Generac Power Systems SG30 Owner's Manual page 63

1 0F6643 1
2 0C2454 64
3 0F5849AG 2
4 ** 077992 5
5 0F3890A 6
6 0F6647 2
7 0F6642 2
8 0F6650 1
9 049813 2
10 022447 2
11 0F6644 1
12 0E5968 1
13 0F5048D 2
14 022127 1
15 022097 1
16 0F5049 2
17 0C2634A 1
18 022473 3
19 042568 2
20 0912970089 2
21 0F7306A 2
22 078115 12
23 0F7651 1
24 0F4051A 1
25 089961 2
26 029289 4
27 029289 2
28 029289 1
29 0F7678 3
30 0F9494 2
31 0F8869D 1
** ALUMINUM ENCLOSURE NOTE: ALL ENCLOSURE PANELS THAT FASTEN TO
THE BASE FRAME MUST BE SECURED USING ITEM 2 & 5 THREAD FORMING
FASTENER AND ITEM 4 LOCK NUT. LOCK NUT IS TO BE INSTALLED AFTER THREAD
FORMING FASTENER HAS PENETRATED THROUGH EXTRUSIONS IN
ENCLOSURE PANELS.
REAR WRAP
SCREW THF M6-1 X 16 N WA Z/JS
DOOR C2 ALUM GRAY
NUT HEX LOCK M6-1.0 SS NY INS
RETAINER INSULATION (740)
DISCHARGE DUCT L/H & R/H SIDE
FRONT CORNERS
DISCHARGE DUCT MIDDLE
NUT HEX M6 X 1.0 G8 YEL CHR
WASHER SHAKEPROOF INT 1/4
ROOF
GASKET EXTRUDED TRIM (158.50" LG)
VISE-ACTION LATCH SLOTTED CIR
NUT HEX 1/4-20 STEEL
WASHER LOCK M6-1/4
TAB PULL
ASSEMBLY COVER ACCESS
WASHER FLAT 1/4-M6 ZINC
SCREW HHC M6-1.0 X 20 G8.8
ASSY WIRE 14AWG 31.3" BLK
INSULATION SIDE SUPPORT
WASHER SELF LOCKING DOME
BAFFLE AIR
INSULATION ROOF TOP
FOAM STRIP 3/4" WIDE X 3/16" THK (144" LG)
TAPE ELEC 1/2 FOAM (40" LG)
TAPE ELEC 1/2 FOAM (8" LG)
TAPE ELEC 1/2 FOAM (33.187" LG)
BRACKET AIR BAFFLE
HEX KEY 5/16 (NOT SHOWN)
KEY VISE-ACTION LATCH SLOT CIR
