Owner's Manual
Model No.
16004801500
- Assembly
- Operation
- Adjustments
- Parts
- Warranty
CAUTION:
You must read and
understand this
owner's manual
before operating
unit.
Keep this manual for
future reference.
Serial number
Write the serial
number in the space
above for reference.
Serial number can be
found at the front
bottom section of the
Treadmill.
PLEASE CAREFULLY READ THIS ENTIRE MANUAL BEFORE
OPERATING YOUR NEW TREADMILL!
Advertisement
Table of Contents
Related Manuals for Dyaco Canada XTERRA TR150
Summary of Contents for Dyaco Canada XTERRA TR150
- Page 1 Owner’s Manual Model No. 16004801500 - Assembly - Operation - Adjustments - Parts - Warranty CAUTION: You must read and understand this owner’s manual before operating unit. Keep this manual for future reference. Serial number Write the serial number in the space above for reference.
-
Page 2: Table Of Contents
Training Guidelines..................26 Manufacturer’s Limited Warranty…………………………………………….… 32 ATTENTION THIS TREADMILL IS INTENDED FOR RESIDENTIAL USE ONLY AND IS WARRANTED FOR THE APPLICATION. ANY OTHER APPLICATION VOIDS THIS WARRANTY IN ITS ENTIRETY. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... -
Page 3: Before You Begin
If you have any questions or problems with the parts included with your XTERRA TR150 Treadmill, please do not return the product. Contact us FIRST! If a part is missing or defective call us toll free at 1-888-707-1880. -
Page 4: Important Safety Instructions
3 metres safe clearance on all sides of the treadmill while in use. Keep the treadmill indoors, away from moisture and dust. Do not put the treadmill in a garage, covered patio or near water. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... - Page 5 Read all instructions before using any fitness equipment. We assume no responsibility from personal injury or property damage sustained by or through the use of this product. SAVE THESE INSTRUCTIONS - THINK SAFETY! Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
-
Page 6: Important Electrical Instructions
Pushing harder is not going to make the unit go faster or slower. If you feel the buttons are not functioning properly with normal pressure, contact your dealer. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... -
Page 7: Assembly Instructions
Remove only the hardware for the step you are currently assembling to avoid confusion and mix ups. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... - Page 8 Ø8 × Ø23 × 1.5T (6pcs) (12pcs) (6pcs) Flat Washer Button Head Socket Bolt Curved Washer #105. Lubricant #40. Safety Key (1pc) (1pc) #104. Combination M5 Allen Wrench & Phillips Head Screwdriver (1pc) Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
- Page 9 Socket Bolts (87), 4pcs of Ø8 × Ø18 × 1.5T Flat Washers (79) and 2pcs of Ø8 × Ø23 × 1.5T Curved Washers (88)by using the Combination M5 Allen Wrench & Phillips Head Screwdriver (104). (Please install the screw without tightening it.) Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
- Page 10 Socket Bolts (87), 2pcs of Ø8 × Ø18 × 1.5T Flat Washers (79) and 4pcs of Ø8 × Ø23 × 1.5T Curved Washers (88)by using the Combination M5 Allen Wrench & Phillips Head Screwdriver (104). NOTE: Please tighten all screws after the assembly is complete. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
-
Page 11: Folding/Transport Instructions
Step: Hold the deck with one hand and pull the knob outward with the other to free the shaft out of the deck and bring the deck down slowly to the floor. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... - Page 12 Relocation Lean the treadmill backward so that the transport wheels touch the floor to move the treadmill. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
- Page 13 Remove the Step Up Frame Pop Pin. Step 3 Select the Adjustment Foot Pad hole, insert the Step Up Frame Pop Pin. (For the left and right Adjustment Foot Pad, make sure to use the same holes) Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
-
Page 14: Treadmill Operation
2. Plug the power cord into an appropriate outlet that is properly installed and grounded. See drawing below. Important: The treadmill is not compatible with GFCI-equipped outlets . Note: Your power cord and outlet may appear different. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... -
Page 15: Operation Of Your Treadmill
3. To slow tread-belt press and hold the Speed ▼ key to the desired speed. You may also press. The Speed keys 1 through 9 then press ENTER key confirm. 4. To stop the tread-belt press the Stop key or pull away Safety key. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... -
Page 16: Calorie Display
When “Lube” appears on the LCD check lubrication under walking deck. See the instructions on page 18 to add lube as needed. After application hold ENTER for 3 seconds to reset the message. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... -
Page 17: Preset Program Profiles
