Danfoss AME 20 Operating Manual page 2

AME 20, AME 30
MAINTENANCE
FREE
4 – 6 mm × 1 mm 32 mm
❷
①
Max 25 Nm
1× 32 mm
❸
Wiring for modulating mode
Proportional 3 point/RL
SN 0 V
SP 24 VAC Power supply
0(2)-10 V
Y
0(4)-20 mA
1
0 V
3
X 0(2)-10 V
Wiring for 3-point floating mode
Controller with relay output
Proportional 3 point/RL
SN
0 V
SP 24 VAC Power supply
1
24 VAC
3
X 0(2)-10 VDC
2 | © Danfoss | 2016.11
5-95 % RH
no condensing
T 10
②
4×
or
①
②
Neutral
Input
Input
Output
Neutral
Input
Output
❶
③
③
Proportional
A
B
Wiring for 3-point floating mode
Controller with triacs output
3 point/RL
SN 24 VAC Neutral
SP
0 V Power supply
1
24 VAC Input
3
X 0(2)-10 VDC Output
CLOSE
OPEN
EI.96.I3.2U
