Applies only to products with serial number 1804-61001 and later
COM PLET E U SER MANUAL
B LU EWAT ER SP IRI T
WAT ER PU RIFIER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spirit Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bluewater Spirit Series

Summary of Contents for Bluewater Spirit Series

  • Page 1 Applies only to products with serial number 1804-61001 and later COM PLET E U SER MANUAL B LU EWAT ER SP IRI T WAT ER PU RIFIER...

  • Page 2: Table Of Contents

    CONT EN TS IN TROD U CT ION About this manual Limited warranty Environment information Disposal Symbols Safety instructions Safety information PRO D U CT OV ERVIEW Models Spirit outside Spirit inside and replacement components Move the water purifier SYS T E M OV ERVIEW System description Intended use Leak protection system...

  • Page 3: Introduct Ion

    NSF/ANSI and meets the applicable published 58 and CSA Standard B483.1. It has also standard. been tested and certified against NSF/ ANSI 372. © Bluewater Group 2019...

  • Page 4: Safety Instructions

    Safety information Install the water purifier in accordance with local regulations. If you are not sure, contact a Bluewater dealer for aid. Bluewater has no responsibility for installation of the water purifier. Do not drink the water when the service light shows that it is not clean.
  • Page 5 Installation must comply with applicable local plumbing codes and regulations. Only connect the water purifier to one clean water faucet supplied by Bluewater. Do not connect it to other pipes, tanks or dishwashers. Do not put or keep objects on top of the water purifier.

  • Page 6: Pro D U Ct Ov Erview 0

    P RODUCT OVERVIEW Models Spirit 300 Electronically controlled Bluewater faucet Model Spirit 300Cp Pressure controlled, compatible with Faucet adapted to reverse household appliances osmosis Spirit outside 2 3 4 10 11 12 13 Figure 1. Spirit outside Description Description Control panel...

  • Page 7: Control Panel

    The water quality has decreased. Wait for the green light. Yellow: The water purifier has stopped. Look at the control panel. FILTER button SERVICE button Data plate The data plate is located behind the filter. Figure 4. Data plate © Bluewater Group 2019...

  • Page 8: Move The Water Purifier

    Move the water purifier Always transport the water purifier upright. Install according to “Installation” on page 12. Put the water purifier into storage if it will not be used for 4 months or more, or if it is to be disconnected from the water and electricity for >5 days, see “Put into storage” on page 24.

  • Page 9: Sys T E M Ov Erview 0

    The electronically controlled Spirit 300 is intended to produce the quantity of water that is normally required for cooking and drinking in a household. The pressure controlled Spirit 300Cp can be connected to other devices such as dishwashers. © Bluewater Group 2019...

  • Page 10: Leak Protection System

    Leak protection system A sensor at the bottom of the water purifier senses water leaks. If there is a leak, the feed water supply is stopped. The water purifier cannot be started again until the leak has been repaired. Low pressure protection If Spirit stops because of low pressure, the cause of the low pressure must be removed.
  • Page 11 The water purifier in standby mode. Spirit is connected to water and power and it is more than 6 hours since the last flush. Flush after maximum operation time 15 minutes. The next production cycle can be started immediately after completed flush. © Bluewater Group 2019...

  • Page 12: In S Tallatio N

    INSTAL L ATI ON Install the water purifier in accordance with local regulations. If you are not sure, contact a Bluewater dealer for aid. Bluewater has no responsibility for installation of the water purifier. Install the water purifier in a vertical position on a horizontal surface.

  • Page 13: Unpack Spirit

    Make sure that Spirit shows no signs of damage, and that no accessories are missing. Tell the Bluewater dealer about missing parts, damage and other problems. Tell the transport company immediately if Spirit is damaged during transport.

  • Page 14: Install Clean Water Faucet

    Install clean water faucet Make sure there is enough space for the plastic nut B underneath the sink. Measurement A must be at least 25 mm. Make sure there is enough space for the faucet above the sink. Spirit 300 Ø...

