7.4

DC 24 V Power supply by ACU

You can use terminal X210A.1 in order to supply a safety control device. Only use the power supply
for the device connected to the frequency inverter. Other safety control devices must not be con-
nected. The maximum output current is 180 mA. The connected device must not have higher current
requirements.
8

Requirements to be met in operation

During operation, the projected and commissioned machine components must not be changed. If the
machine is modified a new acceptance inspection is required.
Check the safety function at regular intervals. The test intervals are to be determined according to the
risk analysis. However, the check should be performed once every year, at the latest.
9

Requirements to be met by acceptance inspection

The acceptance inspection of the safety function is ordered by the manufacturer of the machine. The
inspection (acceptance) shall be performed by a properly qualified person.
The result of the inspection is to be documented and must be signed by the inspector. Each safety
function must be documented in detail in this report.
The inspections also include the machine documentation, including its safety functions. The safety
functions must be checked particularly during the inspection and documented in the inspection report.
Parameter settings shall be attached to the report. Further documents shall be added, as required,
depending on the machine.
Depending on the result of the risk analysis, inspection reports of the regular inspections shall be is-
sued and signed by the inspector.
