Disassembling and Assembling, APP 21-43
Service guide |
14 | 180R9121 | 521B1018 | DKCFN.PI.013.A6.02
11. Warning:
Ensure that the piston shoes and the
piston surfaces are not damaged during
removal. It is recommended to place the
pistons upside down on an even and
clean base/surface.
13. Inspect the piston liners.
Replace any worn parts.
12. Remove the retainer ring by sliding
it across the stop for the retainer ball. If
necessary, tilt the flange.
