- Page 1 & automation TREAE SERIES ELECTRICAL ACTUATOR USER MANUAL NOVEMBER / 2018 PLEASE READ THE INSTRUCTIONS BEFORE USE www.smstork.com...
-
Page 2: Table Of Contents
5. PRODUCT LIFE ....................................17 6. PRODUCT CARE AND MAINTENANCE ........................18 a. Troubleshooting ..................................19 7. PRODUCT SPARE PARTS ..............................19 8. GENERAL CARE, REPAIR AND CLEANING .......................20 9. PRODUCT SHIPMENT ................................20 10. WARRANTY CONDITIONS ............................20 SMS-TORK Endüstriyel Otomasyon Ürünleri San. Tic. Ltd. Şti. -
Page 3: Purpose Of Document
This torque makes the valve open or close. Gearbox provides a steady torque while turning. TREAE series electric actuators are produced as “On / Off Controlled Electric Actuator “. Electrical actuators manufactured by SMS-TORK do not use asbestos, PCB, mercury and other prohibited chemicals. -
Page 4: Product Coding System
Product Coding System There may not be all the variations at the product coding table. For more details, please contact us. Table 1. Product Coding System SMS-TORK Endüstriyel Otomasyon Ürünleri San. Tic. Ltd. Şti. -
Page 5: Product And Part Pictures
c. Product and Part Pictures Fig 2. TREAE Electrical Actuator Valve Connection Point Fig 1. TREAE Electrical Actuator Motor Position Indicator Manual Control Lever Gear Cams and Limit Switches Control Card Fig 3. Electrical Actuator Parts www.smstork.com... -
Page 6: Labeling Details
ON - OFF 230V AC 50Hz Serial No : Power TREAE60-17-0001 6W 20 VA Protection Class Operation Time IP67 14 SEC / 90 Ambient Temperature : Option C, +60 Fig 4. Label Details SMS-TORK Endüstriyel Otomasyon Ürünleri San. Tic. Ltd. Şti. -
Page 7: Product Operation
3. PRODUCT OPERATION When supply voltage (100 - 240 VAC or 24VAC/DC) applied to the electrical actuator, motor and gearbox produce a rotary force. This force makes the valve acting. According to this act valve is opened or closed. a. Storage Conditions Electrical actuators must be stored in clean, dry and cool ambient. -
Page 8: Product Installation
Valve Mounting Electrical actuators are manufactured so that the valve can be mounted according to ISO 5211 standard. Ø 70 Ø 50 Ø 36 Fig 5. ISO5211 Mounting Surface SMS-TORK Endüstriyel Otomasyon Ürünleri San. Tic. Ltd. Şti. - Page 9 Fig 6. Valve Mounting www.smstork.com...
- Page 10 Fig 7. Valve Mounting with Bracket SMS-TORK Endüstriyel Otomasyon Ürünleri San. Tic. Ltd. Şti.
-
Page 11: Manual Working
b. Manual Control Manual Control Lever Fig 8. Manual Control Lever There are two different manual control ways. First way is with manual control lever, and the second way is by buttons on PCB card. 1) Controlling with manual control lever is only recommended to use in case of emergen- cy as power failure or interreptuion of the control signal. -
Page 12: Adjusting Cam And Limit Switches
CLOSE LIMIT SWITCHES 3.(SW1) and 4. (SW3), and press the CLOSE switch. After that, 3. and 4. cams are squeezed and fastened. Follow same instructions for OPEN position. At this time, 1. (SW4) and 2. (SW2) cams position are adjusted. SMS-TORK Endüstriyel Otomasyon Ürünleri San. Tic. Ltd. Şti. -
Page 13: Technical Dimensions
d. Technical Dimensions Ø 70 Ø 50 Ø 36 165,30 Fig 10. TREAE Electrical Actuator ABC Measures www.smstork.com... - Page 14 Valve way is open. Switch 1 Stop Close Valve way is in the middle. Open Valve way is close. Switch 2 Stop Close Valve way is in the middle. Table 2. LED meanings SMS-TORK Endüstriyel Otomasyon Ürünleri San. Tic. Ltd. Şti.
-
Page 15: Wiring Schemes
e. Wiring Schemes 100 - 240 VAC On-Off Wiring Schemes www.smstork.com... - Page 16 24 VDC / VAC On-Off Wiring Schemes SMS-TORK Endüstriyel Otomasyon Ürünleri San. Tic. Ltd. Şti.
-
Page 17: Warnings
h. Warnings If electrical actuator’s wiring is damaged, it must be changed by producer company, certificated service or someone having technical qualification, for preventing any dangerous conditions, If the product is to be used in outdoor, explosive or in environments where harmful animals such as mice live, It is necessary that the supply cables and the connection materials have the appropriate specifications (armor-plated, atex, etc.). -
Page 18: Product Care And Maintenance
During both installation and maintenance be careful about sensitive inner parts. They must not be damaged. Before and after any maintenance electrical wirings must be controlled, electrical precautions must be taken; valve must be tested if it is working proper with actuator. SMS-TORK Endüstriyel Otomasyon Ürünleri San. Tic. Ltd. Şti. -
Page 19: Troubleshooting
Electrical actuators’ spare parts are; • Gears • Motor • Electronic Control Cards • Position Indicator • AC-DC Converter You must choose spare parts according to your actuator model. For supplying spare parts and detailed information please contact to SMS TORK. www.smstork.com... -
Page 20: General Care, Repair And Cleaning
SMS-TORK Endüstriyel Otomasyon Ürünleri San. Tic. Ltd. Şti. - Page 21 to the remaining warranty period of the purchased products. 5)Free repair and product exchange obligations will be annulled under the following conditions: a) If the product becomes faulty due to use contrary to the terms or conditions stated in the user guide, b) If the product serial number has been altered or removed c)The warranty labels have been destroyed, d) If the product has been opened, used, or previously repaired by unauthorized persons,...
- Page 22 SECTOR LEADER WITH 30 YEARS EXPERIENCE SMS-TORK Endüstriyel Otomasyon Ürünleri San. Tic. Ltd. Şti.
