Wall Mounting iPIO-2
Use the ear tabs on the Unit to
directly mount to wall or backboard
Mount to wall or backboard with
proper hardware.
DIN Rail Mounting iPIO-8 and iPIO-16
Install the Intermediate bracket onto
the bottom of the unit using the 4
silver screws.
iPIO-2816_v180808n
iPIO-2, iPIO-8, iPIO-16 Users Guide
Page 9
