Carefree Freedom RM Service Manual page 21

Carefree of Colorado
Item Part Number
1 R037361-005
R037361-006
2 R001685WHT
R001685BLK
3 R001688WHT
R001688BLK
4 R001686WHT
R001686BLK
5 R040832-001
R040832-002
6 R001689
7 R001623
8 R012530-TB94L
9 R012530-TB94R
10 R012530-TB94M
11 R019280-001
12 R019280-002
13 R001776
14 R001595
15 R001692
16 R001819X-aa-xxx
17 R040981-005
R040981-006
18 R040981-005
R040981-006
19 R001691
20 R001655-002
21 R001655-102
22 R00394
23 R001657
24 R001690
25 R019283-005
R019283-006
26 R001605
27 R001594XXX
Notes: 1. Attaching hardware not included with arm assemblies. Order item 14.
2. Motor assembly (item 3) includes motor, bearing, one-way drive and end cap. Motor
components not available separately.
3. The middle spring arm is different than the outer arms. Center arms can be identified by the blue
dot located on or near the case connector of the arm. Do not use center arms for replacing outer
arms, do not use outer arms to replace the center arm.
4. If replacing an original fixed pitch case connector, replace all case connectors.
5. If replacing an original fixed position lead rail connector, replace all lead rail connectors.
6. For Item 16 (lead rail): X= Color; B=Black, W=White, S=Satin. aa = LED; LO= w/ LED outside,
LI= w/ LED Inside, XX=No LED. xxx= product order length.
052978-351r8
Service Manual
Endcap Outer, Manual, LH, White
Endcap Outer, Manual, LH, Black
Motor Assembly, White
Motor Assembly, Black
Plug, LH, White
Plug, LH, Black
Endcap Assembly, RH, White
Endcap Assembly, RH, Black
Plug, RH, White
Plug, RH, Black
Roller Tube Guide
End Plug, Roller Tube
Spring Arm Assembly, LH
Spring Arm Assembly, RH
Spring Arm Assembly, Center
Connector Assembly, Case, LH
Connector Assembly, Case, RH
Connector Assembly, Lead Rail
Hardware Pack, Arm Attach, 1 Arm
Tray Support
Lead Rail
Lead Rail End Plate, LH, White
Lead Rail End Plate, LH, Black
Lead Rail End Plate, RH, White
Lead Rail End Plate, RH, Black
Lead Rail Guide Kit
Vertical Support Leg, LH
Vertical Support Leg, RH
Carport Foot
Flipper Latch Kit, Orange
Leg Support Kit
Kit, Bottom Bracket, White
Kit, Bottom Bracket, Black
Switch Kit
Plug
Description
Used on 4.5 and 5 meter only
(contains 2 ea. screw, washer and spacer)
F RM
REEDOM
Notes
2
2
1
1,3
1,4
1,4
1,5
1
1
6
1
1
pkg of 4
pkg of 2
pkg of 2
18
