- Page 1 Revolution Bedienungsanleitung Operating instructions Gebruiksaanwijzing Mode d´emploi...
- Page 2 Revolution...
-
Page 3: General Safety Instructions
Revolution Latest generation fully automatic rotary laser of an extremely durable design Electronic vials and positioning motors controlled by temperature-stable sensors for automatic alignment, 4° self-levelling range, precision 1 mm / 10 m. Maximum safety and reliability are ensured by the anti-drift system (ADS): the electronic system conti- nuously monitors the measurement and switches the laser off if the device is disturbed by external factors. -
Page 4: Brief Instructions
Revolution Brief instructions Initial switch-on Use the ON/OFF button to switch the device on. The automatic sensor now levels the device horizontally and/ or vertically; the laser remains stationary and flashes during this set-up phase. As soon as levelling is comple- te, the laser starts to rotate at 750 rpm. - Page 5 Revolution Single slope In automatic mode, an axis can be manually set to a function certain slope using this function, even if the ADS tilt function is also active. This means that one axis can be re-adjusted whilst the other is aligned horizontally and/ or vertically.
-
Page 6: Anti-Drift-System (Ads)
Revolution Sensor Automatic The rotary laser aligns itself automatically. It is set to the required initial position (to within an operating angle of ± 4°) and the automatic system then performs the neces- sary fine adjustment, with three electronic measurement sensors detecting the X, Y and Z axes. - Page 7 Revolution Reference / plumb laser outlet Battery compartment Prism head / laser beam outlet Centring tip (retractable) Receiver diodes for remote control 5/8" thread for vertical operation (4 x) Slot for inserting high-performance Control panel rechargeable battery/battery com- partment 5/8" thread for horizontal operation...
- Page 8 Revolution Control panel Revolution Optional accessory: Commander 50 ON/OFF button Positioning button (rotate to the left) Operation/battery indicator Hand receiver mode Scan mode Adjustment mode: toggle between X and Y axes Rotary speed for selection, 750 / 350 / 0 rpm...
- Page 9 Revolution Optional accessory: SensoLite 310 Protection class IP 66 All-round marking groove Hand receiver above laser level Receiver field for laser beam Precisely on laser level SpotLite Marking LED Hand receiver below laser level Vial Volume indicator Fastening screw for levelling staffs...
- Page 10 Revolution Battery (NiMH) charging • Charge rechargeable batteries fully before using the device. • Connect the charger to the mains power supply and the charging socket (G) on the high-performance rechargeable battery (H). Please only use the charger supplied; using a different charger will invalidate the warranty.
-
Page 11: Anti-Shake Function
Revolution Horizontal and vertical use Setting up • Horizontal: Position the device on a level surface or on a tripod. • Vertical: unfold centric point (J) and position unit in vertical mode. Pre- adjust unit with vertical vial (O) and adjusting screws (N). The sensor then adjusts the unit automatically. - Page 12 Revolution Single slope function In automatic mode, an axis can be manually set to a certain slope using this function, even if the ADS tilt function is also active. This means that one axis can be re-adjusted whilst the other is aligned horizontally and/or vertically. Press the slope/man button to activate the function and select the X or Y axis.
- Page 13 Revolution Manual slope function This function deactivates the automatic sensor, which enables two axes to be re-adjusted simultaneously and steep slopes to be set. To use the function, press the slope/man but- ton repeatedly until the man LED lights up. Use the tilt button to toggle between the X and Y axes.
- Page 14 Revolution Manual slope function Manual re-adjustment: Steeper slopes can be set using the angle plate, which is available as an optional extra (product ref. 080.75). To this end you need to use a crank tripod, such as the 300 cm professional crank tripod, pro- duct ref.
-
Page 15: Spot Mode
4 different widths. You position the segment via the direction buttons. Revolution Green The distance at which a laser is visible to the naked eye depends on its colour i.e. wavelength. This is because of the human eye's physiology – green appears brighter to us than red. - Page 16 If points A2 and A3 are more than 1 mm / 10 m apart on either the X or Y axis, the device is in need of adjustment. Contact your authorised dealer or else the UMAREX- LASERLINER Service Department. ENGLISH...
-
Page 17: Adjustment Mode
1. Take the alignment of the rotary laser into account when performing adjustment work. Always adjust all the axes. 2. Switch the device to adjustment mode: Switch off the Revolution and then switch it on again (press the ON/OFF but- ton briefly), whilst holding down the slope/man button. Keep the slope/man (13) button pressed down until the X, Y and Z axis LEDs light up simultaneously. - Page 18 1 x 9V Block / 1 x 9V Block Remote control range Commander 50 max. 50 m (IR-Control) Laser reception range max. 300 m / Revolution red SensoLite 310 max. 200 m / Revolution green Temperature range, operating / storage -10°C ...
- Page 19 Revolution Zubehör (optional) Accessories (optional) Accessoires (optioneel) Accessoires (en option) Art.-Nr: 035.00A Revolution Red (Revolution Green) Art.-Nr: 035.01 Revolution Red Art.-Nr: 080.50 (Revolution Green) Revolution Red Art.-Nr: 080.51 Revolution Green Art.-Nr: 075.105 (5m) Art.-Nr: 080.33...
- Page 20 Laser class 3R < 5 mW · 635 nm EN60825-1:2007-10 Service- und Versand-Anschrift UMAREX GmbH & Co. KG – Laserliner – Service- and Shipping Address Möhnestraße 149, 59755 Arnsberg, Germany Service- en verzendadres Tel.: +49 2932 638-300, Fax: -333 laserliner@umarex.com...
