IP address
IP setup
Subnet
Configuration User cfg. 1
profiles (node name)
Record
User cfg. 2
(node name)
Record
Defaults Port defaults
Protocol
defaults
Touchscreen
calibration
Factory
defaults
40Hz
VALUE
mask
VALUE
Easy IP
Load
Confirm
Back
Confirm
Back
Delete
Confirm
Back
Load
Confirm
Back
Confirm
Back
Delete
Confirm
Back
Load
Load
Reset
Reset
Fixed 40Hz refresh rate
Set the IP address of IQ
Set the subnet mask of IQ
This setting will ensure that software will
search for all masks, not only for a
specified subnet mask
User configuration profile 1
Button for loading the configuration
settings
Button for recording the configuration
settings
Button for deleting the configuration
settings
User configuration profile 2
Button for loading the configuration
settings
Button for recording the configuration
settings
Button for deleting the configuration
settings
This setting will restore port defaults
Confirm
Back
This setting will restore protocol defaults
Confirm
Back
Setting in case the touchscreen
calibration is needed.
Confirm
Back
This setting will restore factory defaults
(will reset ALL settings)
Confirm
Back
