- Page 1 Industrial Communications LEC-6021A User Manual Version: 1.3 Date of Release: 2017/06/13...
-
Page 2: Online Resources
Warning: This exclamation point indicates that there is a caution or warning and it is something that could damage your property or product. Online Resources The listed websites are links to the on-line product information and technical support. Resources Lanner http://www.lannerinc.com Product Resource http://www.lannerinc.com/download-center http://eRMA.lannerinc.com Copyright and Trademarks This document is copyrighted, ©... -
Page 3: Safety Guidelines
LEC-6021A User Manual Compliances and Certification CE Certification This product has passed the CE test for environmental specifications. Test conditions for passing included the equipment being operated within an industrial enclosure. In order to protect the product from being damaged by ESD (Electrostatic Discharge) and EMI leakage, we strongly recommend the use of CE compliant industrial enclosure products. - Page 4 Lanner Electronics Inc. shall not be held liable y for any losses resulting from insufficient strength for supporting the unit or use of inappropriate installation components.
-
Page 5: Revision History
LEC-6021A User Manual Revision History Version Date (YYYY/MM/DD) Description 2014/12/26 Preliminary 2015/05/26 Official release Updated motherboard 2016/04/19 Added GND and Reset button on side panels Modified installation images 2017/04/07 Update operating temperature Updated operating temperature spec Updated input voltage spec... -
Page 6: Table Of Contents
Chapter One: Introduction Table of Contents Package Contents System Specifications System Drawing Block Diagram Front Components Side Components Rear Components Connectors & Jumpers Locations Connectors and Jumpers List Jumper Settings Connector Pinouts Preparing the Hardware Installation Installing the System Memory Installing a CompactFlash Card Installing Heat-sinks Connecting Power... -
Page 7: Package Contents
LEC-6021A User Manual Thank you for choosing Lanner LEC-6021A rugged industrial system. This box PC is an industrial cyber security appliance featuring ESD-protected serial communication and LAN ports. LEC-6012A is compliant with IEC 61850-3 for power substation automation and suitable for harsh environment. Other useful features of... -
Page 8: System Specifications
Chapter One: Introduction System Specifications Processor Options Intel® Atom™ N2600 1.6 GHz Chipset Intel NM10 BIOS AMI SPI Flash ROM Sockets 1 x 204-pin DDR3 SODIMM socket System Memory Max. Capacity 2 GB USB 2.0 compliant hosts x 2, Type A connector Operating System Support Linux 2.6, Windows 7 &... -
Page 9: System Drawing
LEC-6021A User Manual System Drawing Mechanical dimensions of LEC-6021A Unit: mm... -
Page 10: Block Diagram
Chapter Two: System Components Block Diagram The block diagram depicts the relationships among the interfaces and modules on the motherboard. -
Page 11: Front Components
LEC-6021A User Manual Front Components Component Description Serial ports COM with RS-232 Serial Ports COM The upper one is TX (Data transmitting in yellow), and the lower one is RX (Data receiving in yellow) for serial port status. Two SFP Ports The two fiber ports are enabled by Intel I210IS. -
Page 12: Side Components
Chapter Two: System Components Side Components Component Description Dual 18~48Vdc power input through 6xpin Phoenix DC-In (power) 1x6 Pin Phoenix Contact Contact connector Connector with power failure relay Power failure relay is supplied. Reset Reset button... -
Page 13: Rear Components
LEC-6021A User Manual Rear Components As the rear panel is dedicated for DIN Rail installation, there are no I/O components on it. -
Page 14: Connectors & Jumpers Locations
Chapter Three: Motherboard Information Connectors & Jumpers Locations The following picture highlights the location of system jumper settings and connectors of the mainboard. Please refer to Connectors and Jumpers List for more details. CN2 (2x USB ports) -
Page 15: Connectors And Jumpers List
LEC-6021A User Manual Connectors and Jumpers List The table below lists the function of each of the board jumpers and connectors by labels shown in the above section. The next section in this chapter gives pin definitions and instructions on setting jumpers. -
Page 16: Jumper Settings
Jumper Settings PWR1: Power button connector in 2-pin male pin header Description Short pin1-2 Power On/Off system NC (non-connected, default) Normal RST2: Reset Button RST1: HW/SW Reset Select Description Short pin1-2 Software reset Short pin 2-3 (default) Hardware reset CLR1: Clear CMOS via 2-pin male pin header Description Short pin1-2 Clear CMOS... -
Page 17: Connector Pinouts
Chapter Three: Motherboard Information Connector Pinouts VGA1: VGA Connector Description Description CON_RED CRT_ON CON_GREEN GND_VGA CON_BLUE GND_VGA CON_HSYNC GND_VGA CON_VSYNC GND_VGA CON_DDC_DAT CON_DDC_CLK COM1: Serial Port 1 Pin Header Connector Description Description COM2_R_RXD COM2_R_TXD COM1_2_GND KBMS1: Keyboard & Mouse Connector Description Description P5VS... - Page 18 LEC-6021A User Manual CON1: SATA Power Connector Description Description P5VS SATA1: SATA Signal Connector Description Description SATA_TX1_C_DP SATA_TX1_C_DN SATA_RX1_DN SATA_RX1_DP CN2: Double-stacked USB Connectors Description Description USB power USB1N_REAR_L USB1P_REAR_L USB power USB0N_REAR_L USB0P_REAR_L RJ2 Connector: Double-stacked RJ-45 LAN Ports...
