- Page 1 Code 101600 SX2.7 Mill Drill AT&M: 09/10/2015...
-
Page 3: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTION READ ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS TOOL Operator COMMON SENSE AND CAUTION ARE FACTORS WHICH CANNOT BE BUILT INTO ANY PRODUCT. THESE FACTORS MUST BE SUPPLIED BY THE OPERATOR. PLEASE REMEMBER: 1. When using electric tools, machines or equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury. - Page 4 IF THERE IS ANY QUESTION ABOUT A CONDITION BEING SAFE OR UNSAFE, DO NOT OPERATE THE TOOL! Grounding Instructions This machine has a three-prong plug, the third prong is the ground. Plug this cord only into a three-prong receptacle. Do not attempt to defeat the protection the ground wire provides by cutting off the round prong.
- Page 5 FEATURE Base Cross feed handwheel Long worktable Fuselage (with protect cover) Drill chuck with arbor Protective dust guard assembly Spindle sleeve locking handle Micro switch assembly Depth display Touch switch panel Electric control box Speed display Emergency stop switch Spindle box cover Fine feeding handle Spindle box Vertical feed handwheel...
-
Page 6: Mounting The Machine
Installation CAUTION! DO NOT ATTEMPT TO USE THE MACHINE UNTIL INSTALLTION IS CAMPLETED, AND ALL PRELIMINARY CHECKS HAVE BEEN MADE IN ACCORDANCE WITH THIS MANUAL. MOUNTING THE MACHINE The machine should be mounted on a strong, heavy workbench, of sufficient height so that you do not need to bend your back to perform normal operations. - Page 7 Operation 1. Before starts to use this machine, operator should go through the instructions carefully so as to acquaint with the construction of the machines, the functions of the various controls and also the driving systems. 2. This machine uses touching button (see operation panel below), operating steps refer to the flow chart.
- Page 8 same as press the “+” button. 5. Press ‘Stop” button (the red and oval button is “0”), spindle will stop running, if press ‘Start’ button now, spindle runs to the speed last setting automatically. When you operate the mill machine encounter emergency you can press the “Emgency stop switch”...
- Page 9 Parts drawing ( 1 / MT3 ) --the spindle taper is MT3...
- Page 10 Parts list ( 1 / MT3 ) --the spindle taper is MT3 Drawing No. Description Q'ty XN3A0201 spindle box GB 818-85 - M4 x 6 cross recessed small pan head screw H type M4*6 X3C0219 spindle below oil seal ring I X20206 B16 taper shank GB/T 297-94 - 32907...
- Page 11 Parts list ( 1 / MT3 ) --the spindle taper is MT3 Drawing No. Description Q'ty 1-44 X3C021100 locking bolt assembly 1-45 GB 119-86 - A 3 x 10 round pin A 3*10 1-46 GB 301-84 - 8106 thrust ball bearing 8106 1-47 GB 278-89 - 80106 deep groove ball bearing 80106...
- Page 12 Parts drawing ( 3 )
- Page 13 Parts list (3) --- note: The no. With “*” means the part showing in metric. Drawing No. description Q'ty XN3A0901 column 3-2* XN3A0903A metric rise and down leadscrew 3-3* XN3A0908A metric rise and down locking nut 3-4* XN3A0907A metric rise and down leadscrew nut XN3A0904 column nut support XN3A0911...
- Page 14 Parts drawing 4...
- Page 15 Parts list (4) --- note: The no. With “*” means the part showing in metric. Drawing No. description Q'ty X31136 the left bracket cover XN3A1106 left cover X31131 longitudinal leadscrew rod bracket left sleeve XN3A1102 work table 4-5* XN3A1113A metric longitudinal leadscrew nut XN3A1103 saddle XN3A1101...
- Page 16 Parts drawing 5...
- Page 17 Parts list 5 (Note: some type without the protective guard assembly) Drawing No. Description Q'ty GB 70-85 - M4 x 10 hexagon socket head cap screw M4*10 GB 70-85 - M4 x 12 hexagon socket head cap screw M4*12 XN3A2304 connect plate X12304 block...
- Page 18 Circle drawing (only for 230V) according to your choice...
- Page 20 Normal wear and tear; misuse, abuse and neglect are excluded and the machine should not have been engineering machines, Axminster Air compressors and Air Tools, and bench top grinders - no modified in any way. Please do not attempt to service the product without first contacting us; we are registration necessary just proof of purchase.
