FlexRadio Systems FLEX-5000 Series Owner's Manual page 169

O P E R A T I O N
1. Follow the Power Up Procedure, described on page 156. Then click the Start/Stop button
(14). Set the following controls as specified in Table 11 below.
2. In the Antenna Form (38) choose Simple complexity level and set RX1 to ANT1 (see page
149 for more on the Antenna Form). Connect a 50 ohm dummy load to the ANT 1 antenna
jack, or tune VFO A (1) to a quiet frequency on the selected band. Use the TUN (19) button
to verify power output on the TX Meter (4) (Set to Fwd Pwr). If using the optional,
integrated ATU, select Automatic on the ATU Form (39) and then click the TUN (19)
button. See the section on the ATU Form on page 153 for more on how to use the ATU.
Table 11: Initial Control Values for Voice Operation
Ctrl
VFO A 14.3MHz
RX1 Meter Signal
TX Meter MIC
BAND 20
Mode USB
Filter 2.7kHz
Mic Gain 35
DX Off
CPDR Off
VOX Off
GATE Off
RX EQ Off
TX EQ Off
VAC Off
Display Mode Panadapter
AVG On
PEAK Off
MultiRX Off
SPLT Off
XIT Off
RIT Off
MUT Off
ATU/BYP ATU (if applicable)
AF 50
AGC-T 70
Drive 50
AGC Med
Preamp On
SQL Off
RX2 Off (if applicable)
[The rest of this page has been left blank intentionally]
Reference to
Value Figure 148
161
C H A P T E R
(1)
(4)
(4)
(5)
(6)
(7)
(8)
(8)
(8)
(8)
(8)
(8)
(8)
(8)
(9)
(9)
(9)
(10)
(12)
(12)
(12)
(17)
(20)
(21)
(22)
(23)
(24)
(25)
(26)
(29)
