UJF-3042MkII series/ UJF-6042MkII
UJF-3042MkII e series/ UJF-6042MkII e Clear
Ink Print Guide
This manual describes the effects that can be expressed when clear ink is used in UJF-3042MkII /UJF-
3042MkII EX /UJF-3042MkII e /UJF-3042MkII EX e/UJF-6042MkII /UJF-6042MkII e, and how to set and print
them.
Please read this manual carefully and use it correctly.
Note
• It is strictly prohibited to write or copy a part or whole of this document without our approval.
• This document has been carefully prepared for your easy understanding, however, please do not hesitate to
contact a distributor in your district or our office if you have any inquiry.
• Description contained in this document are subject to change without notice for improvement.
• Copying the Mimaki Engineering Co. Ltd. software described in this guide to other disks (except for backup
purposes) or loading it to memory except for the purpose of running it, is strictly prohibited.
• Due to improvement or change of software, the description of this document could be partially different in
specification, for which your understanding is requested.
• With the exception of what is provided for in the warranty provisions of MIMAKI ENGINEERING CO., LTD., we
do not assume any liability against the damages (including but not limited to the loss of profit, indirect damage,
special damage or other monetary damages) arisen out of the use or failure to use of this product. The same
shall also apply to the case even if MIMAKI ENGINEERING CO., LTD. had been notified of the possibility of
arising damages in advance. As an example, we shall not be liable for any loss of the media made using this
product or indirect damages caused by the product made using this media.
• You can also download the latest operation manual from our website.
Notations used in this document
• Items and buttons displayed in menus and on screens are marked with square brackets ([ ]) as in [File].
• RasterLink6,RasterLink6Plus and RasterLink7 are referred to as RasterLink in together.
Screen image used in this document
• The explanation is based on the screen image of RasterLink6Plus as an example.
Symbols
• This symbol indicates important information for using this product.
• This symbol indicates useful information.
RasterLink is the trademarks or registered trademarks of MIMAKI ENGINEERING CO., LTD. in Japan and in other
countries.
Adobe, the Adobe logo, Acrobat, Illustrator, Photoshop, and PostScript are the trademarks or registered trade-
marks of Adobe Systems Incorporated in the United States and other countries.
CorelDRAW is a trademark or registered trademark of Corel Corporation in Canada, the United States and other
countries, and its affiliates.
Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation of the United States and
other countries.
Apple and Macintosh are trademarks or registered trademarks of Apple Inc. of the United States and other coun-
tries.
Other company and product names mentioned herein are the trademarks or registered trademarks of the respec-
tive companies in Japan and in other countries.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MIMAKI UJF-3042MkII Series
Summary of Contents for MIMAKI UJF-3042MkII Series
-
Page 1: Note
• With the exception of what is provided for in the warranty provisions of MIMAKI ENGINEERING CO., LTD., we do not assume any liability against the damages (including but not limited to the loss of profit, indirect damage, special damage or other monetary damages) arisen out of the use or failure to use of this product. -
Page 2: Table Of Contents
• LUS-120 color ink + LUS-120 clear ink • LUS-150 color ink + LH-100 clear ink When using RasterLink6, RasterLink6Plus: The version that is compatible with the printer you use. Mimaki Driver When using RasterLink7:Ver.5.5.0 or later RasterLink6 Ver.5.9 or later RasterLink6Plus Ver.1.0 or later... -
Page 3: Setting The Printer
Setting the printer Before printing with this Guide, carry out setting of the printer as follows. Turn on the printer’s power. • Wait until <Local> is displayed on the panel. • If the power is already on, have the panel display <Local>. Select [UV MODE] on the panel, as follows: (1) With “Local”... - Page 4 • If you use the clear ink according to the procedures in this Guide, the settings will be made so that good-quality images are obtained, with the specified quality feel. Sometimes however, the image quality may be poor due to the media material or other factor. In that case, change the setting of 1-4 of the following procedures, please do a test print.
