Goodman GSC13 Series Wiring Diagram

Standard Features
Quiet condenser fan system
For use with R-22 refrigerant;
charged with inert gas for shipping
R-22 piston kit included
Brass liquid and suction service
valves with sweat connections
Contactor with lug connections
Ground lug connection
ETL Listed
SS-GSC13
Cabinet Features
Louver design sound control top
Steel louver coil guard
Heavy-gauge galvanized-steel cabinet
Attractive Architectural Gray powder-paint
When properly anchored, meets the 2010
Florida Building Code unit integrity
requirements for hurricane-type winds
(Anchor bracket kits available.)
* Complete warranty details available from your
local dealer or at www.goodmanmfg.com.
www.goodmanmfg.com
GSC13
S S A C
plit yStem ir
13 Seer / r-22
1½
Contents
Nomenclature ....................................... 2
.......................... 3
Expanded Cooling Data ....................... 4
AHRI Ratings ....................................... 18
Dimensions ......................................... 18
Wiring Diagram .................................. 19
Accessories .......................................... 20
onditioner
5 t
to onS
2/14
Supersedes 11/13
