is Not Resolved ..........5 Cleaning Flushing Tray ................8 When The Waste Ink Tank Becomes Full..........10 Replacing Water In Water Heater Tank ..........11 Regular Maintenance For White Ink ............17 Cleaning Or Replacing Filter ..............
  • Page 3 Installation environment and Notes on cleaning • Use this printer in clean (less dust) environment. The use of fan and ventilator might be cause of dusty environment. They brow dust up dust around the printer. • As using UV curing ink, install this printer in a well-ventilated area. •...
  • Page 4 Maintenance for frame components If the frame components of the device have stained, dampen a piece of soft cloth with water or neutral detergent diluted with water, squeeze it and wipe the frame components clean.

  • Page 5: In Case Sefective Printing Is Not Resolved

    In Case Sefective Printing Is Not Resolved When the station interior is severely contaminated or defective printing is not resolved after executing the head cleaning function ( Operation manual P.2-20). Clean the suction nozzle and cap using the cleaning kit as follows, Washing liquid, Gloves, Cleaning swab, goggles •...
  • Page 6 • Suction nozzle severely contaminated or bent should be replaced with a new one. Contact your nearest sales agency or Mimaki sales office. • Contact your nearest sales agency or Mimaki sales office to order the exclu- sive cleaning swab.
  • Page 7 Suction nozzle cover 9. Wipe the adherent ink which got on the cap rubber or inside the suction nozzle cover with the exclusive cleaning swab. STATION 10. Close the maintenance cover and then press COMPLETED : ent the [ENTER] key. The initial operation is performe, then the device PLEASE WAIT enters to the LOCAL mode.

  • Page 8: Cleaning Flushing Tray

    Cleaning Flushing Tray Wipe off waste ink from the flushing tray. Tools necessary for cleaning: Washing liquid, Gloves, goggles, paper towel • When cleaning the ink station and head, be sure to wear the supplied goggle and gloves since you may get ink in your eyes. •...
  • Page 9 7. Open the left maintenance cover. 8. Wipe off the waste ink from the flushing tray with the paper towel containing wash- ing liquid. Take the caked ink off by pat- ting the tray. • Make sure to take the caked ink off completely, or it may cause head damage by the remaining caked ink.

  • Page 10: When The Waste Ink Tank Becomes Full

    When The Waste Ink Tank Becomes Full Waste ink used for cleaning the heads will gather in the waste ink tank. • Contact your local MIMAKI distributor or call a local MIMAKI office if you need a spare waste ink tank.

  • Page 11: Replacing Water In Water Heater Tank

    Precautions in handling the Anti-freezing liquid • Be sure to wear goggles and gloves for handling the Anti-freezing liquid. • Use the exclusive Anti-freezing liquid by Mimaki , or the heater may be damaged. • If the Anti-freezing liquid gets on the skin or clothes, immediately wash it off with soap.
  • Page 12 Replacing antifreezing liquid 1. Press the [FUNCTION] key from the LO- << LOCAL >> CAL mode. FUNCTION DATA CLEAR < ENT > FUNCTION 2. Press the [ ]XYnd [ ] keys until the dis- MAINTENANCE < ENT > play gives the indication [MAINTENANCE]. MAINTENANCE 3.
  • Page 13 9. Unlock catch clips on both sides of the cover. 10. Engage the water heater handle with the hook. • When engaging the handle with the hook, take care to avoid bending the cables or tubes or pulling them with excessive force, or it may cause malfunction of the water heater.
  • Page 14 11. Remove the water heater tank. • When moving water, take care not to spill it. If spilled, be sure to wipe it off. 12. Move waste water in the hot-water tank to a polyethylene tank. • When moving water, take care not to spill it.
  • Page 15 17. Open the water heater cover again and then remove the water heater tank. 18. Again, move waste water in the hot-water tank to a polyethylene tank. • When moving water, take care not to spill it. If spilled, be sure to wipe it off. •...
  • Page 16 22. Press the [ENTER] key. WATER CHANGE SET AF :ent 23. Press the [END] key and the replacement MAINTENANCE for the water heater was completed. WATER CHNG < ENT >...

  • Page 17: Regular Maintenance For White Ink

    Regular Maintenance For White Ink White ink is easier precipitate than other inks. In case without plotting more than two weeks, white ink may cause precipitate in ink car- tridge or inside of the device. And nozzle clogging has occurred and the normal plotting result is not able to obtain by precipitation.
  • Page 18 8. Shake the ink cartridge up and down about 10 times slowly. 9. Put the ink cartridge back to the ink sta- WHITE MAINTE. tion. SET CARTRIDGE **INK FILL UP** 10. Press the [ENTER] key and then start PLEASE WAIT [FILL UP INK].

  • Page 19: Cleaning Or Replacing Filter

    Cleaning Or Replacing Filter This unit contains a filter for the table. When the filter is clogged, the media absorbability will be weakened. If filter is soiled with dusts, clean it with vacuum cleaner, etc. If the filter is clogged by ink adhesion, replace the filter. STEP 1.

  • Page 20: Cleaning The Undersurface Of The Carriage

    Cleaning The Undersurface Of The Carriage Ink drops may appears on the head guard plate on the undersurface of the carriage, result in inferior printing or ink blot on the media. Make sure to perform cleaning regularly the undersurface of the carriage. For Cleaning: Washing liquid, Maintenance cleaning liquid, glove, goggles •...
  • Page 21 • Do not touch the head and nozzle part to avoid the damage. • Contact your nearest sales agency or Mimaki sales office to order the exclu- sive cleaning swab. 8. After cleaning, close the front cover and then turn the main device on.

  • Page 22: Storage Of Antifreezing Liquid And Washing Liquid

    Storage Of Antifreezing Liquid And Washing Liquid • Be sure to store the Antifreezing liquid and the washing liquid in a cold and dark place. • Store the Antifreezing liquid and the washing liquid in a place that is out of the reach of children.
  • Page 24 D201579-1.00-05102006 Printed in Japan © MIMAKI ENGINEERING Co., Ltd. 2006...
