Level 1
Level 2
Node setup
Node name
Universe
Screen lock
LCD/ LED
brightness
Protocol
Protocol setup
Easy priority
On source
Source loss
timeout
ArtNet idle
resend
DMX out
refresh rate
Level 3
Label
format
Base 16 (0-15)
Hex (0-F)
Decimal (0-32767)
time
0, 5-600
Off
Dimmed
Full
Art-Net
sACN
Off
On
loss
Hold output
Blackout
Stop DMX
VALUE
0.5 s
1.0 s
2.0 s
4.0 s
Adaptive
20Hz
30Hz
Level 4
Notes
Node name
Enter node name label.
In this menu you can set the universe
format for your needs.
Time after which the screen will
automatically get locked.
0- off
5- minimum
600- maximum
Values in seconds
Adjust LCD and LED brightness settings
for your needs.
Choose out of the 2 possible data
processing protocols.
Art-Net protocol
sACN protocol
If EASY PRIORITY is ON, when two or
more of the same universes are coming
in to the node, the console with the
higher channel 512 value will have
control over the universe.
This setting determines what will happen
on source loss
On DMX source loss, holds the last
received DMX values
After DMX source loss, all values will be
sent at a value of zero
After DMX source loss the outgoing
DMX signal will be disabled
This setting determines how long the IQ
Two will wait before using the Source
Loss setting.
This setting determines the time the IQ
will resend an Art-Net packet even if no
new DMX packet is received (Applies to
ports set to INPUT mode only)
The refresh rate for outgoing DMX data
(actions per second)
Adapts to the input data
Fixed 20Hz refresh rate
Fixed 30Hz refresh rate
