Install the DIN rail clips using the
black screws as shown
Mount to DIN Rail
DIN Rail Mounting iPIO-2
Install the DIN rail clips using the
four black screws. Clips can be
mounted for either vertical or
horizontal aspect.
Mount to DIN Rail
iPIO-2816_v180808n
iPIO-2, iPIO-8, iPIO-16 Users Guide
Page 10
