Generac Power Systems SG30 Owner's Manual page 49

1 0F6830 1 REWORK L/P TANK 120 GAL
2 0F7534 1 POL VALVE TUBE 1/4" NPT
3 033930 2 ELBOW 90D 1/4 NPT
4 026942 3 NIPPLE CLOSE 1/4 NPT X .875
5 0F7530 1 BRACKET MAGNETIC SENSOR DOOR
6 0F7643 1 SWITCH MAGNETIC REED
7 0F7531 1 BRACKET MAGNETIC SENSOR TANK
8 0F6831 1 FRAME L/P TANK
9 0F6956 1 PAN FLUID CONTAINMENT
10 0F7012 1 REGULATOR 2-STAGE
11 026739 1 ELBOW RED STREET 3/4 X 1/2
12 090388 2 SCREW HHTT M6-1.0 X 12 ZINC
13 055934N 2 CLAMP VINYL 1.31 X .281 Z
14 028641 1 NIPPLE TOE 3/4 NPT X 2
15 035473 2 CLAMP HOSE #12 .50-1.25
16 057422 1 HOSE 1IN ID LP GAS (66" LG)
17 0F9111 1 ASSEMBLY SOLENOID 12V
18 ** 029333 3 TIE WRAP UL 7.4" X .19" NATL (NOT SHOWN)
19 096500V 1 ASSY FUEL LEAK DTCTR ALRMW/CON
20 074908 17 SCREW HHTT M5-0.8 X 10 BP
21 0F6832 4 BOLT CARR 9/16-12 X 2-1/4"
22 0F7035 1 HARNESS L/P TANK FRAME
23 047411 4 SCREW HHC M6-1.0 X 16 G8.8
21 0F6832 4 BOLT CARR 9/16-12 X 2-1/4"
22 0F7035 1 HARNESS L/P TANK FRAME
23 047411 4 SCREW HHC M6-1.0 X 16 G8.8
24 022473 10 WASHER FLAT 1/4-M6 ZINC
25 022097 6 WASHER LOCK M6-1/4
26 049813 4 NUT HEX M6 X 1.0 G8 YEL CHR
27 036902 4 SCREW PPHM #6-32 X 1/2
28 022985 4 WASHER FLAT #6 ZINC
29 022155 4 WASHER LOCK #6
30 022188 4 NUT HEX #6-32 STEEL
31 024413 2 SCREW HHTT #10-32 X 1/2 BP
32 *** 085916 6 SCREW HHC 3/8-16 X 1 SS (NOT SHOWN)
33 *** 088775 12 WASHER FLAT 3/8 SS (NOT SHOWN)
34 *** 085917 6 WASHER LOCK 3/8 SS (NOT SHOWN)
35 0A6054 4 NUT HEX 9/16-12
36 070265 4 WASHER LOCK M16
37 0A1646 4 WASHER FLAT M16
38 022287 2 SCREW HHC 1/4-20 X 3/4 G5
39 0C4632 1 PALLET 'A' GRP OPEN
40 022131 6 WASHER FLAT 3/8-M10 ZINC
41 021442 6 SCREW HHL 3/8 X 4.0
42 035482 1 NIPPLE PIPE 1/4 IN X 6 IN
43 024268 1 COUPLING FULL 1/4-18
40 022131 6 WASHER FLAT 3/8-M10 ZINC
41 021442 6 SCREW HHL 3/8 X 4.0
42 0F7567 1 NIPPLE PIPE 1/4 NPT X 5-1/2
43 024268 1 COUPLING FULL 1/4-18
44 0F7667 2 DECAL NO FORKS
45 0F7670 1 PAN RAIN RUNNOFF
46 0D3573 1 ROCHESTER ELEC. GAUGE
47 0F7688 8 END CAP PLASTIC 3" X 3" SQUARE
48 0F2776D 1 BRACKET SIGNAL CONDITONER
49 * 029333 1 TIE WRAP UL 7.4" X .19" NATL (NOT SHOWN)
50 *** 085918 6 NUT HEX 3/8-16 SSTL (NOT SHOWN)
51 0G0050 1 DOOR LATCH, 2-PIECE STEEL
52 0F9245 4 RIVET POP .125 X .337 SS
* TO HOLD SENSOR FROM HARNESS TO I/N 48.
** TO HOLD HARNESS TO I/N 16.
*** MOUNTING HARDWARE FOR GENSET TO L/P TANK FRAME.
PUT IN BAG & TIE WRAP TO FRAME.
NOTE: 1.) ADD PIPE SEALANT TO ALL NPT FITTINGS.
2.) ADD RTV TO SEAM BETWEEN I/N 45 & I/N 9.
