- Page 1 Owner’s Manual Model No. 16007601850 XT185 - Assembly - Operation - Adjustments - Parts - Warranty CAUTION: Read and understand this manual before operating unit Retain For Future Reference...
-
Page 2: Table Of Contents
Important Safety Instructions…………………………………………………. 4 Important Electrical Instructions……………………………………………… .6 Assembly Instructions…………………………………………………………..9 Folding Instructions……………………………………………………………14 Operation of Your New Treadmill…………………………………………….15 Programmable Features……………………………………………………..19 Exploded View Diagram …..…………………………………………………..21 Parts List……………………………………………………………………….. 22 General Maintenance…………………………………………………………..26 Manufacturer’s Limited Warranty……………………………………………..31 Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 3: Product Registration
CONGRATULATIONS ON YOUR NEW TREADMILL Thank you for your purchase of this quality treadmill from Dyaco Canada Inc. Your new treadmill was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available. Through you dealer, Dyaco Canada Inc., will do all we can to make your ownership experience as pleasant as possible for many years to come. -
Page 4: Important Safety Instructions
3 meters safe clearance on all sides of the treadmill while in use. 8. Keep the treadmill indoors, away from moisture and dust. Do not put the treadmill in a garage, covered patio or near water. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... - Page 5 Read all instructions before using any fitness equipment. We assume no responsibility from personal injury or property damage sustained by or through the use of this product. SAVE THESE INSTRUCTIONS Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca...
-
Page 6: Important Electrical Instructions
Pushing harder is not going to make the unit go faster or slower. If you feel the buttons are not functioning properly with normal pressure, contact your Spirit dealer. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 7: Safety Tether Cord
Be familiar with its function and limitations. The treadmill will stop, depending on speed, with a one to two step coast anytime the magnet is pulled off the console. Use the Stop/Pause switch in normal operation. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 8: Assembly Pack Checklist
Button Head Socket Bolt (4 pcs) #93. 5/16" × 15m/m #132. M5 #142. Ø3.5 × 16m/m Button Head Socket Bolt (8 pcs) Speed Nut Clip (6 pcs) Sheet Metal Screw (8 pcs) #58. Lubricant Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 9: Assembly Instructions
ASSEMBLY TOOLS #97. M6 L Allen Wrench #96. Combination M5 Allen Wrench #122. Phillips Head Screwdriver Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... - Page 10 Frame Base Covers (L, R), (42 & 43) and Console Mast Covers (L, R) (99 & 100), respectively, as shown further below. Connect Computer Cable (Middle) (38) with Computer Cable (Lower) (39). Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca...
- Page 11 Install Frame Base Covers (L) and (R), (42 & 43), on the Frame Base (2) and secure with 6 pcs of Ø5 × 16m/m_ Tapping Screws (88) by using Phillips Head Screwdriver (122). Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca...
-
Page 12: Dyaco Canada Inc
Insert Console Assembly (40) into right and left Uprights (4 & 5) and secure with 4 pcs of 3/8"×1-3/4" Button Head Socket Bolts (90) with 4 pcs of Ø10 × 2.0T Split Washers (82) by using M6_L Allen Wrench (97). Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 13: Email: Customerservice@Dyaco.ca
Uprights (4 & 5). Then secure with 6 pcs of Ø3.5×16m/m Sheet Metal Screws (142) by using Phillips Head Screwdriver (122). NOTE: Please tighten all screws after all components have been assembled. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 14: Folding Instructions
*At the rear roller area to relieve pressure on the locking system. Transportation Instruction The treadmill is equipped with four transport wheels that are engaged when the treadmill is folded. After folding simply roll the treadmill away. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 15: Operation Of Your New Treadmill
Pulse, Speed, Incline, Program Name, number of Laps completed, and Segment Time. There is also a Speed & Incline profile graph that lets you see how hard you have worked and how challenging the upcoming segments will be. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 16: Email: Customerservice@Dyaco.ca
• The display will indicate incline percent in increments of .5 as adjustments are made. • The incline will return to zero unless the main power switch or safety key are turned off while it is at a higher setting. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 17: Email: Customerservice@Dyaco.ca
