Carefree FREESTYLE EVOLUTION Owner's Manual

12v motorized roof mounted box awning with carefree’s bt12 wireless awning control system
Hide thumbs Also See for FREESTYLE EVOLUTION:
Table of Contents

Advertisement

Quick Links

Download this manual
RV
with Carefree's BT12 Wireless Awning Control System
Using Bluetooth ® wireless technology

Table of Contents

Introduction ........................................................................................................... 2
Operation ............................................................................................................... 6
Standard Switch Operation ............................................................................ 6
Ignition Lockout ............................................................................................. 6
BT Motion Sensor .......................................................................................... 7
Options ................................................................................................................... 8
BT Remote .................................................................................................... 8
LED's ............................................................................................................. 9
Setting the System into Pairing Mode ......................................................... 10
Carefree Connects Mobile App ................................................................... 11
FAQs ..................................................................................................................... 12
The Indicator Light Blinks on the Control Box. ............................................. 12
The System Beeps and the Awning Retracts. ............................................. 12
The Remote Does Not Work ....................................................................... 12
Manual Override .................................................................................................. 13
Awning Care ........................................................................................................ 14
Fabric Care .................................................................................................. 14
Arm Noise .................................................................................................... 15
Adjusting the Pitch ....................................................................................... 15
Carefree Major Product Limited Warranty ......................................................... 16
Before operating the awning, review the Owner's Manual. The manual
contains important safety information, detailed operating instructions,
common maintenance procedures and other useful information.
12V M
OTORIZED
O
WNER
F
REESTYLE
R
M
OOF
OUNTED
'
M
S
ANUAL
E
VOLUTION
B
A
OX
WNING





















Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FREESTYLE EVOLUTION and is the answer not in the manual?

Questions and answers

Related Manuals for Carefree FREESTYLE EVOLUTION

Summary of Contents for Carefree FREESTYLE EVOLUTION

  • Page 1: Table Of Contents

    WNER ANUAL REESTYLE VOLUTION 12V M OTORIZED OUNTED WNING with Carefree’s BT12 Wireless Awning Control System Using Bluetooth ® wireless technology Table of Contents   Introduction ......................2   Operation ....................... 6 Standard Switch Operation ................6   Ignition Lockout ..................... 6  ...

  • Page 2: Introduction

    Check with your dealer to discover the products that can make your life more Carefree. The Carefree Freestyle Evolution awning is state of the art with lateral support arms that provides strength and functionality without interfering with coach sidewalls, custom graphics or equipment that may be mounted on the sidewalls.
  • Page 3 RADEMARKS The Bluetooth ® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. Use of such marks by Carefree of Colorado is under license. Other trademarks and trade names are those of their respective owners. TATEMENTS OF OMPLIANCE ●...
  • Page 4 The information contained in this manual pertains to the current components and software listed on the title page. Carefree of Colorado reserves the right to cancel, change, alter or add any parts and procedures, described in this manual, without prior notice.
  • Page 5 RAGM F RM A REESTYLE WNING Warnings and Cautions This is the safety alert symbol. It is used to alert individuals to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible personal injury or death. WARNING This product can expose you to chemicals including Di-isodecyl phthalate (DIDP), Vinyl Chloride and Formaldehyde, which are...

  • Page 6: Operation

    Carefree of Colorado PERATION The BT12 Wireless Awning Control System offers multiple methods of operating the awning: standard switch operation, the Carefree Connects Mobile App (see page 10) and the BT Remote (see page 8). TANDARD WITCH PERATION To Operate the Awning: ...

  • Page 7: Bt Motion Sensor

    NOTICE The Carefree auto retract system is a premier electronic auto- retract system that provides protection against adverse elements; but no auto- retract system is a guarantee against severe or destructive weather; the effects of wind and rain on an awning are unpredictable and may cause severe damage to the awning and/or vehicle.

  • Page 8: Options

    The BT12 Wireless Control System offers several options to enhance your awning experience. OEM’s may install these options as a standard offering or can be added to your system at a later date. Contact your Carefree dealer about these options.

  • Page 9: Led's

    Factory installed LEDs are located in the lead rail. The BT12 Control System provides controls to allow you to set the lights to match your preference with ON/OFF and dimming controls through the Carefree Connects Mobile App and/or the BT Remote.

  • Page 10: Setting The System Into Pairing Mode

    ETTING THE YSTEM INTO AIRING Peripheral devices (such as remotes and smart devices with the Carefree Connects app) must be paired to the BT12 Control Module. There are two methods to set the system into pairing mode. Using the Awning Retract Function: Turn power to the awning ON.

  • Page 11: Carefree Connects Mobile App

    The power switch (see page 6) must be on for the MPORTANT extend/retract functions to be active using the standard switch operation, the Carefree Connects Mobile App and the BT Remote. The BT Motion Sensor is disabled when the switch is OFF.

  • Page 12: Faqs

    One long blink and one short blink indicates power and 1 peripheral (i.e. remote) is paired to the module. o The module does not blink for being paired to a mobile device with the Carefree Connects BT023 Mobile App. YSTEM...

  • Page 13: Manual Override

    RAGM F RM A REESTYLE WNING ANUAL VERRIDE If power to the vehicle is not available, the awning can be safely retracted using the manual override located on the idler end of the case. NOTE: This procedure cannot be used to extend the awning. Remove the outer endcap on the idler side and save.

  • Page 14: Awning Care

    Carefree of Colorado WNING Maintaining a Carefree Awning is easy. Just follow these basic steps:  Always operate the awning according to the instructions.  Periodically check that the fasteners are tight. Tighten if necessary.  Keep the awning fabric and arms clean.

  • Page 15: Arm Noise

    RAGM F RM A REESTYLE WNING OISE After a period of use, the arm knuckle joints may slide together slightly making a squeaking or squealing noise; this is normal and not a reason for concern. To reduce ® 1 the sound, apply a few drops of multi-purpose oil (3-IN-1 or equivalent) on the knuckle joint seams.

  • Page 16: Carefree Major Product Limited Warranty

    Carefree’s obligation under this warranty is limited to the repair or replacement, at Carefree’s option, of any defective component with new or factory refurbished components.
