Carefree Freedom RM Service Manual page 23

Carefree of Colorado
Item Part Number
1 R037519-005
R037519-006
R037519-231
2 R037519-001
3 R001651
4 610900-xxx.xx
5 R001623
6 R037516-001
7 R037518-005
R037518-006
R037518-231
8 R019280-003
9a R012530-TB68L
9b R012530-TB76L
9c R012530-TB79L
9d R012530-TB94L
10a R001872
10b R001873
11 R019280-004
12a R012530-TB68R
12b R012530-TB76R
12c R012530-TB79R
12d R012530-TB94R
13 R012530-TB94M
14 R001595
15 R001819X-aa-xxx
16 R041353-005
R041353-006
R041353-231
17 R041352-005
R041352-006
R041352-231
18 R001691
19 R001690
20a R001655-003
20b R001655-001
20c R001655-002
21a R001655-103
21b R001655-101
21c R001655-102
22 R001657
23 R00394
R019283-005
24
R019283-006
25 R001605
Notes: 1. Attaching hardware not included with arm assemblies. Order item 9.
2. Motor assembly (item 2) includes motor, bearing and one-way drive. Components not
available separately.
3. For Item 14 (lead rail): X= Color: B=Black, W=White, S=Satin; aa = LED: LO= w/ LED
outside, XX=No LED; xxx= product order length.
4. The middle spring arm is different than the outer arms. Center arms can be identified by the
blue dot located on or near the case connector of the arm. Do not use center arms for
replacing outer arms, do not use outer arm to replace the center arm.
052978-351r8
Service Manual
Endcap, LH, White
Endcap, LH, Black
Endcap, LH, Satin
Case Endplate, LH
Motor Assembly
Roller Tube
End Plug
Case Endplate, RH
Endcap Assembly, RH, White
Endcap Assembly, RH, Black
Endcap Assembly, RH, Satin
Connector Assembly, Case, LH
Spring Arm, LH
Spring Arm, LH
Spring Arm, LH
Spring Arm, LH
Connector Kit, Lead Rail
Connector Kit, Lead Rail
Connector Assembly, Case, RH
Spring Arm, RH
Spring Arm, RH
Spring Arm, RH
Spring Arm, RH
Spring Arm, Center
Hardware Pack, Arm Attach, 1 Arm
Lead Rail
Lead Rail End Plate, LH, White
Lead Rail End Plate, LH, Black
Lead Rail End Plate, LH, Satin
Lead Rail End Plate, RH, White
Lead Rail End Plate, RH, Black
Lead Rail End Plate, RH, Satin
Lead Rail Guide Kit
Leg Support Kit
Vertical Support Leg, LH
Vertical Support Leg, LH
Vertical Support Leg, LH
Vertical Support Leg, RH
Vertical Support Leg, RH
Vertical Support Leg, RH
Flipper Latch Kit, Orange
Carport Foot
Kit, Bottom Bracket, White
Kit, Bottom Bracket, Black
Switch Kit
Description
2.44 Meter
2.57 Meter used thru 05/2017
2.57 Meter used 06/2017 & ON
3 Meter & Up
includes 1 LH and 1 RH connector
includes 1 LH and 2 RH connectors
2.44 Meter
2.57 Meter used thru 05/2017
2.57 Meter used 06/2017 & ON
3 Meter & Up
4.5 and 5 meter only
(contains 2 ea. screw, washer and spacer)
Used with 2.44 Meter
Used with 2.57 & 3 Meter
Used with 3.5 Meter & Up
Used with 2.44 Meter
Used with 2.57 & 3 Meter
Used with 3.5 Meter & Up
F RM
REEDOM
Notes
2
1
1
1
1
1
4
1
1
1
1
1
1,4
3
pkg of 4
pkg of 2
pkg of 2
20
