Lanner NVA-3000 Series User Manual

Embedded computing
Hide thumbs

Advertisement

Quick Links

Download this manual

Chapter 1: Product Overview

Embedded Computing
NVA-3000
User Manual
Date of Release: 2019-05-08
1
Version: 1.0

Advertisement

loading

Related Manuals for Lanner NVA-3000 Series

Summary of Contents for Lanner NVA-3000 Series

  • Page 1: Chapter 1: Product Overview

    Chapter 1: Product Overview Embedded Computing NVA-3000 User Manual Version: 1.0 Date of Release: 2019-05-08...
  • Page 2 Warning: This mark indicates that there is a caution or warning and it is something that could damage your property or product. The listed websites are links to the on-line product information and technical support. Resources Lanner http://www.lannerinc.com Product Resource http://www.lannerinc.com/download-center http://eRMA.lannerinc.com...
  • Page 3 Chapter 1: Product Overview This product has passed the CE test for environmental specifications. Test conditions for passing included the equipment being operated within an industrial enclosure. In order to protect the product from being damaged by ESD (Electrostatic Discharge) and EMI leakage, we strongly recommend the use of CE compliant industrial enclosure products.
  • Page 4 NVA-3000 User Manual Follow these guidelines to ensure general safety: Keep the chassis area clear and dust-free during and after installation. Do not wear loose clothing or jewelry that could get caught in the chassis. Fasten your tie or scarf and roll up your sleeves.
  • Page 5 The installation of this product must be performed by trained specialists; otherwise, a non-specialist might create the risk of the system’s falling to the ground or other damages. Lanner Electronics Inc. shall not be held liable for any losses resulting from insufficient strength for supporting the system or use of inappropriate installation components.
  • Page 6 NVA-3000 User Manual Risque d’explosion si la pile est remplacée par une autre d’un mauvais type. Jetez les piles usagées conformément aux instructions. L’installation doit être effectuée par un électricien formé ou une personne formée à l’électricité connaissant toutes les spécifications d’installation et d’appareil du produit. Ne transportez pas l’unité...
  • Page 7 Chapter 1: Product Overview Package Content ........................... 9 Ordering Information ........................9 System Specifications ......................... 10 Front Panel ..........................11 Rear Panel ........................... 12 Block Diagram ..........................13 Main ............................15 Advanced ............................ 16 Chipset ............................35 Security ............................41 Boot Menu ..........................
  • Page 8 NVA-3000 User Manual Warranty Policy .......................... 53 RMA Service ..........................53 RMA Service Request Form ......................54...
  • Page 9 Chapter 1: Product Overview NVA-3000 is a cost-effective embedded system which adopts Intel® Pentium® Processor N4200 or Intel to provide a high performance with low power consumption structure and Atom® x7-E3950 Processor featured with 8-port PoE (power over Ethernet) Ethernet switch. NVA-3000, a compact design supports many integrated multimedia and IO features such as video, network, serial communication, PoE, especially for Network Video Recorder physical security applications.
  • Page 10 NVA-3000 User Manual Form Factor Desktop Intel® Pentium® Processor N4200 or Intel Atom® x7-E3950 Processor Options Processor (by SKU) Platform CPU Socket Onboard Chipset Security Acceleration Intel® QuickAssist Technology BIOS AMI SPI Flash BIOS Technology LPDDR4 SDRAM On board System Memory Max.
  • Page 11 Chapter 1: Product Overview Hard Disk Tray A hard disk tray to hold a 3.5” HDD Short-press (<1 sec) to start a system reset Long-press (>10 sec) to start a system reset with recovery mode Reset Button For the recovery mode to be started, make sure the Linux driver for this GPIO setting is provided.
  • Page 12 NVA-3000 User Manual Description USB Port 2x USB 3.0 ports GbE Port 2x 10/100/1000Mbps Ethernet ports 8x 10/100Mbos PoE+ ports (802.3af/802.3at) PoE Port With the support for PoE+ standard, this system can offer the power of more than 15.4W ( no more than 30W) to 4 connected devices simultaneously. 2x 8pin terminal block for 4DI/4DO Make sure the Linux driver for this GPIO setting is provided.

  • Page 13: Chapter 2: Motherboard Information

    Chapter 2: Motherboard Information The block diagram indicates how data flows among components on the motherboard. Please refer to the following figure for your motherboard’s layout design.
  • Page 14 NVA-3000 User Manual BIOS is a firmware embedded on an exclusive chip on the system’s motherboard. Lanner's BIOS firmware offering including market-proven technologies such as Secure Boot and Intel Boot Guard technology deliver solid commitments for the shield protection against malware, uncertified sequences and other named cyber threats.

