4.3 Ventilation
Motors are cooled through outer air blow (IC 411 according to CEI EN 60034-6) and are equipped
with a plastic radial fan, which operates in both directions.
Ensure that fan cover is installed at a suitable distance from the closest wall so to allow air circulation
and servicing of motor and brake, if fitted.
On request, all BX/MX, BE/ME motors and BN/M motors, starting from BN 71 or M1 size, can be sup-
plied with independently power-supplied forced ventilation system.
Motor is cooled by an axial fan with independent power supply and fitted on the fan cover (IC 416
cooling system).
Brake motors of BN_BA type and all motors with rear shaft projection (PS option) are excluded.
4.4 Ratings of separate supply fan units
BN 71
BN 80
BN 90
BN 100
BN 112
BN 132 ... BN 160MR
BN 160M ... BN 180M
BN 180L ... BN200L
BX 80 - BE 80
BX 90 - BE 90
BX 100 - BE 100
BX 112 - BE 112
BX 132 - BE 132
BX 160 - BE 160
BX 180 - BE 180
IOM BX-BE-BN-MX-ME-M_eng - Translation of original instructions in Italian - Rev 02_0 - 30/09/16
Fan wiring terminals are housed in a separate terminal box
M1
M2
—
M3
—
M4
3 ~ 230 / 400Y
M5
—
MX2 - ME2
—
MX3 - ME3
—
MX4 - ME4
3 ~ 230 / 400Y
MX5 - ME5
—
U1
V a.c. ± 10% Hz
1 ~ 230
50 / 60
50
V a.c. ± 10% Hz
1 ~ 230
50 / 60
50
P [W] I [A]
22 0.12
22 0.12
40 0.30
50 0.25
50 0.26 / 0.15
110 0.38 / 0.22
180 1.25 / 0.72
250 1.51 / 0.87
P [W] I [A]
22 0.12
40 0.30
50 0.25
50 0.26 / 0.15
110 0.38 / 0.22
180 1.25 / 0.72
250 1.51 / 0.87
