Behavior of frequency inverter after start
Initialization
−
− Monitoring for release request (5-second monitoring)
− Preparation of release (check of stop paths)
− Release of frequency inverter
Behavior of frequency inverter in the case of an error
Switch off of IGBT in power output stage by disconnection of optocoupler supply voltage
−
Suppression of control pulses of IGBT
−
Setting of error bit with possibility of transfer to overriding controller
−
Setting of digital output for error message
−
Release of digital input for error acknowledgement.
−
6.2

Diagnosis function and enforced dynamizing

The two stop paths are monitored by the frequency inverter every 32 ms. If at least one of the two
inputs S1IND (STOA) or S7IND (STOB) is switched off, the pulse block is activated. Additionally, a 5-
second monitoring cycle begins for the other stop path. If this path is not stop within 5 s, error F1205
is output.
The test required for monitoring the stop paths is performed by the frequency inverter automatically.
Via automated enforced dynamizing, the stop paths are checked for errors. If the test result is nega-
tive, the frequency inverter cannot be switched on anymore, and error F1201 is signaled. Starting is
possible again only after the error has been repaired and the next diagnosis cycle has been completed
successfully.
