0902 [Ppr Align in Stack Tray: Acr Feed 2]

Adjust the alignment width in Sub Jogger at the Stacker to reduce dispersion of sheets at right angles
due to paper size, thickness, curl, etc.
Setting Items
[A3 SEF]
[B4 JIS SEF]
[11 × 17 SEF]
1
[8 / × 14 SEF]
2
[Other Paper Sizes]

0903 [Paper Alignment in Stacker Tray: With Feed]

Adjust the alignment position of the Tip Stopper at the Stacker to reduce variations of paper orientation
in the feeding direction due to paper size, thickness, curl, etc.
Default Max.
Value Value
0.0 1.0
[Finishing: Stacker]
Min.
Step
Value
-1.0 0.1
Unit
mm
