Description:

The Model LC200 consists of an electronic
control and an electronic light sensor interact-
ing. The unit offers separate control of two
lighting zones, each with user settable on/off
light level setpoints. The Electronic control
also offers two digital inputs which will accept
a contact closure from any TORK Timer(s),
or existing EMS system to provide for inde-
pendent time-of-day override if required.

Features:

Installation:

1. Remove the Control from its enclosure,
2. Mount the enclosure at eye level using
MLI-119(B)
1 GROVE ST., MT. VERNON, NY 10550 TEL: 914-664-3542
MODEL LC200
Dual Stage Lighting Controller
DESCRIPTION,
INSTALLATION & OPERATION
Single electronic light sensor with swivel
(Model EPC-1) which can be mounted up
to 1000 feet from controller
Dual outputs with independent adjustment
from 2 to 100 footcandles
Two independent "Time-of-Day" inputs
30 second delay on start-up
Power-On status indicator
Load status indication for each load
push tab to right and swing unit to left and
remove.
screws or other suitable fastening device.
TORK
TORK
FAX: 914-664-5052
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tork LC200

  • Page 1 Dual Stage Lighting Controller DESCRIPTION, INSTALLATION & OPERATION Description: The Model LC200 consists of an electronic control and an electronic light sensor interact- ing. The unit offers separate control of two lighting zones, each with user settable on/off light level setpoints. The Electronic control...
  • Page 2 NOTE: Disconnect all external power before wiring to prevent electrical shock or damage to equipment. Wiring must com- ply with appropriate codes. 3. KO’s top, bottom and side (1/2” and 3/4”) a. Use bottom or side KO’s for Input power, and load wiring. See wiring dia- gram for connection.
  • Page 3 WIRING DIAGRAMS Do not apply any external voltage to terminals TOD1, C, TOD2, or EPC . For time of day operation, connect dry contact closure. *See note 3b. LIGHT LEVEL STAGE 1 STAGE 2 POWER STAGE 1 STAGE 2 For 120 VAC Operation NEUT 120V 240V...
  • Page 4 The two relays can be remotely overridden by attaching a closed dry-contact switch between the “C” and the appropriate “TOD” contact. Temperature Range: – 40°F to 140°F – 40°C to +60°C TORK ® 1 GROVE ST., MT. VERNON, NY 10550 TEL: 914-664-3542 FAX: 914-664-5052...
