Abb. 3
Abb. 4
Abb. 5
Demontage der markierten Steckverbindun-
gen ( Torx 20 )
Undo the marked plug connections
Demontage der markierten Steckverbindun-
gen ( Torx 20 )
Undo the marked plug connections
Amplifier-Modul kann nun ersetzt werden.
The amplifier module can now be replaced.
6