3 Seconds before the ending of a program a buzzer will sound three times, then the running belt will come to a stop. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... -
Page 18: General Maintenance
1/4 turn and wait a few minutes for the belt to adjust itself. Continue to make 1/4 turns until the belt stabilizes in the center of the running deck. The belt may require periodic tracking adjustment Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... - Page 19 5 minutes to ensure the lubricant is evenly distributed. If you purchase a Lube-N-Walk kit, follow the instructions that come with it to apply the lubrication. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
- Page 20 Lift one side of the tread-belt and feel the top surface of the tread board. If the surface is (slick) to the touch, then no further lubrication is required. If the surface is dry to the touch, apply one packet of lubricant or half of the bottle of lubricant. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
-
Page 21: Reset Switch Resetting
Remove the safety clip on console. Press white tab of the reset switch in until it snaps back into place. If the reset switch continues to trip - see tread-belt adjustment and tread-belt lubrication Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... -
Page 22: Service Checklist - Diagnosis Guide
Showing E5 controller. the controller or communication error Console Controller Malfunction 1. Controller component failure Showing E6 Console Abnormal Power Input 1. Check for proper voltage input for treadmill. Showing E7 Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... -
Page 23: Exploded View Diagram
EXPLODED VIEW DIAGRAM Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... -
Page 24: Parts List
Oval End Cap 8015029 Foot Rail 8015030 Power Socket 8015031 Breaker 8015032 On/Off Switch 8015033 Power Cord 8015034 End Cap 8015035 ０ 25 × 50 × 3T × 275m/m_Handgrip Foam 8015036 Motor Controller Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... - Page 25 Ø4 × 12m/m_Sheet Metal Screw 8015081 Ø9.1 × 53L_Constrict Spring 8015082 Ø5 × 16m/m_Tapping Screw 8015083 Ø3.5 × 12m/m_Sheet Metal Screw 8015084 1/4" × 5T_Nyloc Nut 8015085 1/2" × 8T_Nyloc Nut Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
- Page 26 8015089 Ø4 × 45m/m_Sheet Metal Screw 8015091 Ø3 × 10m/m_Sheet Metal Screw 8015092 Ø10 × Ø25 × 2.0T_Flat Washer 80150104 Combination M5 Allen Wrench & Phillips Head Screw Driver 80150105 Lubricant Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
-
Page 27: Training Guidelines
This is the minimum level of exercise which is required to produce significant improvements in any physical fitness parameter. Progression As your become fitter, a higher intensity of exercise is required to create an overload and therefore provide continued improvement Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... - Page 28 Some of its natural loss is won back as fitness improves. The following table is a guide to those who are “starting fitness”. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
- Page 29 The body responds better to variety and so do you. In addition, when you feel yourself getting “stale’, bring in periods of lighter exercise to allow the body to recuperate and restore its reserves. You will enjoy your program more and feel better for it. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
-
Page 30: What To Wear
This will depend mostly on your level of fitness and the program you have chosen. Rest between exercises by all means, but do not allow this to exceed two minutes. Most people manage with half minute to one-minute rest periods Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca... - Page 31 Bring your heel as close to your buttocks as you can for one count. Feel the stretch up possible. Hold for 15 counts and repeat with your right side. Repeat this action with your left foot up. left arm. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
- Page 32 Relax and then repeat with left leg floor then bend the left leg and lean forward extended. by moving your hips toward the wall. Hold, then repeat on the other side for 15 counts. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018 Email: customerservice@dyaco.ca...
-
Page 33: Manufacturer's Limited Warranty
MANUFACTURER’S LIMITED WARRANTY Dyaco Canada Inc. warrants all its treadmill parts for a period of time listed below from the date of retail sale, as determined by sale receipt. Dyaco Canada Inc.’s responsibilities include providing new or remanufactured parts, at Dyaco Canada Inc.’s option, and technical support to our independent dealers and servicing organizations. - Page 34 Please visit us online for information about our other brands and products manufactured and distributed by Dyaco Canada Inc. www.dyaco.ca www.dyaco.ca www.dyaco.ca www.dyaco.ca www.spiritfitnesscanada.ca www.spiritfitnesscanada.ca www.dyaco.ca www.dyaco.ca www.solefitness.ca www.trainorsports.ca www.dyaco.ca www.dyaco.ca www.xterrafitness.ca www.dyaco.ca Customer Service 1-888-707-1880 Dyaco Canada Inc. 2018...
