4.8.
Wall and DIN Mounting
A mounting kit for wall and DIN rail mounting is available.
Part # 1920034 Wall and DIN Mounting Kit
Wall Mounting iPIO-8 and iPIO-16
Install the wall mounting ears to the
unit using the four silver screws.
Mount to wall using appropriate
hardware
iPIO-2816_v180808n
Remove all cables from the unit prior to installing or
removing any mounting hardware.
iPIO-2, iPIO-8, iPIO-16 Users Guide
Page 8