The Pulse Display Window will display your heart rate, or pulse in beats per minute. The console includes a built-in fan to help keep you cool. To turn the fan on, press the key on the left side of the console. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 18: Email: Customerservice@Dyaco.ca
Each preset program has a maximum Speed and Incline level that is displayed when a desired workout is chosen. The maximum Speed and Incline that the particular program will achieve will be displayed in the Message Center. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 19: Programmable Features
Incline + / - keys to adjust, then press Enter. You are now done programming data and may press Start to begin your workout or Enter to go back one level to change data entered in the programming phase. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 20: Email: Customerservice@Dyaco.ca
(columns); this means that all of your lower extremity muscles will be equally challenged throughout this program. The incline alternates between 25 & 65 % of maximum elevation Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 21: Exploded View Diagram
EXPLODED VIEW DIAGRAM Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 22: Parts List
200m/m_Connecting Wire (White) 6018536 200m/m_Connecting Wire (Black) 6018537 800m/m_Computer Cable (Upper) 6018538 1300m/m_Computer Cable (Middle) 6018539 1200m/m_Computer Cable(Lower) 6018540 Console Assembly 40~1 6018540-1 Console Top Cover 40~2 6018540-2 Console Bottom Cover Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 23: Email: Customerservice@Dyaco.ca
3 × 10m/m_Sheet Metal Screw 6018569 3/8" × 2"_Flat Head Socket Bolt 6018570 5/16" × 1"_Button Head Socket Bolt 6018571 M8 × 60m/m_Hex Head Bolt 6018572 M8 × 80m/m_Socket Head Cap Bolt (Alloy Steel) Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... - Page 24 Ø5.5 × 27 × 60 × 1T× 2.5H_Concave Washer 60185115 Ø5 × Ø13 × 1.0T_Flat Washer 60185116 M3_Split Washer 60185117 3 × 10m/m_Sheet Metal Screw 60185118 Controller Back Plate 60185120 400m/m_Console Ground Wire Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca...
-
Page 25: Email: Customerservice@Dyaco.ca
Handpulse Top End Cap 60185139 Handpulse Bottom End Cap 60185140 Ø8 × 1.5T_Split Washer 60185141 M8 × 12m/m_Hex Head Bolt 60185142 Ø3.5 × 16L_Sheet Metal Screw 60185152 Ø5 × 19L_Tapping Screw Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 26: General Maintenance
- that connects the motor to the front roller. If that belt is loose it feels similar to the walking belt being loose. Tightening the motor belt should be done by a trained service person. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 27: Email: Customerservice@Dyaco.ca
DAMAGE TO THE RUNNING BELT RESULTING FROM IMPROPER TRACKING / TENSION ADJUSTMENTS IS NOT COVERED UNDER THE WARRANTY. Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 28: Email: Customerservice@Dyaco.ca
• Press the Speed + button until “Maintenance” message appears; press Enter • Press Stop to exit Engineering mode and resume use of your treadmill Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 29: Email: Customerservice@Dyaco.ca
Refer to Grounding Instructions. walking/running House circuit breaker trips, but not Need to replace the house breaker with a “High In- the treadmill circuit breaker rush current” type breaker(see page 6 for details) Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 30: Email: Customerservice@Dyaco.ca
When the child lock is enabled, the console will not allow the keypad to operate unless you press and hold the Start and Enter buttons for 3 seconds to unlock the console.) 5. Exit Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016 Email: customerservice@dyaco.ca... -
Page 31: Manufacturer's Limited Warranty
All of the parts for the Spirit Treadmill, shown in figure can be ordered from: Dyaco Canada Inc., 5955 Don Murie Street, Niagara Falls, Ontario L2G 0A9. When ordering parts, the parts will be sent and billed at the current prices. -
Page 32: Email: Customerservice@Dyaco.ca
Please visit us online for information about our other brands and products manufactured and distributed by Dyaco Canada Inc. www.dyaco.ca www.dyaco.ca www.dyaco.ca www.dyaco.ca www.spiritfitnesscanada.ca www.spiritfitnesscanada.ca www.dyaco.ca www.dyaco.ca www.solefitness.ca www.trainorsports.ca www.dyaco.ca www.dyaco.ca www.xterrafitness.ca www.dyaco.ca Customer Service 1-888-707-1880 Dyaco Canada Inc. 2016...