  • Page 15: Install Drain Water Connection

    Figure 14. Install drain water connection Connect the water purifier Do not connect the clean water hose to equipment before Spirit has been flushed. 19 mm Spirit 300 3/4” 3/4” Figure 15. Connect the water purifier © Bluewater Group 2019...

  • Page 16: Flush Spirit

    Flush Spirit Do not drink the water when the water purifier flushes. It is not safe to use. The water purifier should always be flushed: • when it is new and has not been used • when it is installed again after storage/freeze protection •...

  • Page 17: M Ai Nte Nance

    Do a check for leaks See “Do a check for leaks” on page 16. Repair leaks 10 mm (1/2”) Figure 18. Repair leaks Wipe off condensation from base plate Figure 19. Wipe off condensation from base plate © Bluewater Group 2019...

  • Page 18: Each 4-6 Months

    The descaling product is harmful. Keep it where children cannot get it. Clean your hands when you have used it. Order the descaling product from a Bluewater dealer. Frequency depending on water quality and usage! To extend the water purifier lifetime: Descale Spirit with 6 month intervals or when the flow is decreased.
  • Page 19 20 s 10 h 10 s ZH EU 45 min Figure 20. Descale and flush © Bluewater Group 2019...
  • Page 20 Replace prefilter Replace the filters after what comes first of 4-6 months or 18 925 l (5 000 gal) of purified water. Order filters from a Bluewater dealer. 5-7 s 60 min 90 s 2-4 s Figure 21. Replace prefilter...

  • Page 21: Each Year

    The grid filter in the feed water connection catches larger particles. If the flow is decreased or if Spirit makes a noise, the grid filter can be blocked. 3 min Figure 22. Clean the grid filter © Bluewater Group 2019...
  • Page 22 Use disinfectant to clean the system Disinfectant is harmful! Keep it where children cannot get it. Clean your hands when you have used it. Use sodium hypochlorite (NaClO) without added color or fragrance additives. Disinfect the water purifier when the water tastes or smells bad. 5-7 s 60 min 700 ml...
  • Page 23 10 s ZH EU 45 min Figure 23. Use disinfectant to clean the system, and flush © Bluewater Group 2019...
  • Page 24 Put the water purifier into storage if it will not be used for 4 months or more, or if it is to be disconnected from the water and electricity for >5 days. Order the preserving agent from a Bluewater dealer. 100% 2 l + 2 l (~0.5 + 0.5 gal)
  • Page 25 (-22°F) Figure 24. Put into storage Reinstall after storage Preserving agent is harmful! Keep it where children cannot get it. Clean your hands when you have used it. 48 h +5°C Spirit 300 19 mm 3/4” © Bluewater Group 2019...
  • Page 26 10 s ZH EU 45 min Figure 25. Reinstall after storage and flush Complete User manual...

  • Page 27: Tec H Nical In Form At Ion

    < 0.5/< 0.3 (< 0.5/< 0.3) < 0.5/< 0.3 (< 0.5/< 0.3) Manganese Mn [mg/l (ppm)] < 0.2 (< 0.2) < 0.2 (< 0.2) Chlorine Cl2 [mg/l (ppm)] < 1.0 (< 1.0) < 1.0 (< 1.0) © Bluewater Group 2019...

  • Page 28: T Roub L Eshootin G

    The filter must be replaced. the faucet is on. 4 The SERVICE light The water quality has decreased, Contact Bluewater to replace the flashes, and the green but is safe to drink. The water membrane. light on the faucet is purifier will stop soon, see 5.
  • Page 29 Symptom Cause Solution Spirit 300: The faucet There is a problem with the Contact your Bluewater dealer. light is not on. electronic faucet. The faucet cable is not Make sure that the faucet cable connected. and connector are connected. The flow rate from the The water purifier needs to be See “Descale”...
  • Page 30 Complete User manual...
  • Page 31 © Bluewater Group 2019...
  • Page 32 Bluewater is a world leading water purification company. Headquartered in Stockholm, Sweden, the company helps people and businesses globally enjoy the health and wellbeing benefits of cleaner, healthier tap water. Bluewater innovates, makes and sells compact water purifiers that harness the company’s patented reverse...