- Page 19 Chapter Three: Motherboard Information RJ1 Connector: Double-stacked RJ-45 LAN Ports with LAN Bypass Description Description MDI0+_3 MDI0+_4 MDI0-_3 MDI0-_4 MDI1+_3 MDI1+_4 MDI1-_3 MDI1-_4 MDI2+_3 MDI2+_4 MDI2-_3 MDI2-_4 MDI3+_3 MDI3+_4 MDI3-_3 MDI3-_4 Power Power SFP1,SFP2 Connectors Description Description SFP0_TX_FAULT SFP0_TX_DIS SFP0_I2C_SDA SFP0_I2C_SCL SFP0_MOD_ABS SFP0_RS0...
-
Page 20: Preparing The Hardware Installation
LEC-6021A User Manual Preparing the Hardware Installation Warning: To reduce the risk of personal injury, electric shock, or damage to the equipment, please make sure the device is totally powered off and without any power source connected. Turn the device around (facing the rear panel) and then turn it upside down. -
Page 21: Installing The System Memory
Chapter 4: Hardware Setup Installing the System Memory The motherboard comes with one DDR3 SO-DIMM socket. Please follow the steps below for installation. Align the memory module’s key with the SO-DIMM socket’s key. Install the SO-DIMM until firmly seated. Place the heat sink onto the memory module. Note: SO-DIMMs for installation should meet the required frequency which is 1066/1333 MHz for this system. -
Page 22: Installing A Compactflash Card
LEC-6021A User Manual Installing a CompactFlash Card The system provides one CompactFlash slot. Follow the procedures below to install a CompactFlash card. Align CompactFlash and the card slot. Insert the CompactFlash into the connector until firmly seated. Note: The device has an error proof design so that the card will not be inserted if it is in the wrong orientation. -
Page 23: Installing Heat-Sinks
Chapter 4: Hardware Setup Installing Heat-sinks The system comes with heat sink thermal solutions on the internal side of the top compartment. 1. Install the heat sinks onto the circled areas. 2. The heat sinks are provided as thermal solutions for SFP fiber I/O connectors, Super I/O chip, CF and other components on the main board. -
Page 24: Connecting Power
Note: This product is intended for use with a UL-listed ITE DC power source, rated 18-48Vdc, 3.33-1.25A, operating at 70 C/min Tma and at 2000m operation altitude. If you need further assistance with purchasing the appropriate power source, please contact Lanner Electronics Inc. for more information. -
Page 25: Din Rail Mounting
Chapter 4: Hardware Setup DIN Rail Mounting The system can be mounted via DIN Rail method with included DIN Rail kit. 1. Attach the DIN Rail kit to the rear of the system with 3 screws. 2. Hang the system onto a rail. Aim the hook of the kit into the DIN Rail until it is totally fixed. Note: After the unit is mounted, be sure to check that the installation provides strong and appropriate support and that each part is assembled correctly. -
Page 26: Wall-Mounting
LEC-6021A User Manual Wall-Mounting The system can be mounted via the provided wall mounting brackets and screws. 1. If the DIN Rail kit is already mounted on rear panel, remove it. 2. On both side panels of the unit, attach the brackets using the provided screws. Please note that there are two types of brackets: one with the two holes (for unit fixation) aligned with each other and the other with two unaligned holes. - Page 27 Appendix A: Programming Watchdog Timer A watchdog timer is a piece of hardware that can be used to automatically detect system anomalies and reset the processor in case there are any problems. Generally speaking, a watchdog timer is based on a counter that counts down from an initial value to zero.
-
Page 28: Warranty Policy
LEC-6021A User Manual Warranty Policy 1. All products are under warranty against defects in materials and workmanship for a period of one year from the date of purchase. 2. The buyer will bear the return freight charges for goods returned for repair within the warranty period;... - Page 29 Appendix B: Terms and Conditions...
