PRINTING GUIDE
UJF-7151plus
PRODUCTION FLATBED LED UV PRINTER
Date: 13-12-2018
Version: 1.1EU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UJF-7151plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MIMAKI UJF-7151plus

Summary of Contents for MIMAKI UJF-7151plus

  • Page 1 PRINTING GUIDE UJF-7151plus PRODUCTION FLATBED LED UV PRINTER Date: 13-12-2018 Version: 1.1EU...

  • Page 2: Terms Of Use

    Mimaki Europe B.V. • Contents and technical explanations in this presentation are based on the test results achieved at Mimaki at the time of testing and are not a guarantee for performance. Substrates should be tested beforehand.

  • Page 3: Available Print Modes

    AVAILABLE PRINT MODES Print condition Printing method Color Color Color Print time Print mode Resolution Pass Color only White only Clear only Primer only + White + Clear + Primer （full size） Undercoat 600x300 4pass 3m47s △ △ △ △ △...

  • Page 4: Operation Panel

    MAPS • Use the MAPS* (Mimaki Advanced Pass System) function to disperse the pass boundary to make the feeding stripes less visible • MAPS4 can be switched to “AUTO” or “MANUAL” from printer’s operation panel: • Press the “MENU” key in local mode •...

  • Page 5: Color Matching Function

    • To create new color matching setting: • RasterLink6 Print Condition  Color Matching • Highlight and delete “Mimaki Expand Color” in Color Matching Window and input new name • Click on and change the setting • New setting will be active...

  • Page 6: Printing Clear Ink

    PRINTING CLEAR INK • For printing clear use print modes above 600x600dpi 8pass • Use recommended ink density settings for printing clear depending on the substrate and the resolution • Clear printings will have a better quality by using the optimum density depending on the print condition Purpose Print condition...

  • Page 7: Printing Primer Ink

    PRINTING PRIMER INK • When printing with 600x600dpi 6pass, the adhesion between ink and media may not be sufficient. • Please use print modes above 600x600dpi 8pass • It is recommended to print Primer with 100% density from RasterLink6 • This setting will automatically adjust the density to the recommended print density •...

  • Page 8: Printing White Ink

    PRINTING WHITE INK • A Higher density white ink is available for following print modes: Print conditions High density printing Print time MAPS4 availability Print mode Resolution Pass High density white Recommended density when printing high density white （full table） 12pass 10m15s 10 - 90% (*2)

  • Page 9: Undercoat Printing

    UNDERCOAT PRINTING • When printing directly on general acrylic substrates, Acrylite, Sumipex or Plexiglas with LUS-120, the image quality may gets blurred • By printing undercoat* with “primer” or “clear”, thin lines and small fonts can be printed sharp without being blurry *1 Refer to recommended density setting of clear and primer for undercoat printing •...

  • Page 10: Setting Undercoat Printing: Primer

    SETTING UNDERCOAT PRINTING: PRIMER 1. Create “Primer” layer by clicking on Color layer and then “Special Plate” Set the Special Color condition I. Ink: Primer II. Primer: 100% III. Created Area: choose one of options IV. Click on Create Set print condition for Special Plate 1.

  • Page 11: Setting Undercoat Printing: Clear

    SETTING UNDERCOAT PRINTING: CLEAR 1. Create “Clear” layer by clicking on Color layer and then “Special Plate” Set the Special Color condition Ink: Clear Clear: 70% III. Created Area: choose one of options IV. Click on Create Set print condition for Special Plate 1.

  • Page 12: Braille Printing: General

    BRAILLE PRINTING: GENERAL • Braille characters shape according to JIS* (Japanese Industrial Standard) can be can be easily created in in Adobe Illustrator by setting a spot color around Braille characters with RasterLink Tools Measurement range Minimum size d= dot base diameter 1,46mm +/- 0,05 h= dot height 0,4mm +/- 0,1...

  • Page 13: Braille Printing: Procedure

    BRAILLE PRINTING: PROCEDURE 1. Illustrator • Braille file preparation in Adobe Illustrator 2. RasterLink Tools • Set Spot Color around Braille signs in Illustrator 3. RasterLink Tools • Exporting the Braille signs to RasterLink6Plus • Import Braille data into rasterLink6Plus and set 4.

  • Page 14: Braille Printing: Design

    BRAILLE PRINTING: DESIGN • Create vector data for Braille characters • Shape: Circle • Diameter: 1,45mm • Dimensions of JIS Braille sizes: Measurement range Measurement size a: Vertical dot-to-dot 2,3mm +/- 0,1 b: Horizontal dot-to-dot 2,3mm +/- 0,1 q: Vertical cell-to-cell 6,1mm +/- 0,1 p: Horizontal cell-to-cell 5,0mm...
  • Page 15 BRAILLE PRINTING: DESIGN • Confirm RasterLink Tools setting : • Set the Braille type to “JIS” • Check off the option “Print Special Color Layer” • Set a spot color around Braille data by RasterLink Tools • Select Braille data •...

