- Page 1 Industrial Communications Hardware Platforms for Industrial Computing LEC-6040 V1.1 User's Manual Release Date: 2015-09-09...
-
Page 2: Copyright And Trademarks
Resource Website installed and used in accordance with the instruction manual, may cause harmful interference to radio Lanner http://www.lannerinc.com communications. Operation of this equipment in a residential area is likely to cause harmful interference http://www.lannerinc.com/support/... -
Page 3: Safety Guidelines
EMC Notice Operating Safety • Electrical equipment generates heat. Ambient air temperature may not be adequate to cool equipment to This equipment has been tested and found to comply acceptable operating temperatures without adequate with the limits for a Class A digital device, pursuant to Part circulation. -
Page 4: Table Of Contents
Mechanical Specifications Chapter 2: System Front Panel Rear Panel Block Diagram Chapter 3: Motherboard Information Inside LEC-6040 Motherboard Layout Add-on Card and Backplane Motherboard Jumper and Connector Table Jumper Setting & Connector Pinouts Chapter 4: Hardware Setup Preparing the Hardware Installation... -
Page 5: Chapter 1: Introduction
Microsoft Windows 7 Embedded, OS Support purposes. Window 7, Linux 2.6 NAND Flash Here is the summary of the key features of LEC-6040: 1 x SATA 2.5” HDD/SSD Storage HDD/SSD Support 1 x mSATA storage (leveraged from the Intel® Haswell Core™ inside for high performance... -
Page 6: Package Contents
Package Contents Your package contains the following items: LEC-6040 fanless box PC • Drivers and User’s Manual CD • Notes: if there is any missing item, please contact your dealer immediately for assistance. Ordering Information Intel® Core™ Core™ i5-4402E 2.7 GHz CPU, 4 x Intel®... -
Page 7: Mechanical Specifications
Mechanical Specifications (based on 8 x GbE ports model) button holes SINK 0.4mm FOR NAME PLATE PASTED Unit: mm APPROVED PART LEC-C604 MOLD USER Extrusion RANGE NAME Levis Tsao 0~10 0.15 0.10 0.10 0.10 10~50 0.20 0.15 0.15 0.15 EXAMINED MATERIAL 0.25 0.20... -
Page 8: Chapter 2: System
Front Panel (B1/B3 Types) Description Note F1 DC IN Single 12VDC Power input F2 COM ports 1 x DB9 RS-232 COM ports; COM1 with isolated protection F3 USB 3.0 ports 2 x USB 3.0 Type-A ports F4 LAN 4 or 8 x RJ-45 LAN ports at 10/100/1000 Mbps depending This image is based on the 8-LAN port on the model chosen... -
Page 9: Rear Panel
Front Panel (B2 Type) Description Note F1 DC IN Single 12VDC Power input F2 COM ports 1 x DB9 RS-232 COM ports; COM1 with isolated protection F3 USB 3.0 ports 2 x USB 3.0 Type-A ports F4 LAN 6 x RJ-45 LAN ports at 10/100/1000 Mbps depending This image is based on the 8-LAN port 2 x SFP ports... -
Page 10: Block Diagram
Block Diagram ������������� ������������� ������������� ������������� i5 4400E CL8064701483902 DDR3 ChA PCIE x1 DDR3 ChB x2 FDI x4 DMI PCH QM87 DH82QM87 Full size USB 2.0 x1 Mini-PCIe PIN HEADER LAN1 i210AT PCIE x1 USB 3.0 2.0/3.0 Connector LAN2 i210AT PCIE x1 USB 2.0 LAN3 i210AT... -
Page 11: Chapter 3: Motherboard Information
Chapter 3: Motherboard Information Inside LEC-6040 Add-on Card LEK-EN1 Backplane LEK-P02 Motherboard LEB-6040B LEB-6040B: the motherboard LEK-EN1: the add-on card for additional LAN ports. It comes in either 2 LAN ports or 4 LAN ports type. The card is only available for models with 6 or 8 LAN ports. Please see Ordering Information for details. -
Page 12: Motherboard Layout
Motherboard Layout MPCIE2 RJ1~4 connectors SW1/2 LEDs USB2 COM2 PCIE1 VGA1 SATA1 PWR1 DIMM1 COM1 USB_J1 SPI1 FAN1 CMOS1 LPC1 MPCIE1 KBMS1 DC_IN1... - Page 13 Chipset...
