Firmware Upgrades - Dataprobe iPIO-8 Manual

The iPIO can be field upgraded. Find the latest version or special purpose versions at
http://dataprobe.com/support-ipio
Firmware upgrades may or may not reset the iPIO to factory defaults. Check the
release notes on our user's forum for the upgrade before making changes to you iPIO.
1) Run the Device Management Utility, available at the link above. If the iPIO you would like to upgrade is not
visible in the list box, either
Select Device | Discover from the menu to locate iPIO units on the local network, or
Select Device | Add from the menu to add the IP address of the iPIO.
Once the device is displayed in the list, highlight it
2) Select Manage | Upgrade Firmware
Enter User Name root and the Password for the Administrator. (default is admin)
Enter the filename of the firmware,
or click Browse and find the file of
the firmware file to be used. iPIO
firmware uses the extension .ipu If
you don't see any files of that type;
make sure the 'Files of type' box is
set for iPIO or All Files.
Click OK when all the details are
entered.
3) The upload will
progress bar will be displayed.
4) When the firmware
completed, WAIT 2 Minutes.
iPIO will automatically reset and be
ready for use.
iPIO-2816_v180808n
10.

Firmware Upgrades

begin, and a
upload is
The
iPIO-2, iPIO-8, iPIO-16 Users Guide Page 25