  • Page 16: Braille Printing: Print

    BRAILLE PRINTING: PRINT • Braille printing requires that the specific profile is installed in RasterLink6Plus Printer Ink set Output setting Profile Material UJF-7151plus LH-100 CMYK 600x900dpi UV-PET UJF-3042MkII LH-100 CMYK 1200x1200dpi* UV-PET v3.5 Glossy white PET UJF-3042MkIIEX/ UJF-6042MkII LH-100 CMYKLcLm 1200x1200dpi* UV-PET v3.5...

  • Page 17: Metallic Ink: Print Workflow

    METALLIC INK: PRINT WORKFLOW 1. Import Data • Import “Color” and “Metallic Color” data 2. Create Metallic Layer • Create “Metallic” layer from “Metallic Color” data 3. Composite Layers • Composite all layers into one job 4. Finish Metallic Layer •...
  • Page 18 INTRODUCTION • The MUH-100 metallic in RasterLink6 can be printed by arranging the print data in 3 layers 3. Metallic Color Layer • Color ink over metallic ink Top Layer 2. Color Layer Middle Layer • Color ink 1. Metallic layer •...

  • Page 19: Muh-100-Si Print Condition

    MUH-100-SI PRINT CONDITION • Compatible Printer Printer Ink-set Special ink-set UJF-7151 LH-100 CMYK • Print Condition Type Resolution Pass Color-matching Note Attribute Hi 600x900 VD Si High speed Metallic layer Optional Silver Std 600x900 VD Si High quality Metallic 600x900 VD Silver ColorMatching OFF Color Color Layer...

  • Page 20: Import Data

    IMPORT DATA • Import to RasterLink 6 Plus the print data for “Color” and “Metallic Color” 1. Metallic Color Layer layers • Color ink over metallic ink 2. Color Layer • Color ink • The “Color” and “Metalic Color” layers are displayed in [Job List] of RasterLink 6 Plus...
  • Page 21 CREATE METALLIC LAYER • Select “Metallic Color” layer and click the [Special plate] icon from Toolbar • On the [Special plate] window, specify "Silver" for ink, "Valid pixel" for created area, and then click the .Select ”Silver” for Ink [Create] button Select "Valid pixel“...

  • Page 22: Composite Layers

    COMPOSITE LAYERS • Select three jobs from the [Job List] : “Metallic Color”, “Color”, and “Silver” layers • Click on [Composition] icon from Toolbar • On Composition window confirm: Metallic Color • Layer order from top: “Metallic Color”, “Color”, “Silver” Color Silver •...

  • Page 23: Composition Confirmation

    COMPOSITION CONFIRMATION • The selected jobs in the job list are composed and a line is displayed in [Layered] • Composed jobs output order: • “Metallic Color” -3 (Top layer) • “Color” -2 (Middle layer) • “Silver” -1 (Bottom Layer)
  • Page 24 FINISH OF METALLIC LAYER • Click on [Properties] Icon from Toolbar 1. Select [Properties] • Select the “Silver” layer from [Job List” 2. Select silver plate • Click the [Setup] button in “Job 3. Click [Setup] Attribute” on [Properties] window •...

  • Page 25: Set Print Quality Of Metallic Layer

    SET PRINT QUALITY OF METALLIC LAYER • Click the [Quality] icon from Toolbar • Select ‘Silver” Job from [Job List] • Setup [Print Quality] Tab as follows: • “Media”: Select media that ends with “Si” • “Resolution”: Select “Std 600x900 VD Si” 1.

  • Page 26: Set Print Quality Of Metallic Color

    SET PRINT QUALITY OF METALLIC COLOR • Click the [Quality] icon from Toolbar • Select ‘Metallic Color” Job from [Job List] 4. Select “ColorMatching OFF” • Setup [Print Quality] Tab as follows: • “Media”: Select media that ends with “Si” •...
  • Page 27 SET PRINT QUALITY OF COLOR • Click the [Quality] icon from Toolbar • Select ‘Color” Job from [Job List] • Setup [Print Quality] Tab as follows: • “Media”: Select media that is used for printing Color OceanDew.. [3]. • “Resolution”: Select available resolution Color OceanDew..

  • Page 28: Print Metallic Job Composition

    PRINT METALLIC JOB COMPOSITION • Click the [Execution] icon from Toolbar...
  • Page 29 Thank you...
