Checklist

This list provides an overview of the requirements to be met in installation, commissioning and opera-
tion of the safety function Depending on the application, additional requirements must be met. Com-
plete this list according to your application.
Risk analysis:
− was performed
requires the use of the safety function "Safe Torque Off"
−
requires category 3 according to the following classifications:
−
- PL d (or smaller) according to EN ISO 13849-1
- SIL 2 (or smaller) according to IEC 61508
- Category 3 (or smaller) according to EN 954-1
− considers the stopping behavior of the ACTIVE Cube frequency inverter
− permits coasting of the drive to a standstill or requires the installation of a mechanical brake.
− considers the access time to the hazard area
− defines intervals for regular functional checks of the safety function
Installation:
EMC instructions in the operating instructions considered?
−
The shield of the 24 V power supply was connected on both sides.
−
− Emergency stop devices meet the following classifications:
- PL d (or smaller) according to EN ISO 13849-1
- SIL 2 (or smaller) according to IEC 61508
- Category 3 (or smaller) according to ENn 954-1
− Emergency Stop devices have a cross fault monitoring (2-channel connection) or protected wir-
ing?
It is ensured that resetting of the safety control device alone does not result in a restart of the
−
drive.
It is ensured that no voltage higher than DC 30 V can occur on the terminals of the control elec-
−
tronic unit (voltage resistance).
− The protection against unexpected restart is set up.
Commissioning:
− Functional check of safety function performed?
− Wiring of safety components checked?
− Acceptance report issued?
Operation:
The safety function is checked regularly.
−