  • Page 15: Chapter 3: Bios Setup

    Chapter 3: BIOS Setup Setup main page contains BIOS information and project version information. Feature Description BIOS Vendor: American Megatrends Core Version: AMI Kernel version, CRB code base, X64 BIOS Compliancy: UEFI version, PI version Information Project Version: BIOS release version Build Date and Time: MM/DD/YYYY Access Level: Administrator / User To set the Date, use <Tab>...
  • Page 16 NVA-3000 User Manual Select the Advanced menu item from the BIOS setup screen to enter the “Advanced” setup screen. Users can select any of the items in the left frame of the screen.
  • Page 17 Chapter 3: BIOS Setup...
  • Page 18 NVA-3000 User Manual Serial port 1 Configuration Feature Options Description Enabled Serial Port Enables or disables Serial Port 1. Disabled Device Settings IO=3F8h; IRQ = 4...

  • Page 19: Cpu Vcore

    Chapter 3: BIOS Setup Feature Description CPU Temp This value reports the CPU temperature. SYS Temp This value reports the System temperature. CPU VCORE This value reports the CPU VCORE. VSB5V This value reports the VSB5V Input voltage. VBAT This value reports the VBAT Input voltage. 3.3V This value reports the 3.3V Input voltage.
  • Page 20 NVA-3000 User Manual Feature Options Description Watch Dog Timer Enabled Enable or Disable Watch Dog function Disabled Timer Count Second Mode Select Second Mode or Minute Mode Mode Minute Mode Timer out Value Watch Dog Timer out Value 0-255...
  • Page 21 Chapter 3: BIOS Setup Feature Options Description Output Low POE GPIO Pin 1 Configure POE GPIO Pin 1. Output High Output Low POE GPIO Pin 2 Configure POE GPIO Pin 2. Output High Output Low POE GPIO Pin 3 Configure POE GPIO Pin 3. Output High Output Low POE GPIO Pin 4...
  • Page 22 NVA-3000 User Manual Feature Options Description Output Low Digital I/O Pin 1 Configure Digital I/O Pin 1. Output High Output Low Digital I/O Pin 2 Configure Digital I/O Pin 2. Output High Output Low Digital I/O Pin 3 Configure Digital I/O Pin 3. Output High Output Low Digital I/O Pin 4...
  • Page 23 Chapter 3: BIOS Setup Feature Options Description Power LED ORANGE Configure Status POWER LED. GREEN CAMERA1 LED Configure CAMERA1 LED . ORANGE CAMERA2 LED Configure CAMERA2 LED. ORANGE CAMERA3 LED Configure CAMERA3 LED . ORANGE CAMERA4 LED Configure CAMERA4 LED. ORANGE CAMERA5 LED Configure CAMERA5 LED .
  • Page 24 NVA-3000 User Manual Feature Options Description COM0 Enabled Console Redirection Enable or Disable. Console Redirection Disabled...
  • Page 25 Chapter 3: BIOS Setup Console Redirection Setting Feature Options Description Terminal Type VT100 ANSI: Extended ASCII char set. VT100+ VT100: ASCII char set. VT-UTF8 VT100+: Extends VT100 to support color, ANSI function keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes.
  • Page 26 NVA-3000 User Manual VT-UTF8 Combo Key Disabled Enable VT-UTF8 Combination Support Enabled Support for ANSI/VT100 terminals Recorder Mode Disabled With this mode enabled only text will be Enabled sent. This is to capture Terminal data. Resolution 100x31 Disabled Enables or disables extended terminal Enabled resolution.
  • Page 27 Chapter 3: BIOS Setup Feature Options Description Intel Virtualization Disabled When enabled, a VMM can utilize the Technology Enabled additional hardware capabilities provided by Vanderpool Technology VT-d Disabled Enable/Disable CPU VT-d Enabled...
  • Page 28 NVA-3000 User Manual Socket 0 CPU Information...
  • Page 29 Chapter 3: BIOS Setup CPU Power Management Feature Options Description EIST Disabled Enable/Disable Intel SpeedStep Enabled...
  • Page 30 NVA-3000 User Manual Feature Options Description Globally Enables or Disables 64bit capable Devices Above 4G Disabled to be Decoded in Above 4G Address Space (Only if Decoding Enabled System Supports 64 bit PCI Decoding). Globally Enables or Disables Hot-Plug support for Enabled the entire System.
  • Page 31 Chapter 3: BIOS Setup Feature Options Description Disabled CSM Support Enables or disables CSM Support Enabled Do Not Launch Controls the execution of UEFI and Legacy Network UEFI PXE OpROM Legacy Do Not Launch Controls the execution of UEFI and Legacy Storage UEFI Storage OpROM...
  • Page 32 NVA-3000 User Manual Feature Options Description SDIO Access Mode AUTO Auto: Access SD device in DMA mode if ADMA controller supports it, otherwise in PIO SDMA mode. DMA: Access SD device in DMA mode. PIO: Access SD device in PIO mode.
  • Page 33 Chapter 3: BIOS Setup Feature Options Description Enables Legacy USB support. Enabled Auto option disables legacy support if no Legacy USB Support Disabled USB devices are connected; Auto Disabled option will keep USB devices available only for EFI applications. This is a workaround for OSes without Enabled XHCI hand-off...
  • Page 34 NVA-3000 User Manual Feature Options Description Disabled Select On Board LAN for enabled PXE boot PXE Function LAN1 function. LAN2...
  • Page 35 Chapter 3: BIOS Setup Select the Chipset menu item from the BIOS setup screen to enter the “Chipset” setup screen. Users can select any of the items in the left frame of the screen.
  • Page 36 NVA-3000 User Manual Feature Options Description 2 GB 2.25 GB Max TOLUD 2.5 GB Maximum Value of TOLUD. 2.75 GB 3 GB...
  • Page 37 Chapter 3: BIOS Setup The OS Selection setting is linked to the status of CSM Support under Advanced > CSM Configuration. Please make sure you select the right option based on the OS used. Feature Options Description Windows Android OS Selection Select the target OS Win7 Intel Linux...
  • Page 38 NVA-3000 User Manual...
  • Page 39 Chapter 3: BIOS Setup...
  • Page 40 NVA-3000 User Manual...
  • Page 41 Chapter 3: BIOS Setup Select the Security menu item from the BIOS setup screen to enter the Security Setup screen. Users can select any of the items in the left frame of the screen. Feature Description If ONLY the Administrator's password is set, it only limits access to Setup and is only asked for when Administrator Password entering Setup.
  • Page 42 NVA-3000 User Manual Feature Options Description Secure Boot is activated when Platform Key(PK) is Attempt Secure Disabled enrolled, System mode is User/Deployed, and CSM Boot Enabled function is disabled. Customizable Secure Boot mode: In Custom mode, Standard Secure Boot Policy variables can be configured by Secure Boot Mode Customized physically...
  • Page 43 Chapter 3: BIOS Setup Key Management Feature Options Description Provision Factory Disabled Allow to provision factory default Secure Boot keys Default keys Enabled when System is in Setup Mode Install Factory Force System to User Mode - install all Factory None Default keys Default keys...
  • Page 44 NVA-3000 User Manual Select the Boot menu item from the BIOS setup screen to enter the Boot Setup screen. Users can select any of the items in the left frame of the screen. Feature Options Description The number of seconds to wait for setup Setup Prompt Timeout activation key.
  • Page 45 Select the Save and Exit menu item from the BIOS setup screen to enter the Save and Exit Setup screen. Users can select any of the items in the left frame of the screen. ■ Save Changes and Reset When Users have completed the system configuration changes, select this option to save the changes and exit from BIOS Setup in order for the new system configuration parameters to take effect.
  • Page 46 NVA-3000 User Manual ■ Restore Defaults Restore default values for all setup options. Select “Yes” to load Optimized defaults. PS: The items under Boot Override were not same with image. It should depend on devices connect on system. PS: The items under Boot Override were not same with image. It should depend on devices connect on system.

