WolfVision EYE Series Quick Instructions

QUICK INSTRUCTIONS EYE-Series
The next page describes everything a typical user should know about the Visualizer. More detailed information can be found in
the detailed instruction manual (in English and German).

Precautions

Safety information

Use this unit only with the correct voltage as shown on the type label!
-
Do not expose the unit to extreme Heat or moisture!
-
- Protect the unit from excessive shocks!
Make sure that sufficient air circulation for cooling the unit is possible!
-
- If there is any abnormality (abnormal noise, smell, smoke etc.) disconnect the unit from mains immediately and contact your
WolfVision dealer!
- Do not use a damaged power cord / power supply. This may cause short circuits or electrical shocks!
- Do not modify the unit or operate it without the cover firmly in place!
Do not expose the unit to liquids, metallic objects or any flammable material!
-
- Avoid installing the unit in locations exposed to strong magnetic fields or electrical currents. This could cause monitor image
distortion or damage to the CCD camera!
- Avoid installing the unit in environments where there is radiation!
Never touch the power supply or power cord with wet fingers!
-
- If the unit is not used for a long time, disconnect it from mains!
- The power source equipment has to be approved by CSA or UL in accordance to CSA 22.2-60950 or UL 1950. And it shall
comply with all applicable local and national codes related to safety!
- The Power over Ethernet power equipment (PoE PSE) shall be classified as Limited Power Source (LPS) in accordance
with IEC 60950-1:2001!
- No user serviceable parts inside! Refer servicing to qualified service personal only!
Do not stare directly into laser beam!
-
Überlassen Sie den Service geschultem Personal!
-
- Nicht in den Laserstrahl blicken!

Laser Information

FDA accession number: 9912688-00
This device complies with:
21 CFR 1040.10 and 1040.11
