2. Descriptions
1.
Channel 1 Display
2.
Channel 2 Display
3.
Channel 3 Display
4.
LOG and
5.
SET button
▲and
6.
▼ and
7.
8.
AC adaptor socket
9.
Reset button
10. RS-232 output
11. SD memory card socket
12. Channel 1 input
13. Channel 2 input
14. Channel 3 input
Note: Battery Compartment and Tilt Stand are located on the back of the meter.
(ENTER) button
(TIME) button
( Power) button
4
SD900-en-GB_V1.3 6/19