-
Page 5: Effects And Printing With Clear Ink
Effects and printing with clear ink Clear ink’s effects The effects below can be obtained by using clear ink. Gloss feel effect - “Glossy Print” Matte feel effect - “Matte Print” 3D feel effect - “Emboss Print” These effects can be obtained via the “UV MODE” settings in RasterLink. Recommended settings for printing a clear ink To obtain a better effect of clear ink, please use the recommended setting below for the printing con- dition and clear ink concentration according to the image quality and printing speed. -
Page 6: Ways Clear Ink Can Be Printed
Ways clear ink can be printed Clear ink can be printed in the ways below with RasterLink. Printed over the whole of a Printed onto valid pixels of a color Printed as a special image for color image image clear ink use For printing the clear ink over the whole of a color image, and for printing it onto valid pixels of a color image, cre- ate a clear ink job using the “Special plate”... -
Page 7: Printing Methods
Printing methods Data creation and printing procedures In order to print, you must first create clear ink data and make the settings for it on RasterLink, using the proce- dure below. Decide the way the clear ink is to be printed Clear ink is to be printed to A special clear ink image is to be printed match a color image... -
Page 8: Decide The Way The Clear Ink Is To Be Printed
1. Decide the way the clear ink is to be printed Suppose you have the following color image. You can print the clear ink in any of the three ways shown below. Print it over the whole of the color image ->... -
Page 9: Printing The Clear Ink Over The Whole Of The Color Image
A. Printing the clear ink over the whole of the color image To print the clear ink over the whole of the color image, create a special plate on the basis of the image. In the job list, select the job that will be the basis for the plate. •... -
Page 10: Printing The Clear Ink Onto The Valid Pixels Of The Color Image
B. Printing the clear ink onto the valid pixels of the color image To print the clear ink onto the valid pixels of the color image, create a special plate on the basis of the image. In the Job List, select the job that will be the basis for the plate. •... -
Page 11: Printing A Special Clear Ink Image
C. Printing a special clear ink image To print an image designed for clear ink, create a special image, separate from the color image, and carry out mono color replacement with RasterLink. After that, composite the clear ink image with the color image. Creating the clear ink image Using design software such as Illustrator or Photoshop, create a clear ink image with the following conditions:... - Page 12 Setting mono color replacement In the job list, select the clear ink job. • Click the “Properties” icon. Select “Mono color” in the [Job Attri- bute] dropdown list. Select the [Mono color] tab. (1) [Source color]: “Black” (2) [Ink]: “Clear” (3) Click the [OK] button.
- Page 13 Compositing the clear ink image with the color job In the job list, select the color job and the clear ink job. • Click the “Composition” icon. Carry out the following check. (1) Is the clear ink job above the color job in the job list.
-
Page 14: Select The Clear Ink's Effect: Set The Uv Mode
2. Select the clear ink’s effect: set the UV mode The clear ink’s effect is determined by the [UV mode setting] in RasterLink. Gloss feel effect - “Glossy Print” -> Go to a. Setting Glossy Print Matte feel effect - “Matte Print” ->... -
Page 15: Setting Glossy Print
a. Setting Glossy Print In the job list, select the clear ink job. • Click the “Properties” icon. • Click the [Setup] button in the [Job Attribute] field. Select the [UV Mode] tab. • Make the settings as follows. (1) Select “Glossy Print” in the mode list on the left side. -
Page 16: Setting Emboss Print
c. Setting Emboss Print In the job list, select the clear ink job. • Click the “Properties” icon. • Click the [Setup] button in the [Job Attribute] field. Select the [UV Mode] tab. • Make the settings as follows. (1) Select “Emboss Print” in the mode list on the left side. -
Page 17: Set The Recommended Values For The Printing Conditions
3. Set the recommended values for the printing conditions To obtain better effects from the clear ink, use the settings below that are appropriate for the image quality and output speed that you want. • When the color ink is LH-100 ink / LUS-120 ink Glossy print Resolution Pass... -
Page 18: Execute Printing
In the job list, select the applicable job. • Click the “Quality” icon. Select both the color job and the clear ink job that are displayed in the job list. • You can select multiple items by holding down the CTRL key while clicking on them. -
Page 19: Setting Glossy Finish For Emboss Print
Setting glossy finish for Emboss Print If you set just Emboss Print, the finish will be matte. To obtain a glossy finish, you must reate a Glossy clear ink job, separate from the Emboss Print clear ink job. Referring to “1. Decide the way the clear ink is to be printed” (P. 8~) to , create 1 color job and 2 clear ink jobs. - Page 20 Choose the job of clear ink from the job list that is not selected in step 2. • Refer to “a. Setting Glossy Print”and set the glossy print. Choose the color job and clear ink of step2+3 from the job list, •...
- Page 21 - 21 -...
- Page 22 D203138-14-01102021 © MIMAKI ENGINEERING CO., LTD.2016...