-
Page 14: Add-On Card And Backplane
Add-on Card and Backplane Add-on Card LEK-EN1 Backplane LEK-P02 LEK-EN1: the add-on card for additional LAN ports. It comes in either 2 LAN ports or 4 LAN ports type. The card is only available for models with 6 or 8 LAN ports. Please see Ordering Information for details. LEK-P02 Backplane: the backplane for board-to-board connector... -
Page 15: Motherboard Jumper And Connector Table
Motherboard Jumper and Connector Table Label Descriptions COM2 Front panel serial interface for RS-232 port USB2 Double stacked USB port 1 and 2 on the front panel RJ1~4 4 x RJ45 Ethernet ports on the front panel connectors LEDs LED signals for system activity indicators KBMS1 Keyboard &... -
Page 16: Jumper Setting & Connector Pinouts
Jumper Setting & Connector Pinouts USB Interface (USB2) USB 3.0 port 1 & 2 connector on the front panel CMOS1: This jumper is used to erase data in CMOS. To clear CMOS, first turn off your system and unplug power source. Then, by placing the cap on pin 2 and 3 (short pin 2-3), this jumper can erase the system settings stored in CMOS memory. - Page 17 Internal Serial Interface with RS-232: COM1 Keyboard/Mouse Interface: KBMS1 Description Description Data Carrier Detect (DCD) Data Set Ready (DSR) MSCLK Received Data (RxD) MSDAT Request To Send (RTS) Transmit Data (TxD) KBDAT Clear To Send (CTS) Data Terminal Ready (DTR) Ground Ring Indicator (RI) KBCLK...
-
Page 18: Power Connector
SATA Interface: PWR1 RESET Button: SATA Power Connector Connector SW2 Description SYS_RESET Description VCC12 (12V) Ground Power Connector: Ground DC_IN1 VCC (5V) FAN connector: FAN1 Description VCC12 (12V) Ground Description Ground +12V FAN status ATX Power Button: Connector SW1 Description PANSW... - Page 19 Mini PCIe Connector: MPCIE1 Mini PCIe Connector: MPCIE2 MPCIE1:mini PCIe Slot /w SIM (Full Size) MPCIE2:mini PCIe Slot (half-sized) with USB and mSATA signals Description Description WAKE# +3.3V RSVD RSVD +1.5V CLKREQ# RSVD RSVD Description Description RSVD RSVD WAKE# +3.3V RSVD RSVD RSVD...
-
Page 20: Chapter 4: Hardware Setup
Chapter 4: Hardware Setup Installing the System Memory Preparing the Hardware Installation The motherboard supports DDR3L memory at1333/1600 WARNING: MHz, up to 2GB, low-voltage, unbuffered and non-ECC. Please make sure the DDR3L SO-DIMM module in use To reduce the risk of personal injury, electric meet the specifications. -
Page 21: Installing A Disk Drive (Hdd/Ssd)
Installing a Disk Drive (HDD/SSD) 4. Connect the SATA cable to the SATA signal and power Locate the disk drive bay attached on the internal connectors on the board. Remember that the board sup- side of the top cover. ports 4-pin SATA power connector. Please use a matching connector. -
Page 22: Connecting Power
Connecting Power Mounting LEC-6040M by DIN Rail LEC-6040 is designed with a DIN Rail mounting bracket at the rear of the product. Connect the LEC-6040 to a 12Vdc power source. The power source comes from the AC/DC Adapter through a Phoenix contact. -
Page 23: Installing The Ear Mount Brackets
Installing the Ear Mount Brackets 1. Prepare the ear mount bracket set 4. Completed. 2. Align the ear mount bracket to LEC-6040 and make sure the two screw holes are aligned. 3. Apply screws to have the brackets fixed. Do the same for both sides. -
Page 24: Installing The Wall Mount Brackets
Installing the Wall Mount Brackets 1. Prepare the wall mount bracket set 2. Align the wall mount bracket to LEC-6040 and make sure the two screw holes are aligned. 3. Apply screws to have the brackets fixed. Do the same for both sides. -
Page 25: Appendix 1: Programming Watchdog Timer
Appendix 1: Programming Watchdog Timer A watchdog timer is a piece of hardware that can be used to automatically detect system anomalies and reset the processor in case there are any problems. Generally speaking, a watchdog timer is based on a counter that counts down from an initial value to zero. -
Page 26: Appendix 2: Terms And Conditions
Appendix 2: Terms and Conditions RMA Service Warranty Policy Requesting a RMA# All products are under warranty against defects in materials and workmanship for a period of one year To obtain a RMA number, simply fill out and fax the from the date of purchase.
