Carefree Freedom RM Service Manual page 19

Carefree of Colorado
Item Part Number
1 R037382-005
R037382-006
R037382-231
2 R001651
3 R001594WHT
R001594BLK
R001594SAT
4 R040832-001
R040665-002
5a R012530-TB68L
5b R012530-TB76L
5c R012530-TB94L
6a R012530-TB68R
6b R012530-TB76R
6c R012530-TB94R
7 R019280-001
8 R019280-002
9 R001872
10 R001595
11 R001819X-aa-xxx
12 R040981-005
R040981-006
R040981-231
13 R040981-005
R040981-006
R040981-231
14 R001691
15a R001655-003
15b R001655-001
15c R001655-002
16a R001655-103
16b R001655-101
16c R001655-102
17 R001657
18 R00394
19 R001690
20 R019283-005
R019283-006
R019283-231
21 R001605
Notes: 1. Attaching hardware not included with arm assemblies. Order item 10.
2. Motor assembly (item 3) includes motor, bearing and one-way drive. Components not available
separately.
3. A motor upgrade kit (SR0098XXX) is available for manual crank awnings and includes end cap
(item 1), motor assembly (item 2), switch kit (item 21) and attaching hardware.
4. If replacing an original fixed pitch case connector, replace both case connectors.
5. If replacing an original lead rail connector, replace both lead rail connectors.
6. For Item 12 (lead rail): X= Color; B=Black, W=White, S=Satin. aa = LED; LO= w/ LED outside,
LI= w/ LED Inside, XX=No LED. xxx= product order length.
052978-351r8
Service Manual
Endcap, LH, White
Endcap, LH, Black
Endcap, LH, Satin
Motor Assembly
Endcap Assembly, RH, White
Endcap Assembly, RH, Black
Endcap Assembly, RH, Satin
Plug, White
Plug, Black
Spring Arm Assembly, LH
Spring Arm Assembly, LH
Spring Arm Assembly, LH
Spring Arm Assembly, RH
Spring Arm Assembly, RH
Spring Arm Assembly, RH
Connector Assembly, Case, LH
Connector Assembly, Case, RH
Connector Kit, Lead Rail
Hardware Pack, Arm Attach, 1 Arm
Lead Rail
Lead Rail End Plate, LH, White
Lead Rail End Plate, LH, Black
Lead Rail End Plate, LH, Satin
Lead Rail End Plate, RH, White
Lead Rail End Plate, RH, Black
Lead Rail End Plate, RH, Satin
Lead Rail Guide Kit
Vertical Support Leg, LH
Vertical Support Leg, LH
Vertical Support Leg, LH
Vertical Support Leg, RH
Vertical Support Leg, RH
Vertical Support Leg, RH
Flipper Latch Kit, Orange
Carport Foot
Leg Support Kit
Kit, Bottom Bracket, White
Kit, Bottom Bracket, Black
Kit, Bottom Bracket, Satin
Switch Kit
Description
Used with 2.44 Meter
Used with 2.57 Meter
Used with 3 Meter & Up
Used with 2.44 Meter
Used with 2.57 Meter
Used with 3 Meter & Up
includes 1 LH and 1 RH connector
Used with 2.44 Meter
Used with 2.57 & 3 Meter
Used with 3.5 Meter & Up
Used with 2.44 Meter
Used with 2.57 & 3 Meter
Used with 3.5 Meter & Up
(contains 2 ea. screw, washer and spacer)
F RM
REEDOM
Notes
2,3
1
1
1
1
1
1
1,4
1,4
1,5
6
pkg of 4
pkg of 2
pkg of 2
pkg of 2
16