  • Page 47: Chapter 4: Hardware Setup

    Chapter 4: Hardware Setup To reduce the risk of personal injury, electric shock, or damage to the equipment, please remove all power connections to completely shut down the device. Also, please wear ESD protection gloves when conducting the steps described hereafter. In light of the motherboard layout arrangement, the installation of the M.2 card, DDR4 memory, and Wireless module should be prior to that of the 3.5”...
  • Page 48 NVA-3000 User Manual 1. Loosen the screw that fixes the hard disk tray latch on the front panel. 2. Pull the tray out. 3. Secure the hard disk on the tray with three screws on each side. Make sure the SATA Connector faces outward.
  • Page 49 Chapter 4: Hardware Setup 4. Insert the tray into the bay and fasten the screw that fixes the hard disk tray on the front panel.
  • Page 50 NVA-3000 User Manual The status explanations of LED indicators on Front Panel are as follows: System LAN1 & LAN2 PoE Power Status Power Activity Link Activity System Power Green The system is powered and running Orange The system is restarting The system is powered off HDD Activity Green...

  • Page 51: Appendix B: Setting Up Console Redirections

    Appendix B: Setting up Console Redirections Console redirection lets you monitor and configure a system from a remote terminal computer by re-directing keyboard input and text output through the serial port. The following steps illustrate how to use this feature. The BIOS of the system allows the redirection of the console I/O to a serial port. With this configured, you can remotely access the entire boot sequence through a console port.
  • Page 52 NVA-3000 User Manual To install the Intel® LAN controller base driver for the Red Hat® and Linux operating system, please visit http://www.lannerinc.com/support/download-center/drivers, enter the product category and download the utility package. For the latest driver update, please visit Intel® download center at https://downloadcenter.intel.com/, use the keyword search or the filter to access the driver’s product page, and then download the latest controller driver as well as the ReadMe document.

  • Page 53: Appendix D: Terms And Conditions

    Appendix D: Terms and Conditions 1. All products are under warranty against defects in materials and workmanship for a period of one year from the date of purchase. 2. The buyer will bear the return freight charges for goods returned for repair within the warranty period; whereas the manufacturer will bear the after service freight charges for goods returned to the user.
  • Page 54 NVA-3000 User Manual When requesting RMA service, please fill out the following form. Without this form enclosed, your RMA cannot be processed.
